SWZ ELECTRICAL SCHEMATIC - RECOIL START
Parts (9)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 3219-3 | NUT-HEX Price: $0.34 |
| 2 | 3254-6 | WASHER-LOCK, INTERNAL Price: $0.31 |
| 3 | 5-1468-01 | PNEU. WHEEL HUB This part replaces 5-1468. Price: $101.29 |
| 4 | 3253-4 | WASHER-LOCK Price: $0.25 |
| 5 | 5-1470 | SCREW-HH Price: $0.61 |
| 6 | 3217-6 | NUT-HEX Price: $1.19 |
| 7 | 51-2560 | WHEEL DISC-HALF Price: $136.33 |
| 8 | 51-2550 | TIRE (18X4-12) SEMI-PNEUMATIC Price: $138.74 |
| 9 | 322-2 | SCREW-HH Price: $0.69 |
