| Ref | Part Number | Description |
|---|
| 1 |
104-4620 |
SEAT This part replaces 92-1180. Price: $273.15 |
| 1 |
539102587 |
GROMMET, BUMPER Price: $4.99 |
| 2 |
579411601 |
BATTERY, 12 V 300 AMP DRY This part replaces 539102436. Price: $129.99 |
| 3 |
539105728 |
BATTERY HOLD DOWN Price: $27.99 |
| 3 |
75-4370-03 |
BRACKET-SEAT This part replaces 75-4370. Price: $20.93 |
| 4 |
3296-54 |
NUT-LOCK Price: $3.59 |
| 4 |
539104974 |
POST.CABLE LONG Price: $27.99 |
| 5 |
539102758 |
CABLE-NEGATIVE Price: $12.99 |
| 5 |
92-8753 |
DISCONTINUED Price: Call Us |
| 6 |
539102759 |
INSULATOR Price: $3.99 |
| 6 |
92-8001 |
SENSOR-SWITCH, REED Price: $86.02 |
| 7 |
3250-29 |
SCREW-PPH Price: $0.25 |
| 7 |
539101080 |
SWITCH, INTERLOCK Price: $14.99 |
| 8 |
539102678 |
TAPPED PLATE Price: $12.99 |
| 8 |
75-4360-03 |
BRACKET-SUSPENSION, SEAT This part replaces 75-4360. Price: $17.81 |
| 9 |
596039001 |
Screws This part replaces 539976952. Price: $2.99 |
| 10 |
532175566 |
IGNITION SWITCH This part replaces 539107541. Price: $22.99 |
| 10 |
74-0720 |
TUBE-MANUAL Price: $22.99 |
| 11 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 11 |
597520401 |
Service Kit This part replaces 539131627. Price: $54.99 |
| 12 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 12 |
576179401 |
HOUR METER This part replaces 539110074. Price: $27.99 |
| 13 |
322-3 |
SCREW-HH Price: $0.79 |
| 13 |
539110950 |
FRAME HARNESS Price: $279.99 |
| 14 |
596040801 |
Hardware This part replaces 539976977. Price: $2.99 |
| 14 |
75-3400 |
SHAFT-PIVOT, SEAT Price: $21.81 |
| 15 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 539976934. Price: $3.99 |
| 15 |
93-0141 |
Seat Plate Assembly (Incl. Ref. #41) Price: Call Us |
| 16 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 16 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
| 17 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 17 |
539102617 |
SCREW, #1--24 X 1/2 SLOTTED Price: $2.99 |
| 18 |
596584001 |
Screws This part replaces 539991034. Price: $2.99 |
| 18 |
75-3680-03 |
ROD-SEAT This part replaces 75-3680. Price: $38.90 |
| 19 |
32121-38 |
PIN-ROLL Price: $0.53 |
| 19 |
539105169 |
KNOB Price: $7.99 |
| 20 |
539102914 |
RELAY Price: $21.99 |
| 20 |
75-1350 |
THROTTLE CABLE Price: $15.76 |
| 21 |
539101771 |
FUSE, 7.5 AMP 32 VOLT ATO Price: $3.99 |
| 27 |
75-3300 |
DISCONTINUED Price: Call Us |
| 28 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 29 |
63-6760 |
FITTING-CONNECTOR Price: $61.52 |
| 30 |
3-6657 |
CLIP-SKID Price: $22.64 |
| 31 |
66-2920 |
WASHER-FRICTION Price: $2.58 |
| 32 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 34 |
75-3430-03 |
LEVER-THROTTLE This part replaces 75-3430. Price: $29.18 |
| 35 |
233-42 |
KNOB Price: $12.88 |
| 36 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 37 |
75-5270 |
SPACER-KNOB, SEAT Price: $4.61 |
| 38 |
75-5260 |
DISCONTINUED Price: Call Us |
| 39 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 41 |
93-0140 |
GROMMET-RUBBER Price: $3.94 |
| 42 |
2412-133 |
CLAMP-R Price: $3.19 |
| 46 |
321-4 |
SCREW-HH Price: $0.99 |
| 47 |
323-4 |
SCREW-HH Price: $1.02 |
| 50 |
2412-93 |
CLAMP-R Price: $1.02 |
| 51 |
5-0838 |
WASHER Price: $1.09 |
