| Ref | Part Number | Description |
|---|
| 1 |
3230-3 |
SCREW-CARR Price: $0.53 |
| 1 |
532423502 |
CONTROL.TH/CK.COBRA.B&S.TWN.BK Price: $24.99 |
| 2 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 2 |
83-7470 |
SHIM Price: $8.86 |
| 3 |
83-4970-03 |
BRACKET-BEARING This part replaces 83-4970. Price: $95.44 |
| 4 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 4 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 5 |
581881101 |
EXHAUST.TUBE.LH.BS/TWIN This part replaces 532159955. Price: $27.99 |
| 5 |
76-2460 |
BEARING ASM Price: $67.16 |
| 6 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 6 |
581881001 |
EXHAUST.TUBE.RH.B&S.TWIN.INTEK This part replaces 532160589. Price: $22.99 |
| 7 |
54-9090 |
YOKE-END Price: $202.33 |
| 8 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 8 |
54-9180 |
U-JOINT KIT Price: $58.18 |
| 9 |
72-3420 |
YOKE AND SHAFT ASM Price: $278.13 |
| 10 |
302-58 |
FITTING-STRAIGHT Price: $0.81 |
| 10 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 11 |
83-5260 |
TUBE-YOKE, SLIP Price: $657.90 |
| 12 |
72-3440 |
SHAFT-YOKE Price: $743.98 |
| 13 |
253-155 |
SEAL-OIL Price: $14.36 |
| 13 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 14 |
71-4590 |
WASHER-THRUST Price: $3.32 |
| 15 |
76-4690-03 |
COUPLING-AXLE This part replaces 76-4690. Price: $318.79 |
| 16 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 17 |
3274-64 |
SCREW-HSH This part replaces 3274-8. Price: $1.02 |
| 17 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 18 |
32121-34 |
PIN-ROLL Price: $1.31 |
| 19 |
322-8 |
SCREW-HH Price: $1.26 |
| 20 |
284-3 |
PLUG Price: $7.14 |
| 21 |
32151-87 |
RING-RETAINING Price: $1.22 |
| 22 |
71-4580 |
BEARING Price: $80.51 |
| 23 |
532439870 |
SHIELD.BROWNING.PNT.GT.V2 This part replaces 532436086. Price: $14.99 |
| 23 |
71-4570-03 |
HOUSING-CLUTCH, ROLLER This part replaces 71-4570. Price: $367.36 |
| 24 |
3245-35 |
SCREW-SET, HSH Price: $0.41 |
| 25 |
251-77 |
COLLAR-LOCK, BEARING Price: $10.22 |
| 26 |
251-337 |
BEARING Price: $37.82 |
| 27 |
33114-025 |
SCREW-HH This part replaces 48-9460. Price: $0.70 |
| 28 |
3253-4 |
WASHER-LOCK This part replaces 42-9850. Price: $0.25 |
| 29 |
33094-00 |
WASHER-PLAIN This part replaces 48-8030. Price: $0.25 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
3274-34 |
SCREW-HSFH Price: $3.73 |
| 31 |
581290101 |
TANK.ASSEMBL.2.5GAL.NON-EPA This part replaces 532407489. Price: $99.99 |
| 31 |
83-4900 |
DISCONTINUED Price: Call Us |
| 32 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532430220. Price: $22.99 |
| 33 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 37 |
587044820 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532137040. Price: $9.99 |
| 44 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 45 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 46 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 72 |
596134202 |
Screws This part replaces 532183906. Price: $2.99 |
