| Ref | Part Number | Description |
|---|
| 1 |
233-39 |
KNOB-CONTROL Price: $16.12 |
| 2 |
583110501 |
SPACER.GEARCASE This part replaces 532181362. Price: $4.99 |
| 2 |
74-3190 |
LEVER-LIFT Price: $102.52 |
| 3 |
583066801 |
GEAR.REVERSE This part replaces 532175035. Price: $19.99 |
| 4 |
532105345 |
GEAR TI Price: $54.99 |
| 5 |
585695501 |
NEEDLE BEARING This part replaces 532100413. Price: $7.99 |
| 5 |
60-5690 |
CLIP Price: $3.58 |
| 6 |
532144564 |
SPROCKET ASMBLY, TINE Price: $59.99 |
| 6 |
58-1520 |
PIN Price: $12.55 |
| 7 |
42-9310 |
BOLT Price: $1.29 |
| 8 |
33114-060 |
SCREW-HH This part replaces 42-9510. Price: $0.88 |
| 8 |
532004358 |
WASHER Price: $3.99 |
| 9 |
63-4800 |
MOTOR-SPOOL, VALVE Price: $2,291.65 |
| 10 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 10 |
532008371 |
CHAIN.ROLLER.TILLER Price: $54.99 |
| 11 |
237-21 |
O-RING Price: $0.70 |
| 11 |
532100371 |
SPRING-SHIFT CRT Price: $4.99 |
| 12 |
532100482 |
KIT.STEEL BALL(12 BALLS) This part replaces 532124697. Price: $4.99 |
| 12 |
58-7190 |
SPRING Price: $19.74 |
| 13 |
33094-00 |
WASHER-PLAIN This part replaces 48-8030. Price: $0.25 |
| 13 |
532008353 |
SHIFT FORK TI Price: $22.99 |
| 14 |
3253-4 |
WASHER-LOCK This part replaces 48-9570. Price: $0.25 |
| 14 |
583068601 |
SHAFT.SHFIT This part replaces 532175372. Price: $5.99 |
| 15 |
14-5679 |
VALVE KIT - SERVICE This part replaces 58-5470. Price: $2,889.00 |
| 15 |
812000039 |
KLIP RING Price: $4.99 |
| 16 |
532154467 |
WASHER, SEAL (2 2) Price: $3.99 |
| 16 |
58-3830 |
PIN-CLEVIS Price: $1.84 |
| 17 |
33093-00 |
WASHER-FLAT This part replaces 48-8010. Price: $0.70 |
| 17 |
532001370 |
THRUST WASHER Price: $4.99 |
| 18 |
532004895 |
BEARING This part replaces 532124792. Price: $9.99 |
| 18 |
58-4450 |
LEVER Price: $81.85 |
| 19 |
233-10 |
KNOB-LEVER Price: $47.39 |
| 19 |
532150695 |
SHAFT INPUT Price: $54.99 |
| 20 |
58-4460 |
CLEVIS Price: $112.62 |
| 21 |
532432060 |
KIT.TINE.SHAFT.8HP.SERVICE This part replaces 532431519. Price: $99.99 |
| 21 |
58-1570 |
LINK Price: $15.74 |
| 22 |
3272-1 |
PIN-COTTER This part replaces 58-1480. Price: $0.25 |
| 22 |
532106181 |
SPACER 1.008X1-3/4X.645 Price: $12.99 |
| 23 |
586196401 |
GEAR.PINION.INPUT This part replaces 532175031. Price: $39.99 |
| 23 |
60-0550 |
BUSHING Price: $16.69 |
| 24 |
532005020 |
NEEDLE BRNG LT Price: $14.99 |
| 24 |
68-9400 |
NUT-FLANGE This part replaces 48-7930. Price: $2.29 |
| 25 |
33095-00 |
WASHER-FLAT This part replaces 48-9580. Price: $0.25 |
| 25 |
532431023 |
GASKET.GEARCASE.8HP Price: $22.99 |
| 26 |
32121-118 |
PIN-ROLL Price: $0.36 |
| 26 |
532106389 |
SPACER Price: $6.99 |
| 27 |
237-78 |
O-RING Price: $3.85 |
| 27 |
532100433 |
GEAR, CLUSTER CRT Price: $49.99 |
| 28 |
532008357 |
REVERSE GEAR Price: $29.99 |
| 28 |
58-5520 |
VALVE-RELIEF, ADJUSTABLE Price: $410.76 |
| 29 |
48-9430 |
DISCONTINUED Price: Call Us |
| 30 |
237-22 |
O-RING Price: $2.43 |
| 30 |
532006803 |
NEEDLE BEARING TI Price: $7.99 |
| 31 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 31 |
812000040 |
KLIP RING Price: $4.99 |
| 32 |
237-42 |
O-RING Price: $2.78 |
| 32 |
532008356 |
SHAFT, REVERSE IDLER Price: $17.99 |
| 33 |
59-7130 |
KNOB-CONTROL, SPEED Price: $25.40 |
| 34 |
532106392 |
SPACER.765 X 1.12 X .380. Price: $12.99 |
| 34 |
58-1510 |
SHAFT Price: $74.91 |
| 35 |
532106394 |
SPACER, GROUND DRIVE RH Price: $27.99 |
| 35 |
59-7910 |
GROMMET Price: $2.07 |
| 36 |
532100436 |
SHAFT ASSY CRT Price: $119.99 |
| 36 |
60-2110 |
PIN Price: $1.42 |
| 37 |
340-64 |
O-RING Price: $4.22 |
| 37 |
532142145 |
BRACKET ASM.SHIFT.CRT Price: $17.99 |
| 38 |
340-80 |
FITTING-STR Price: $47.82 |
| 38 |
532106393 |
SPACER, GROUND DRIVE Price: $17.99 |
| 39 |
237-101 |
O-RING This part replaces 237-123. Price: $2.80 |
| 40 |
58-2150 |
BLOCK-MANIFOLD Price: $325.81 |
| 41 |
532155236 |
SEAL ASM, OIL Price: $5.99 |
| 41 |
66-5410 |
ORIFICE (.109) Price: $24.26 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 43 |
237-80 |
O-RING Price: $6.10 |
| 43 |
873610700 |
NUT.ASF.HEX.7/16 Price: $5.99 |
| 44 |
340-7 |
FITTING-STRAIGHT Price: $14.00 |
| 45 |
237-65 |
O-RING Price: $2.50 |
| 45 |
817000510 |
BOLT.5/16HEX.WHS.HD Price: $4.99 |
| 46 |
43-5930 |
WASHER-LOCK, SPRING Price: $0.75 |
| 47 |
33113-016 |
SCREW-HH This part replaces 48-7620. Price: $0.34 |
| 47 |
596436301 |
Nuts This part replaces 873220500. Price: $2.99 |
| 48 |
340-17 |
FITTING-ELBOW, 90 DEG Price: $42.29 |
| 48 |
532100107 |
SCREW 5/16-18X4 Price: $3.99 |
| 49 |
532106391 |
SPACER Price: $7.99 |
| 49 |
58-3810 |
PIN-CLEVIS Price: $6.22 |
| 50 |
58-1560 |
LINK Price: $7.20 |
| 51 |
48-7890 |
NUT-HEX Price: $0.25 |
| 52 |
340-86 |
FITTING-TEE Price: $35.23 |
| 53 |
58-1530 |
COUPLING Price: $3.35 |
| 54 |
52-6430 |
WASHER Price: $0.25 |
| 55 |
66-5860 |
FITTING-ELBOW, 45 DEG Price: $92.86 |
| 56 |
58-5490 |
VALVE-CONTROL, FLOW Price: $1,092.55 |
| 56 |
58-5491 |
DISCONTINUED Price: Call Us |
| 57 |
340-3 |
FITTING-STRAIGHT Price: $10.42 |
| 58 |
237-79 |
O-RING Price: $5.46 |
| 59 |
58-1540 |
SPACER-NYLON Price: $11.85 |
| 60 |
33113-050 |
SCREW-HH This part replaces 60-6650. Price: $0.62 |
| 60 |
532183226 |
FITTING.GREASE.TAPERED Price: $4.99 |
| 61 |
237-42 |
O-RING Price: $2.78 |
| 61 |
583470401 |
SPACER.1.015 X 1.50 X .765 This part replaces 532431501. Price: $4.99 |
| 62 |
59-7410 |
FITTING-DIAGNOSTIC Price: $36.39 |
| 63 |
353-947 |
CAP-DUST, RUBBER Price: $7.73 |
| 64 |
321-3 |
SCREW-HH Price: $0.28 |
| 65 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 66 |
3217-5 |
NUT-HEX Price: $0.25 |
| 67 |
63-4690-03 |
BRACKET-VALVE This part replaces 63-4690. Price: $23.58 |
| 68 |
3296-8 |
NUT-HEX Price: $1.29 |
| 69 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 70 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 71 |
321-10 |
SCREW-HH Price: $1.29 |
| 72 |
63-4700 |
VALVE-FLOW, REGULATOR Price: $295.76 |
| 72 |
63-4701 |
DISCONTINUED Price: Call Us |
| 73 |
3245-44 |
SCREW-SET Price: $2.57 |
| 74 |
74-3170 |
LINK Price: $95.07 |
| 75 |
3245-45 |
SET SCREW 5/16-18 X 1 Price: $6.04 |
| 532183655 |
TRANS.SERVICE.21.CRT |
This part replaces 532181337. Price: $749.99 532183655 |
