| Ref | Part Number | Description |
|---|
| 1 |
712-05134 |
FLANGE NUT 5/8-18 Price: $5.52 |
| 1 |
719-07293-M |
DECK SPINDLE HOUSING (W/O FTG) This part replaces 619-04183B. Price: $39.28 |
| 1 |
738-1186A |
BLADE SPINDLE SHAFT STAR 6.11 LG Price: $45.83 |
| 1 |
741P0919B |
BALL BEARING This part replaces 941-0919B. Price: $18.90 |
| 1 |
750-04936 |
SPACER- .792 x 1.060 x 1.860 Price: $5.94 |
| 1 |
750-06153 |
SPACER .792 x 1.060 x 1.191 Price: $3.68 |
| 1 |
750-06365 |
SPACER Price: $5.52 |
| 1 |
783-08435 |
SHIELD-BRG DECK Price: $6.28 |
| 1 |
918-07146 |
SPINDLE ASM 4.6" DIA This part replaces 618-07146. Price: $111.49 |
| 2 |
728-0175 |
RIVOT Price: $4.04 |
| 2 |
753-09904A |
DECK BRAKE ASSEMBLY KIT This part replaces 983-05183. Price: $93.12 |
| 2 |
761-05007 |
DECK BRAKE PAD Price: $9.20 |
| 3 |
710-0353 |
WELD BOLT 5/16-18 x .875 Price: $3.50 |
| 3 |
710-1009 |
SCREW 5/16-18 x 1.5 Price: Call Us |
| 4 |
728-0175 |
RIVOT Price: $4.04 |
| 4 |
761-05007 |
DECK BRAKE PAD Price: $9.20 |
| 4 |
987-05169 |
IDLER PIVOT ASSEMBLY BRACKET This part replaces 687-05169. Price: $40.16 |
| 5 |
710-0347 |
HEX SCREW 3/8-16 x 1.75 GR5 Price: $4.39 |
| 6 |
710-0376 |
SCREW 5/16-18 x 1.0 GR5 Price: $3.66 |
| 7 |
710-0521 |
SCREW 3/8-16 x 3 GR8 Price: $4.54 |
| 8 |
710-06133 |
SCREW M6-1 x .625 Price: $3.08 |
| 10 |
710-1260A |
SCREW 5/16-18 x .750 Price: $3.34 |
| 11 |
712-04063 |
FLANGE LOCK NUT 5/16-18 Price: $3.56 |
| 12 |
712-0417A |
HEX NUT Price: $6.50 |
| 13 |
712-04217 |
FLANGE LOCK NUT Price: $3.75 |
| 14 |
714-04043 |
PIN:COTTER Price: $4.24 |
| 15 |
720-05010 |
VINYL CAP Price: $3.70 |
| 16 |
921-04041 |
WATER NOZZLE Price: $20.19 |
| 17 |
731-07487 |
DECK WASH NOZZLE Price: $3.86 |
| 19 |
732-04280B |
EXTENSION SPRING Price: $7.18 |
| 20 |
732-05151A |
TORSION SPRING Price: $3.70 |
| 21 |
736-3040 |
HUB CAP WASHER .406 x 1.92 x .060 Price: $5.52 |
| 22 |
736-3078 |
FLAT WASHER 344X1.00 Price: $3.95 |
| 23 |
738-04502 |
SHOULDER SCREW 1/4-20 x .50 Price: $3.75 |
| 24 |
738-05088 |
SHOULDER SPACER .750 x .145 Price: $3.86 |
| 25 |
738-05099 |
SHOULDER SPACER Price: $6.47 |
| 27 |
747-06506 |
ROD HOOK Price: $5.52 |
| 28 |
747-06583 |
DECK BRAKE ROD Price: $12.76 |
| 29 |
747-06626 |
ENGINE PULLEY BELT KEEPER ROD Price: $7.30 |
| 30 |
748-05029A |
SHOULDER SPACER Price: $4.19 |
| 31 |
750-06031 |
SPACER Price: $4.69 |
| 33 |
756-05034A |
IDLER PULLEY 4.50" DIA This part replaces 756-05034. Price: $40.14 |
| 34 |
783-08389 |
IDLER PULLEY CAP Price: $5.23 |
| 35 |
783-08690A-0637 |
BELT KEEPER (POWDER BLACK) This part replaces 783-08690-0637. Price: $11.37 |
| 36 |
787-03537 |
BELT COVER Price: $22.15 |
