| Ref | Part Number | Description |
|---|
| 1 |
55100100 |
WLDMT, LIFT FRAME - W/ZERK AND DECAL Price: $1,733.95 |
| 2 |
55100200 |
WLDMT, LINK LIFT - W/ZERK Price: $239.45 |
| 3 |
05901631 |
BLT,HEX .50-13X1.50 G5 ZCC Price: $3.95 |
| 4 |
05901701 |
BLT,HEX .31-18X1.00 G5 ZCC Price: $1.45 |
| 5 |
05901711 |
BLT,HEX .38-16X1.00 G5 ZCC Price: $1.45 |
| 6 |
05901835 |
BLT, HEX .50-13X2.25 G5 ZCC Price: $3.45 |
| 7 |
06401013 |
WSHR,FLT .406X.812X.065 ZCC Price: $0.95 |
| 8 |
06401015 |
WSHR,FLT .531X1.062X.095 ZCC Price: $0.95 |
| 9 |
06401017 |
WSHR,FLT .344X.688X.065 ZCC Price: $0.45 |
| 10 |
06401039 |
WSHRFLT 5/8SAE CARBHARD FBP Price: $3.45 |
| 11 |
06401140 |
WSHR, FLT .812X1.469X.134 ZCC Price: $1.45 |
| 12 |
06500726 |
NUT,NYL-FLG .38-16 GF ZCC Price: $1.45 |
| 13 |
06500809 |
NUT,LK-NYL-FLG .31-18 G5ZC120 Price: $1.45 |
| 14 |
06500827 |
NUT,LK-CTR .50-13 GA ZCC Price: $3.95 |
| 15 |
06700212 |
PIN,CTR.12X1.25EXTPRSQCT ZC120 Price: $0.45 |
| 16 |
06700214 |
PIN, CTR .18X1.50 EXTPRSQCT ZC120 Price: Call Us |
| 17 |
06800215 |
PIN- CLEVIS .50 X 1.75" Price: $7.95 |
| 18 |
06800216 |
PIN- CLEVIS Price: $12.45 |
| 19 |
07002003 |
CLAMP, HARNESS - "P" (5/8" ID) Price: $2.45 |
| 20 |
07002004 |
BOLT- HEX 5/8-11 X 1" GR5 Price: $3.45 |
| 21 |
07002025 |
SPRG- COMPRESSION Price: $2.45 |
| 22 |
07001806 |
FITTING, LUBE .25-28X.256 ZC120 This part replaces 07012600. Price: $4.95 |
| 23 |
09450900 |
ACTUATOR- LINEAR PARKER EHA Price: $999.95 |
| 24 |
09452300 |
PLATE- BRKT CONNECTOR Price: $20.45 |
| 25 |
09456000 |
CAP- DUST Price: $6.45 |
| 26 |
09456100 |
LATCH- LEFT COUPLER Price: $20.45 |
| 27 |
09456200 |
HANDLE- RIGHT COUPLER Price: $30.95 |
| 28 |
09456300 |
LATCH- RIGHT COUPLER Price: $15.45 |
| 29 |
09456400 |
HANDLE- LEFT COUPLER Price: $40.95 |
| 30 |
09456600 |
PIN- PIVOT Price: $40.95 |
