| Ref | Part Number | Description |
|---|
| 1 |
100-6571 |
HOOD ASM This part replaces 84-7740. Price: $1,342.17 |
| 1 |
583486301 |
DECK SVCX 97 W/GWB 429121 This part replaces 532429121. Price: $279.99 |
| 2 |
65-5100 |
HANDLE-DOOR Price: $9.05 |
| 3 |
532431864 |
BRACKET.ASM.BAR.SWAY.CHASS Price: $19.99 |
| 3 |
63-7030-03 |
SCREEN-HOOD REAR This part replaces 63-7030. Price: $141.98 |
| 4 |
321-39 |
SCREW-HH Price: $0.42 |
| 5 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 5 |
71-3390 |
DISCONTINUED Price: Call Us |
| 6 |
32128-33 |
NUT-HF Price: $0.25 |
| 6 |
532165557 |
BAR.SWAY.92.CRD Price: $6.99 |
| 7 |
66-8680 |
DISCONTINUED Price: Call Us |
| 8 |
583116901 |
BOLT.3/8-24X1.25 GR8 This part replaces 532181712. Price: $5.99 |
| 8 |
66-8110 |
TRIM-HOOD Price: $4.91 |
| 9 |
3290-359 |
SCREW-HWH Price: $6.23 |
| 9 |
596238701 |
Washers This part replaces 810030600. Price: $3.99 |
| 10 |
532140296 |
WASHER.BLADE Price: $5.99 |
| 10 |
63-6900-01 |
LH HOOD HINGE PLATE ASM This part replaces 63-6900. Price: $23.15 |
| 11 |
532427984 |
BLADE.3N1.LH.CRD.97 Price: $49.99 |
| 11 |
76-4790 |
PAD-RUBBER Price: $17.89 |
| 12 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 13 |
3274-32 |
SCREW-HSBH Price: $4.79 |
| 13 |
532137646 |
KIT MANDREL W/NUT This part replaces 532137645. Price: $29.99 |
| 14 |
532128774 |
HOUSING.MANDREL.VENTED (MACHD) Price: $29.99 |
| 14 |
66-3040-03 |
COVER-BOX, TOOL This part replaces 66-3040. Price: $26.24 |
| 15 |
532110485 |
BEARING Price: $11.99 |
| 15 |
66-3050 |
DISCONTINUED Price: Call Us |
| 16 |
27-7310 |
DECAL-REFUELING Price: $27.52 |
| 16 |
532427985 |
BLADE.3N1.RH.CRD.97 Price: $49.99 |
| 17 |
595901101 |
Bolts This part replaces 872140610. Price: $3.99 |
| 17 |
66-8880 |
DECAL - CAUTION (INSTR) Price: $23.35 |
| 18 |
71-3520 |
DISCONTINUED Price: Call Us |
| 19 |
532132827 |
BOLT SHD 5/16-18 Price: $4.99 |
| 19 |
66-2830 |
DISCONTINUED Price: Call Us |
| 20 |
583117001 |
BOLT.3/8-24X1.25GR8. LHTHRD This part replaces 532181713. Price: $3.99 |
| 20 |
63-7310 |
DISCONTINUED Price: Call Us |
| 21 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 22 |
532431169 |
BRACKET.SUPT.IDLER.REAR.RH Price: $5.99 |
| 24 |
3234-13 |
SCREW-HHF Price: $0.77 |
| 25 |
32128-20 |
NUT-HF Price: $0.99 |
| 26 |
46-6810 |
SCREW AND WASHER ASM Price: $3.49 |
| 27 |
532427981 |
BRACKET.ASM.SUSP.REAR.RH. Price: $22.99 |
| 27 |
93-7830 |
DECAL-TORQUE This part replaces 67-1720. Price: $23.91 |
| 28 |
3230-23 |
SCREW-CARR Price: $0.89 |
| 29 |
66-3200 |
TREAD-FOOTREST, LH Price: $7.38 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 30 |
66-3210 |
TREAD-FOOTREST, LH Price: $30.94 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 31 |
92-5540 |
TREAD-FOOTREST, RH This part replaces 66-3220. Price: $23.53 |
| 32 |
532173435 |
MANDREL.PULLEY.38.BRIGHT.ZINC This part replaces 532153532. Price: $19.99 |
| 32 |
63-7320 |
DISCONTINUED Price: Call Us |
| 33 |
596134801 |
Nuts This part replaces 532400234. Price: $1.00 |
| 33 |
66-8760 |
DISCONTINUED Price: Call Us |
| 33 |
66-8770 |
DECAL-TOWER, RH Price: $40.20 |
| 34 |
53-4430 |
DECAL-OIL Price: $8.99 |
| 35 |
84-7700 |
FRAME ASM - GM 223D Price: $1,882.51 |
| 36 |
593787801 |
PULLEYS This part replaces 532146763. Price: $27.99 |
| 36 |
63-7330 |
DISCONTINUED Price: Call Us |
| 37 |
62-5550 |
DECAL Price: $9.32 |
| 38 |
66-8890 |
DISCONTINUED Price: Call Us |
| 39 |
63-7300 |
DISCONTINUED Price: Call Us |
| 40 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 40 |
63-8050 |
BOX-CONTROL Price: $106.29 |
| 41 |
106-8095 |
DECAL-TOWER This part replaces 66-2470. Price: $48.49 |
| 41 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 42 |
63-6890-01 |
RH HOOD HINGE PLATE ASM This part replaces 63-6890. Price: $12.36 |
| 43 |
46-8091 |
SCREW-HWH Price: $3.59 |
| 44 |
283-58 |
PIN-CLEVIS Price: $3.87 |
| 44 |
532431170 |
OVER.MANDREL.LH.CRD Price: $17.99 |
| 45 |
66-2870 |
CABLE-HOOD STOP Price: $27.51 |
| 46 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 47 |
59-9740 |
FLEX DRAW LATCH ASM Price: $36.89 |
| 48 |
3290-271 |
RIVET-POP Price: $0.25 |
| 49 |
3296-12 |
NUT-LOCK, NI Price: $1.29 |
| 50 |
75-0810 |
CAUTION DECAL Price: $15.36 |
| 55 |
583252901 |
ARM.IDLER.92.CRD./2006 This part replaces 532199498. Price: $22.99 |
| 56 |
532165723 |
SPACER.RETAINER.MOWER Price: $5.99 |
| 61 |
583252601 |
SPRING.TENSION.92.CRD.2006 This part replaces 532199486. Price: $8.99 |
| 67 |
532106932 |
KNOB T (3/8 HOLE) Price: $6.99 |
| 68 |
584454401 |
BELT.DRIVE.CRD.97.2010 This part replaces 532429532. Price: $99.99 |
| 69 |
532165482 |
SHAFT.ASM.W/LWR.BRG.RH.THREAD Price: $59.99 |
| 80 |
532423062 |
PALNUT 1/4 Price: $2.99 |
| 84 |
597024901 |
Keepers This part replaces 532156085. Price: $3.99 |
| 116 |
596434404 |
Bolts This part replaces 532193406. Price: $4.99 |
| 117 |
589527301 |
WHEEL.GAUGE.RALLY This part replaces 532174873. Price: $8.99 |
| 119 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 131 |
532165661 |
CHUTE BAGGER Price: $79.99 |
| 152 |
532176074 |
Price: Call Us |
| 158 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 185 |
532188234 |
HEAD ASM. CABLE CLUTCH Price: $34.99 |
| 260 |
817670608 |
SCREW 3/8-16X1/2 Price: $3.99 |
| 298 |
599972501 |
BOLT This part replaces 817490628. Price: $2.99 |
