Auger Housing/Impeller Assembly
Parts (37)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 105-8250 | CONSOLE Price: $213.37 |
| 1 | 404929X428 | AUGER HOUSING 27 Price: Call Us |
| 2 | 105-8254-03 | LID-CONSOLE Price: $63.57 |
| 2 | 404932X479 | SCRAPER BAR Price: Call Us |
| 3 | 105-8255-03 | BAFFLE-CONSOLE Price: $33.59 |
| 3 | 72270505 | CARRIAGE BOLT 5/16-18 X .625 Price: Call Us |
| 4 | 105-8256 | ROD-HINGE Price: $17.77 |
| 5 | 105-8283 | BUSHING Price: $1.70 |
| 6 | 105-8251 | POD Price: $67.39 |
| 7 | 105-8252-03 | BRACKET-POD Price: $113.31 |
| 8 | 105-8284-03 | SHIELD-VALVE Price: $21.17 |
| 9 | 94-5780 | SCREW-HWH Price: $7.49 |
| 10 | 93-5547 | BUSHING-NYLON Price: $6.15 |
| 11 | 147-3050 | HUB-PIVOT, JOYSTICK This part replaces 105-7507. Price: $21.71 |
| 12 | 3296-29 | NUT-LOCK, NI Price: $2.09 |
| 13 | 3290-354 | NUT-SPEED Price: $9.99 |
| 14 | 3290-329 | SCREW-PPH Price: $0.22 |
| 15 | 111332 | SWITCH Price: $10.99 |
| 16 | 93-5512 | SPACER Price: $3.80 |
| 17 | 233-42 | KNOB Price: $12.88 |
| 18 | 93-5961 | BOOT-LEVER Price: $56.35 |
| 19 | 115-5357-03 | BRACKET-JOYSTICK This part replaces 105-8287-03. Price: $35.61 |
| 20 | 105-8288 | ROD-JOYSTICK Price: $26.49 |
| 21 | 105-8289 | SPRING-TORSION Price: $15.05 |
| 22 | 105-8280-03 | PLATE-CONSOLE Price: $9.63 |
| 23 | 105-8305 | DECAL-PANEL, CONTROL Price: $23.63 |
| 24 | 105-8306 | DECAL-SELECTOR, SPEED Price: $20.42 |
| 25 | 104-2541 | SWITCH ASM This part replaces 88-9830. Price: $36.70 |
| 27 | 63-8360 | KEY-IGNITION Price: $5.29 |
| 29 | 3230-1 | BOLT-CARR Price: $1.49 |
| 30 | 32144-19 | SCREW-SHWH Price: $0.89 |
| 31 | 32144-10 | SCREW-HWH Price: $4.29 |
| 32 | 3290-134 | SCREW Price: $0.27 |
| 34 | 3290-148 | NUT-HF Price: $0.25 |
| 35 | 3256-22 | WASHER-FLAT Price: $0.39 |
| 36 | 3290-378 | TIE-CABLE Price: $0.79 |
| 37 | 3256-77 | WASHER-FLAT Price: $1.60 |
