| Ref | Part Number | Description |
|---|
| 2 |
427561 |
Guard, Muffler Price: Call Us |
| 3 |
04117-01 |
Nut, Flange Head Elastic Stop 5/16-18 Price: Call Us |
| 5 |
04021-09 |
HEX NUT, ELASTIC STOP LOCK, 3/8-16 Price: Call Us |
| 6 |
04019-03 |
Nut, Serrated Flange 5/16-18 (Right Front Engine Mounting, Briggs and Kohler Only) Price: Call Us |
| 8 |
452726 |
Plate Weldment, Engine Mounting Price: Call Us |
| 9 |
04001-19 |
Bolt, Hex Head, 3/8-16 x 1 Gr. 5 Price: Call Us |
| 10 |
04030-04 |
Lockwasher, 3/8” Spring, Kawasaki FX / FT & FT-EFI / B&S 32BV Price: Call Us |
| 11 |
04001-21 |
Bolt, Hex Head 3/8-16 x 1-3/4" (Kohler EFI) Price: Call Us |
| 12 |
04003-12 |
Bolt, 5/16-18 x .75 RHSN Carriage Price: Call Us |
| 13 |
04117-02 |
Nut, Flange Elastic Stop Nut, 3/8-16 Price: Call Us |
| 14 |
427071 |
Cover, Rear Price: Call Us |
| 15 |
04001-32 |
Bolt, Hex Head 3/8-16 x 1-1/4", Kawasaki FX / FT & FT-EFI Price: Call Us |
| 16 |
04041-07 |
Flatwasher, 3/8" Special (.391 x .938 x .105) Price: Call Us |
| 17 |
427909 |
Bracket, Air Cleaner Mount Price: Call Us |
| 18 |
48136-25 |
Clamp, 2-3/4" Max. Dia. Price: Call Us |
| 19 |
04017-17 |
Cpscrw, 5/16-18 x 1"Serrated Flange Hex Head Price: Call Us |
| 20 |
04019-03 |
Nut, Serrated Flange 5/16-18 (Right Front Engine Mounting, Briggs and Kohler Only) Price: Call Us |
| 22 |
486043 |
Hose, Air Intake Price: Call Us |
