| Ref | Part Number | Description |
|---|
| 1 |
140-5560 |
FULL REAR ROLLER(2.0IN DIA)(21IN) This part replaces 119-4093. Price: $291.30 |
| 1 |
530016154 |
Screw Price: $0.99 |
| 2 |
119-4166 |
SPACER-HEIGHT, ROLLER Price: $6.17 |
| 2 |
530069700 |
Kit-Cylinder Shield Price: $14.99 |
| 3 |
119-4157 |
RETAINER-SHAFT Price: $6.03 |
| 3 |
530037464 |
Grommet -Carb. Price: $1.99 |
| 4 |
119-4165 |
SHIM-HEIGHT, ROLLER Price: $4.02 |
| 4 |
530015814 |
Screw Price: $1.99 |
| 5 |
119-4035 |
SCREW-HSH Price: $1.00 |
| 6 |
119-4040 |
NUT-FLANGE, NI Price: $0.52 |
| 6 |
545199901 |
IGNITION MODULE This part replaces 530039143. Price: $22.99 |
| 7 |
140-5691 |
BRACKET-GR FRONT HOC This part replaces 115-7041. Price: $20.85 |
| 7 |
530015895 |
Screw Price: $1.99 |
| 8 |
110-7352 |
SCREW-HOC Price: $17.51 |
| 8 |
530037467 |
Assy-Switch Wire Price: $19.99 |
| 9 |
530037652 |
Insulator-Heat Price: $1.99 |
| 9 |
99-3773 |
BOLT-PLOW Price: $10.65 |
| 10 |
48-9220 |
WASHER-PLAIN This part replaces 119-4158. Price: $0.87 |
| 11 |
133-7570 |
NUT-FLANGE, NI This part replaces 115-7193. Price: $0.45 |
| 12 |
119-4067 |
SCREW-HH Price: $0.81 |
| 12 |
574266401 |
NUT 10MM BRASS This part replaces 530016359. Price: $1.99 |
| 13 |
530056061 |
Cover-Bolt Price: $2.99 |
| 14 |
530016338 |
Bolt-Muffler Price: $1.99 |
| 15 |
530016351 |
Screw-Spark Screen Price: $1.99 |
| 16 |
530055128 |
Gasket-Muffler Price: $1.99 |
| 17 |
530055765 |
Assy-Muffler Backplate Price: $3.99 |
| 18 |
530055402 |
Backplate - Alum. Price: $4.99 |
| 19 |
530032117 |
Bearing Price: $4.99 |
| 20 |
530056363 |
Assy-Bearing & Seal Price: $11.99 |
| 21 |
530049794 |
Cap-Crankcase Price: $3.99 |
| 22 |
530015897 |
Screw Price: $1.99 |
| 23 |
503920801 |
ASSY-CRANKSHAFT & ROD This part replaces 530029794. Price: $129.99 |
| 24 |
530015697 |
Retainer-Piston Pin Price: $1.99 |
| 25 |
530037380 |
Ring-Piston Price: $2.99 |
| 28 |
530019251 |
Seal-Super Clean Price: $1.99 |
| 29 |
530071654 |
Kit-Carb.-Adapter This part replaces 530037668. Price: $17.99 |
| 30 |
530053396 |
Adapter-Carb. Price: $2.99 |
| 31 |
530037872 |
Intake Plate-Carb Price: $1.99 |
| 32 |
530019172 |
Gasket-Carb. Price: $1.99 |
| 34 |
530036792 |
Isolator Price: $4.99 |
| 36 |
530015970 |
Screw Price: $1.99 |
| 38 |
530015899 |
Screw Price: $1.99 |
| 40 |
530095646 |
Assy-Fuel Pick-up Price: $2.99 |
