| Ref | Part Number | Description |
|---|
| 1 |
139-2564 |
NUT-LUG This part replaces 242-50. Price: $0.99 |
| 1 |
532401043 |
SEAT.XG150.BLK.KB/SLD.NO-LOGO This part replaces 532184995. Price: $219.99 |
| 2 |
121-5631 |
HUB ASM Price: $156.48 |
| 2 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 3 |
136-7963 |
TIRE ASM Price: $455.76 |
| 3 |
532140675 |
STRAP Price: $5.99 |
| 4 |
115-5103 |
SCREW-HHF Price: $0.34 |
| 5 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 6 |
325-12 |
SCREW-HH Price: $2.27 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 7 |
147-3594 |
ADAPTER-BRAKE This part replaces 120-6253-03. Price: $47.56 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 8 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 8 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 9 |
117-3290 |
NUT-HEX Price: $32.02 |
| 10 |
114-8864 |
DRUM-BRAKE Price: $248.55 |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT This part replaces 532182493. Price: $17.99 |
| 11 |
127-2741 |
SHIELD-WHEEL, FRONT Price: $9.99 |
| 12 |
127-2742 |
SHIELD-WHEEL, REAR Price: $8.07 |
| 12 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT.BLACK This part replaces 532121246. Price: $8.99 |
| 13 |
532121248 |
BUSHING Price: $4.99 |
| 14 |
283-62 |
PIN-CLEVIS Price: $0.61 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $4.99 |
| 15 |
139-5952 |
LH BRAKE ASM This part replaces 120-6261. Price: $449.41 |
| 16 |
139-5951 |
RH BRAKE ASM This part replaces 120-6260. Price: $449.41 |
| 16 |
532123740 |
SPRING COMPRESSED Price: $3.99 |
| 17 |
323-4 |
SCREW-HH Price: $1.02 |
| 17 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 18 |
322-7 |
SCREW-HH Price: $0.89 |
| 20 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 21 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 22 |
120-6267 |
CLIP-SPRING, LH Price: $6.99 |
| 22 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 23 |
120-6266 |
CLIP-SPRING, RH Price: $6.99 |
| 24 |
532177946 |
TRACK SLIDE, SEAT(L) Price: $59.99 |
| 24 |
87-4020 |
SPRING-EXTENSION Price: $17.01 |
| 25 |
3218-2 |
NUT-JAM Price: $0.25 |
| 25 |
532177947 |
TRACK SLIDE, SEAT(R) Price: $119.99 |
| 26 |
596039901 |
Washers This part replaces 819111012. Price: $2.99 |
| 28 |
810010500 |
WASHER Price: $3.99 |
| 33 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874780512. Price: $3.99 |
| 35 |
583670601 |
CAP.VINYL.BLK.SERVICE This part replaces 532178426. Price: $2.99 |
| 37 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
