| Ref | Part Number | Description |
|---|
| 1 |
32151-46 |
RING-RETAINING Price: $8.38 |
| 1 |
522710802 |
SHAFT.ASSY.BRAKE.WLDMT.BLACK Price: $199.00 |
| 2 |
25-2500 |
SHAFT-TRUNNION Price: $191.66 |
| 2 |
574216602 |
SHAFT, LIFT, BLACK Price: $139.99 |
| 3 |
25-2510 |
WASHER-FLAT Price: $2.41 |
| 3 |
510422902 |
Rods This part replaces 510422901. Price: $4.99 |
| 4 |
28-3300 |
BEARING-ROLLER Price: $137.87 |
| 4 |
583629301 |
ROD.LATCH.RELEASE This part replaces 516008801. Price: $4.99 |
| 5 |
252-82 |
BEARING-NEEDLE This part replaces 28-3310. Price: $51.31 |
| 5 |
510030702 |
Springs This part replaces 510030701. Price: $3.99 |
| 6 |
596482001 |
Springs This part replaces 539118762. Price: $6.99 |
| 6 |
92-5709 |
HOUSING-TRANSMISSION Price: $1,947.60 |
| 7 |
25-3210 |
SEAL-LIP Price: $23.14 |
| 7 |
510207201 |
GRIP, HANDLE, BLACK 4" Price: $5.99 |
| 8 |
28-3670 |
SHAFT-TRUNNION Price: $149.64 |
| 8 |
510207301 |
BUTTON, PUSH, BLACK Price: $4.99 |
| 9 |
587623001 |
LINK.ASM.RZ.LIFT.SERVICE This part replaces 525847201. Price: $9.99 |
| 9 |
93-4133 |
SEAL-LIP Price: $37.43 |
| 10 |
251-8 |
BEARING-BALL This part replaces 28-3650. Price: $30.06 |
| 10 |
587623001 |
LINK.ASM.RZ.LIFT.SERVICE This part replaces 522858601. Price: $9.99 |
| 11 |
3257-5 |
KEY-WOODRUFF Price: $5.13 |
| 11 |
531169201 |
SERVICE KIT ARM ARM.SUSPENSION This part replaces 532195185. Price: $12.99 |
| 12 |
28-3640 |
SHAFT-PUMP Price: $1,171.13 |
| 12 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 13 |
25-2450 |
PLATE-SWASH, VARIABLE This part replaces 49-7820. Price: $896.81 |
| 13 |
596273101 |
Pins This part replaces 539976989. Price: $2.99 |
| 14 |
32121-91 |
PIN-SPRING Price: $0.81 |
| 14 |
539105069 |
E-RING 5/8 Price: $2.99 |
| 15 |
25-2380 |
PLATE-THRUST Price: $32.89 |
| 15 |
589464902 |
NUT.LIFT LNK.7/16-2 This part replaces 532175994. Price: $3.99 |
| 16 |
48-1800 |
CYLINDER BLOCK KIT Price: $1,923.22 |
| 16 |
510184901 |
PLASTIC NUT Price: $4.99 |
| 17 |
46-7320 |
PLATE-VALVE, PUMP Price: $418.46 |
| 17 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 18 |
25-3300 |
BEARING-NEEDLE Price: $107.05 |
| 18 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 873800400. Price: $1.99 |
| 19 |
28-3590 |
O-RING Price: $4.60 |
| 19 |
596204201 |
Washers This part replaces 819091216. Price: $2.99 |
| 20 |
28-3580 |
RING-BACK UP Price: $20.88 |
| 21 |
28-3570 |
O-RING Price: $6.06 |
| 22 |
49-7830 |
CHECK VALVE KIT Price: $311.16 |
| 23 |
25-2460 |
PLUG-HH Price: $37.38 |
| 24 |
28-3400 |
O-RING Price: $6.67 |
| 25 |
25-2470 |
PACK-SHIM Price: $47.36 |
| 26 |
46-7310 |
SPRING Price: $18.78 |
| 27 |
83-7260 |
CONE-RELIEF, CHARGE This part replaces 28-3420. Price: $50.57 |
| 28 |
285-17 |
PLUG-PIPE Price: $2.59 |
| 29 |
323-8 |
SCREW-HH Price: $1.20 |
| 30 |
28-3530 |
CAPSCREW Price: $4.00 |
| 31 |
28-3520 |
O-RING Price: $8.44 |
| 32 |
38-2680 |
PIN Price: $23.93 |
| 33 |
28-3480 |
BEARING Price: $74.83 |
| 34 |
94-2975 |
SEAL-SHAFT Price: $24.63 |
| 35 |
92-1773 |
SCREW-HHF This part replaces 324-23. Price: $3.05 |
| 36 |
28-3450 |
WASHER Price: $0.25 |
| 37 |
117-6988 |
CHARGE PUMP KIT This part replaces 38-2670. Price: $1,753.04 |
| 39 |
92-5716 |
SECTION-CENTER Price: $2,472.04 |
| 40 |
125-5303 |
PLUG ASM This part replaces 92-5717. Price: $29.84 |
| 42 |
136-3219 |
PLUG ASM This part replaces 28-3440. Price: $21.54 |
| 43 |
323-10 |
SCREW-HH Price: $0.89 |
| 44 |
25-2480 |
SPRING-VALVE Price: $4.93 |
| 45 |
28-3380 |
PLATE-VALVE, MOTOR Price: $468.61 |
| 46 |
25-2430 |
PIN-DOWEL Price: $0.95 |
| 47 |
49-8200 |
SHAFT-MOTOR Price: $1,051.65 |
| 48 |
353-599 |
PIN-DOWEL This part replaces 28-3350. Price: $2.65 |
| 49 |
28-3340 |
GASKET Price: $16.81 |
