| Ref | Part Number | Description |
|---|
| 1 |
75-6180 |
HOSE Price: $72.14 |
| 1 |
929-3022 |
MAIN HARNESS Not Available This part replaces 629-3022. Price: |
| 2 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 2 |
925-0222 |
Head Light This part replaces 725-0222. Price: $51.68 |
| 3 |
353-512 |
PLUG Price: $15.26 |
| 3 |
725-3185 |
HARNESS-INDICATOR Not Available Price: |
| 4 |
321-11 |
SCREW-HH Price: $0.36 |
| 4 |
925-1365 |
Bulb, Indicator This part replaces 725-1365. Price: $9.56 |
| 5 |
75-1180 |
BLOCK-MANIFOLD, 4 PORT Price: $187.64 |
| 5 |
925-3159 |
HOUR METER Not Available This part replaces 725-3159. Price: |
| 6 |
340-143 |
ELBOW-SWIVEL, 90 DEG Price: $58.91 |
| 6 |
710-0936 |
SCREW #6-20 x .625 Not Available Price: |
| 7 |
32128-33 |
NUT-HF Price: $0.25 |
| 7 |
725-3066 |
SWITCH Not Available Price: |
| 8 |
340-132 |
FITTING-ELBOW, 90 DEG Price: $24.64 |
| 8 |
712-3052 |
LOCK NUT #4-40 Not Available Price: |
| 9 |
711-3259 |
SCREW-SWITCH Not Available Price: |
| 9 |
93-0118 |
HOSE ASM Price: $123.69 |
| 10 |
75-6080 |
HOSE ASM Price: $53.86 |
| 10 |
925-3163 |
Switch, Ignition This part replaces 725-3163. Price: $44.93 |
| 11 |
712-3013 |
NUT-IGNITION SWITCH Not Available Price: |
| 12 |
925-0201 |
Key This part replaces 759-3476A. Price: $8.70 |
| 12 |
98-9742 |
VALVE-CONTROL, FLOW Price: $158.79 |
| 13 |
75-6070 |
HOSE Price: $35.77 |
| 13 |
925-0893 |
Switch, PTO This part replaces 725-0893. Price: $72.43 |
| 14 |
712-3014 |
HEX NUT 1/2-27 x .100 THK Not Available Price: |
| 14 |
94-4920-03 |
PLATE-MOUNTING, VALVE Price: $29.80 |
| 15 |
925-3164A |
Switch, Interlock This part replaces 725-3164. Price: $37.67 |
| 15 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 16 |
32128-20 |
NUT-HF Price: $0.99 |
| 16 |
735-3036 |
BOOT-SWITCH Not Available Price: |
| 17 |
340-1 |
FITTING-STRAIGHT Price: $10.19 |
| 17 |
925-3166 |
Switch, Snap Mount Normally Closed (Grey) This part replaces 725-3166. Price: $15.61 |
| 18 |
925-3167 |
Switch, Snap Mount Normally Open (Black) This part replaces 725-3167. Price: $13.53 |
| 19 |
725-3019 |
CABLE ASSEMBLY-TAIL LAMP Not Available Price: |
| 20 |
725-3020 |
BULB Not Available Price: |
| 21 |
725-3018 |
Lens Assy, Tail Light Price: Call Us |
| 22 |
710-0748 |
SCREW #12-14 x .500 Not Available Price: |
