| Ref | Part Number | Description |
|---|
| 1 |
04110-01 |
U-Nut 1/4-20 Price: Call Us |
| 2 |
48136-13 |
Hose Clamp, 0.69 dia. Price: Call Us |
| 3 |
04001-03 |
Bolt, Hex Head 1/4-20 x 2.0" Price: Call Us |
| 5 |
48136-07 |
Clamp, Hose 1/2" Price: Call Us |
| 6 |
481301-03 |
Elbow, 90 Degree - 1/4 NPT x 3/8 Hose Price: Call Us |
| 7 |
482266-01 |
Elbow, 90 Degree - 9/16 O-ring x 3/8 Hose Price: Call Us |
| 8 |
48471-02 |
Oil Filter Base Price: Call Us |
| 9 |
482606 |
Hose Assembly, 1/2" ID (Tank to Filter Base) Price: Call Us |
| 13 |
481308 |
Valve, Shutoff Kawasaki Price: Call Us |
| 14 |
48059-01 |
Clamp, Fuel Hose Price: Call Us |
| 16 |
481602 |
Hose Fitting Price: Call Us |
| 17 |
482571 |
Bushing This part replaces 48309. Price: Call Us |
| 18 |
04001-09 |
Bolt, Hex Head 5/16-18 x1.0" Zinc Price: Call Us |
| 19 |
04019-03 |
Nut, Serrated Flange 5/16-18 Price: Call Us |
| 20 |
48758 |
Oil Filter Price: Call Us |
| 21 |
482483 |
Tee, 3/4 O-ring x JIC x 1/2" Hose Price: Call Us |
| 22 |
04021-08 |
Nut, Hex Elastic Stop 1/4-20 Price: Call Us |
| 23 |
481164 |
Cap, Hydraulic Tank Price: Call Us |
| 24 |
481507 |
Insert, Filler Neck Price: Call Us |
| 25 |
48603-02 |
O-Ring Price: Call Us |
| 27 |
482572 |
Elbow, 90 Degree .38 Hose Price: Call Us |
| 28 |
48136-13 |
Hose Clamp, 0.69 dia. Price: Call Us |
| 30 |
04010-10 |
Screw, Phillips Head, 1/4-20 Price: Call Us |
| 31 |
48571-02 |
Cap Price: Call Us |
| 33 |
48136-05A |
Clamp, Hose Price: Call Us |
| 34 |
48350-02 |
Elbow, 90 Degree, 7/8-14 THD Price: Call Us |
| 35 |
48938-02 |
Bushing, 7/8-14 JIC x 3/4-16 O-Ring Price: Call Us |
| 36 |
423701 |
Support Bracket, Fuel Tank Price: Call Us |
| 37 |
04019-03 |
Nut, 5/16-18 Serrated Flange Price: Call Us |
| 38 |
04003-02 |
Bolt, Carraige 1/4-20 x 3/4" Price: Call Us |
| 39 |
482574 |
Elbow, 90 Degree Price: Call Us |
| 40 |
423513 |
Strap, Hydraulic Tank Price: Call Us |
| 41 |
423485 |
Support Bracket, Hydraulic Tank Price: Call Us |
| 42 |
484459 |
Hose Assembly, Pump This part replaces 481611. Price: Call Us |
| 43 |
48572-04 |
Union, 3/4-16 JIC x 3/4-16 O-ring Price: Call Us |
| 44 |
04001-59 |
Bolt, Hex Head, 1/4-20 x 1-14" Price: Call Us |
| 45 |
04030-02 |
Lockwasher, 1/4" Spring Price: Call Us |
| 46 |
04060-09 |
Roll Pin, Spring 3/16 x 3/4" Price: Call Us |
| 47 |
04017-05 |
Bolt, Hex Serrated Flange, 1/4-20 x 3/4" Price: Call Us |
| 48 |
48136-13 |
Clamp, .69 Dia. Price: Call Us |
| 49 |
422694 |
Clamp Plate, Pump Control Price: Call Us |
| 50 |
481793 |
Block, Pump Control Price: Call Us |
| 51 |
482695 |
Pump, Left Hand, BDP-16A-410 Price: Call Us |
| 52 |
04021-09 |
Nut, Hex, Elastic Stop 3/8-16 Price: Call Us |
| 53 |
04001-32 |
Bolt, Hex Head 3/8-16 x 1-1/4", Kawasaki FX / FT & FT-EFI Price: Call Us |
| 54 |
482696 |
Pump, Right Hand, BDP 16A-307 Price: Call Us |
| 55 |
483788 |
FUEL CAP W/GAUGE This part replaces 482497. Price: Call Us |
| 56 |
04021-09 |
Nut, Hex Elastic Stop 3/8-16 Price: Call Us |
| 57 |
04043-04 |
Flatwasher, 3/8" (.391 x .938 x .105) Grade 8 Price: Call Us |
| 58 |
424884 |
Mounting Bracket - LH, Oil Cooler This part replaces 423524. Price: Call Us |
| 59 |
04001-08 |
Bolt, Hex Head 5/16-18 x 3/4" Price: Call Us |
| 424885 |
Mounting |
Bracket - RH, Oil Cooler This part replaces 423525. Price: Call Us 424885 |
| 481753 |
Valve, |
Shutoff Kohler Price: Call Us 481753 |
| 483100 |
Pump, |
Right Hand, BDP-16A (31BV) Price: Call Us 483100 |
| 483101 |
Pump, |
Left Hand, BDP-16A (31BV) Price: Call Us 483101 |
