| Ref | Part Number | Description |
|---|
| 1 |
132-6259-0P |
SWITCH MOUNT ASM This part replaces 132-6259-03. Price: $105.94 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532163465. Price: $149.99 |
| 2 |
117-5458 |
SCREW-HHF Price: $0.22 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 3 |
99-3410 |
SWITCH Price: $95.63 |
| 4 |
108-9824 |
NUT-SWITCH Price: $1.97 |
| 5 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 6 |
32144-69 |
SCREW-HWHTF Price: $1.58 |
| 7 |
2412-4 |
CLAMP-R Price: $4.22 |
| 8 |
256-236 |
BEARING-MOUNT, FLANGE Price: $27.99 |
| 8 |
532176689 |
BOX.BATTERY.FENDER Price: $9.99 |
| 9 |
120-8899 |
CABLE-BRAKE, LH Price: $97.43 |
| 10 |
322-13 |
SCREW-HH Price: $2.73 |
| 11 |
132-6290-0P |
RACK ASM This part replaces 132-6290-03. Price: $114.51 |
| 12 |
3256-69 |
WASHER-FLAT Price: $0.62 |
| 13 |
63-7880 |
PIN-LATCH, BRAKE Price: $6.04 |
| 14 |
32121-50 |
PIN-SPRING Price: $1.21 |
| 15 |
93-8742 |
FOOTPAD-BRAKE Price: $27.95 |
| 16 |
132-6288-01 |
PEDAL-BRAKE, LH Price: $132.21 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $19.99 |
| 17 |
120-8898 |
CABLE-BRAKE, RH Price: $104.62 |
| 18 |
94-3088 |
SPRING-COMPRESSION Price: $8.24 |
| 19 |
120-9694 |
PIN-CLEVIS Price: $2.17 |
| 20 |
3234-29 |
SCREW-HHF Price: $1.84 |
| 21 |
132-6252 |
PEDAL-BRAKE, RH Price: $122.77 |
| 21 |
532166181 |
HARNESS Price: $26.99 |
| 22 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 22 |
532004152 |
LIGHTBULB Price: $3.99 |
| 23 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 24 |
3231-21 |
SCREW-CARR Price: $0.76 |
| 24 |
532004799 |
BATTERY CABLE This part replaces 532124780. Price: $8.99 |
| 25 |
532146147 |
CABLE BATTERY Price: $22.99 |
| 25 |
94-3050 |
PLATE-SPRING Price: $7.88 |
| 26 |
532175158 |
FUSE 20AMP Price: $4.99 |
| 27 |
110-4896 |
LANYARD Price: $40.99 |
| 27 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 28 |
3256-57 |
WASHER-FLAT Price: $0.41 |
| 28 |
532004207 |
CABLE T This part replaces 532124773. Price: $4.99 |
| 29 |
3230-23 |
SCREW-CARR Price: $0.89 |
| 29 |
532421062 |
SWITCH.SNAPMOUNT.NC This part replaces 532121305. Price: $12.99 |
| 30 |
132-6247-01 |
MOUNT-BEARING Price: $13.60 |
| 30 |
532175566 |
IGNITION SWITCH Price: $22.99 |
| 31 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 32 |
137-1632 |
HUB-BRAKE This part replaces 132-6229. Price: $43.71 |
| 33 |
4-2390 |
WASHER-FLAT Price: $0.62 |
| 34 |
32121-125 |
PIN-SPRING Price: $0.54 |
| 35 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 36 |
88-7970 |
CLIP Price: $2.51 |
| 40 |
532179720 |
HARNESS.IGNITION Price: $99.99 |
| 41 |
596437001 |
Screws This part replaces 871110408. Price: $2.99 |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 43 |
532146154 |
KIT SOLENOID .95 This part replaces 532178861. Price: $19.99 |
| 48 |
532140844 |
ADAPTER.AMMETER Price: $4.99 |
| 52 |
532141940 |
WIRE PROTECTION LOOP Price: $4.99 |
| 89 |
532435395 |
COVER.TERMINAL.BATTERY This part replaces 532180449. Price: $4.99 |
