| Ref | Part Number | Description |
|---|
| 1 |
36560A |
CYLINDER This part replaces 34708A. Price: $73.24 |
| 2 |
26727 |
DOWEL PIN Price: $1.26 |
| 14 |
28277 |
WASHER Price: $1.26 |
| 15 |
31334 |
GOVERNOR ROD Price: $3.89 |
| 16 |
37735 |
LINK & LEVER This part replaces 31510. Price: $9.95 |
| 17 |
31335 |
CLAMP Price: $1.26 |
| 18 |
651018 |
SCREW This part replaces 650548. Price: $1.18 |
| 19 |
31426 |
EXT SPRING Price: $2.80 |
| 20 |
32600 |
OIL SEAL Price: $4.80 |
| 25 |
36552 |
BAFFLE This part replaces 33342. Price: $6.54 |
| 25A |
35883 |
EXTENSION Price: $1.26 |
| 26 |
650561 |
SCREW Price: $1.25 |
| 26A |
650926 |
SCREW This part replaces 650884. Price: $0.88 |
| 30 |
37303 |
CRANKSHAFT This part replaces 34709. Price: $91.01 |
| 40 |
34514 |
PISTON ASSY STD Price: Call Us |
| 40 |
34515 |
PISTON ASSY 010 Price: $57.12 |
| 40 |
34516 |
PISTON ASSY 020 Price: $57.12 |
| 41 |
32538B |
PISTON & PIN ST Price: $31.97 |
| 41 |
32548B |
PISTON & PIN 10 Price: $34.97 |
| 41 |
32549B |
PISTON & PIN 20 Price: $35.71 |
| 42 |
28986 |
RING SET STD Price: Call Us |
| 42 |
28987 |
RING SET 010 Price: $20.53 |
| 42 |
28988 |
RING SET 020 Price: Call Us |
| 43 |
20381 |
RET RING Price: $1.26 |
| 45 |
30963B |
CONN ROD Price: $20.90 |
| 46 |
32610A |
SCREW Price: $1.26 |
| 48 |
27241 |
VALVE LIFTER Price: $3.89 |
| 49 |
28594 |
OIL DIPPER Price: $6.11 |
| 50 |
33149A |
CAMSHAFT Price: $36.24 |
| 60 |
29745 |
EXTENSION Price: $2.62 |
| 65 |
650128 |
SCREW Price: $3.60 |
| 69 |
27677A |
GASKET Price: $5.31 |
| 70 |
35863A |
CYL COVER This part replaces 35863. Price: $70.85 |
| 72 |
27642 |
PIPE PLUG Price: $1.26 |
| 75 |
26208 |
OIL SEAL Price: $5.75 |
| 80 |
30574A |
GOV SHAFT This part replaces 30574. Price: $5.00 |
| 81 |
651080 |
WASHER This part replaces 30590A. Price: $1.24 |
| 82 |
30591 |
GEAR Price: $9.93 |
| 83 |
30588A |
GOV SPOOL Price: $1.26 |
| 84 |
29193 |
RET RING Price: $1.26 |
| 86 |
650488 |
SCREW Price: $1.25 |
| 89 |
610961 |
KEY Price: $1.09 |
| 90 |
611080A |
FLYWHEEL This part replaces 611080. Price: $87.68 |
| 92 |
650815 |
WASHER Price: $1.25 |
| 93 |
650816 |
NUT Price: $2.95 |
| 100 |
34443D |
LAMINATION This part replaces 34443A. Price: $35.95 |
| 101 |
610118 |
PLUG COVER Price: $4.45 |
| 102 |
651024 |
STUD This part replaces 650872. Price: $2.60 |
| 103 |
651007 |
SCREW This part replaces 650814. Price: $1.17 |
| 110 |
35182 |
GROUND WIRE Price: $1.26 |
| 119 |
29953C |
GASKET Price: $12.00 |
| 120 |
36438 |
CYL HEAD This part replaces 30579A. Price: $23.98 |
| 125 |
29313C |
EXH VALVE STD Price: $6.23 |
| 125 |
29315C |
EX/INT VALVE OS Price: Call Us |
| 126 |
29314C |
INT VALVE ST This part replaces 29314B. Price: $4.05 |
| 126 |
29315C |
EX/INT VALVE OS Price: Call Us |
| 130 |
650694A |
SCREW Price: $2.15 |
| 131 |
6021A |
SCREW Price: $1.26 |
| 135 |
33636 |
SPARK PLUG Price: $5.05 |
| 150 |
31672 |
VALVE SPRING Price: $1.26 |
| 151 |
31673 |
VALVE CAP Price: $1.23 |
| 169 |
27234A |
GASKET Price: $3.95 |
| 170 |
27666 |
BREATHER Price: $10.56 |
| 171 |
31410 |
ELEMENT Price: $1.19 |
| 172 |
34146 |
COVER Price: $2.62 |
| 173 |
35350 |
TUBE Price: $4.57 |
| 174 |
650128 |
SCREW Price: $3.60 |
| 178 |
29752 |
NUT Price: $1.26 |
| 182 |
6201 |
SCREW Price: $1.26 |
| 184 |
26756 |
Gasket Price: $2.95 |
| 185 |
28416A |
INTAKE PIPE Price: $18.20 |
| 186 |
37735 |
LINK & LEVER This part replaces 31858. Price: $9.95 |
| 200 |
36677 |
CONTROL ASSY This part replaces 33879A. Price: $29.60 |
| 203 |
31342 |
COMP SPRING Price: $3.95 |
| 204 |
651029 |
SCREW This part replaces 650549. Price: $1.22 |
| 206 |
610973 |
TERMINAL Price: $2.60 |
| 210 |
27793 |
CLIP Price: $1.26 |
| 211 |
28942 |
SCREW Price: $0.88 |
| 223 |
650664 |
SCREW Price: $1.25 |
| 223A |
650840 |
SCREW Price: $1.25 |
| 224 |
26754A |
GASKET Price: $1.18 |
| 260 |
37600 |
BLOWER HSG This part replaces 35585. Price: $34.61 |
| 262 |
29716 |
SCREW This part replaces 29212. Price: $0.91 |
| 267 |
34212 |
BRACKET Price: $1.26 |
| 268 |
30200 |
SCREW Price: $3.25 |
| 285 |
34694 |
STARTER CUP Price: $7.97 |
| 287 |
650926 |
SCREW This part replaces 650884. Price: $0.88 |
| 290 |
30705 |
FUEL LINE Price: $11.47 |
| 292 |
26460 |
CLAMP Price: $1.19 |
| 298 |
650665 |
SCREW Price: $1.25 |
| 300 |
35584 |
FUEL TANK Price: $28.00 |
| 301 |
37845 |
FUEL CAP This part replaces 35355. Price: $6.33 |
| 313 |
34080 |
SPACER Price: $1.26 |
| 327 |
35392 |
STARTER PLUG Price: $1.22 |
| 340 |
36247 |
TANK BRACKET Price: $8.21 |
| 342 |
650751 |
SCREW Price: $1.25 |
| 345 |
33344 |
BAFFLE Price: $3.79 |
| 370 |
550223 |
DECAL--Discontinued Price: Call Us |
| 370A |
36261 |
DECAL This part replaces 34346. Price: Call Us |
| 380 |
631921 |
CARBURETOR Price: $88.97 |
| 390 |
590785 |
STARTER This part replaces 590642A. Price: $33.49 |
| 400 |
33233A |
GASKET SET Price: $17.95 |
