| Ref | Part Number | Description |
|---|
| 1 |
2412-133 |
CLAMP-R Price: $3.19 |
| 1 |
532414280 |
KNOB LEVER, BLACK This part replaces 532183334. Price: $6.99 |
| 2 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 2 |
817501010 |
SCREW #10-24 X 5/8 Price: $4.99 |
| 3 |
322-2 |
SCREW-HH Price: $0.69 |
| 3 |
587030801 |
CONTROL.ASM.DEFLEC.BLK.BOWDEN This part replaces 532198475. Price: $54.99 |
| 4 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 4 |
74-0720 |
TUBE-MANUAL Price: $22.99 |
| 5 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 5 |
85-9660-03 |
PLATE-ADJUSTMENT, SEAT This part replaces 85-9660. Price: $74.11 |
| 6 |
3258-166 |
SCREW-PRH Price: $0.28 |
| 6 |
532428272 |
LEVER/CABLE.ASM.ROTATOR This part replaces 532404974. Price: $129.99 |
| 7 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 7 |
532443617 |
SUPPORT.WELDMENT.ROTATOR.BLACK This part replaces 532407643. Price: $24.99 |
| 8 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 532150078. Price: $4.99 |
| 8 |
98-0977 |
DECAL-SERVICE Price: $53.97 |
| 9 |
532184505 |
SPRING.DEFLECTOR.REM.CHUTE Price: $6.99 |
| 10 |
532179829 |
BOLT, SHOULDER Price: $4.99 |
| 11 |
532179246 |
WASHER, NYLON FRICTION Price: $3.99 |
| 11 |
98-0979 |
LYNCH PIN ASM Price: $20.82 |
| 12 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 12 |
532191730 |
NUT.HEX.FLANGE.1/4 Price: $3.99 |
| 13 |
596136401 |
Bolts This part replaces 872250505. Price: $2.99 |
| 14 |
532751153 |
NUT.LOCK.5/16-18 Price: $2.99 |
| 15 |
590518207 |
DEFLECTOR ASSEMBLY RIVETED This part replaces 532407655. Price: $17.99 |
| 16 |
51-0780 |
SLIDER-SEAT Price: $116.02 |
| 16 |
590518207 |
DEFLECTOR ASSEMBLY RIVETED This part replaces 532184113. Price: $17.99 |
| 17 |
32141-36 |
SCREW-ADJUSTMENT, LEVEL Price: $12.75 |
| 17 |
532420325 |
SEAL.DEFLECTOR This part replaces 532179145. Price: $5.99 |
| 18 |
3218-2 |
NUT-JAM Price: $0.25 |
| 18 |
532128415 |
RIVET BLIND Price: $3.99 |
| 19 |
51-0790 |
ADJUSTER-SEAT, LH Price: $127.92 |
| 19 |
532183333 |
RP KNOB, SPEED CONTROL LEVER Price: $8.99 |
| 20 |
63-8410 |
WASHER Price: $1.76 |
| 20 |
872110506 |
BOLT.CARR.SQNK.5/16-18UNC.X3/4 This part replaces 872270506. Price: $3.99 |
| 21 |
117-2453 |
SEAT KIT This part replaces 92-8976. Price: $303.45 |
| 22 |
874041024 |
SCREW Price: $2.99 |
| 23 |
532421249 |
CABLE.TRIGGER.CONTROL.ASM This part replaces 532192449. Price: $19.99 |
| 25 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 25 |
596039201 |
GSPW Hardware This part replaces 532198541. Price: $2.99 |
| 26 |
532429667 |
KIT.CONTROL.SPEED.SELECTOR.SNO This part replaces 532198474. Price: $74.99 |
| 27 |
532169675 |
SPRING RETAINER Price: $4.99 |
| 28 |
532180445 |
ROD, UPPER SPEED CONTROL Price: $34.99 |
| 29 |
532187716 |
ROD, LOWER SPEED CONTROL.SNOW Price: $17.99 |
| 30 |
532192710 |
CLAMP.ASM.CLEANOUT.TOOL.SNOW Price: $8.99 |
| 32 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
