| Ref | Part Number | Description |
|---|
| 1 |
237-21 |
O-RING Price: $0.70 |
| 1 |
539105060 |
CLEVIS PIN Price: $4.99 |
| 2 |
322-3 |
SCREW-HH Price: $0.79 |
| 2 |
596933401 |
Washers This part replaces 539991043. Price: $2.99 |
| 3 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 3 |
539105069 |
E-RING 5/8 Price: $2.99 |
| 4 |
595305901 |
Nuts This part replaces 539990546. Price: $2.99 |
| 4 |
82-9330 |
BRACKET - SENSOR *R Price: $24.29 |
| 5 |
23-1840 |
BUSHING-TAPERLOCK Price: $92.22 |
| 5 |
596917701 |
Pins This part replaces 539102526. Price: $4.99 |
| 6 |
237-22 |
O-RING Price: $2.43 |
| 6 |
539105059 |
LANYARD Price: $4.99 |
| 7 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 7 |
594722002 |
LIFT This part replaces 539102641. Price: $4.99 |
| 8 |
237-42 |
O-RING Price: $2.78 |
| 8 |
539104321 |
ADJ. PLATE WLDMNT Price: $63.99 |
| 9 |
539104530 |
DECK LIFT SPACER Price: $5.99 |
| 9 |
58-0070 |
DISC BRAKE ASM Price: $316.73 |
| 10 |
353-948 |
FITTING-PLUG Price: $3.31 |
| 10 |
539104323 |
ADJ. PLATE PAINTED Price: $23.99 |
| 11 |
237-118 |
O-RING Price: $1.73 |
| 11 |
596434201 |
Bolts This part replaces 539990637. Price: $3.99 |
| 12 |
58-5430 |
PISTON MOTOR ASM Price: $3,072.75 |
| 12 |
596273101 |
Pins This part replaces 539976989. Price: $2.99 |
| 13 |
237-81 |
O-RING Price: $2.76 |
| 13 |
596564404 |
Bolts This part replaces 539990629. Price: $2.99 |
| 14 |
340-9 |
FITTING-HYD, STRAIGHT Price: $67.47 |
| 14 |
539102515 |
GRIP Price: $3.99 |
| 15 |
237-58 |
O-RING Price: $2.18 |
| 15 |
539108322 |
LIFT LEVER WELDMENT Price: $84.99 |
| 16 |
323-18 |
SCREW-HH Price: $0.82 |
| 16 |
539105050 |
LIFT LINKAGE,PAINTED Price: $23.99 |
| 17 |
3253-5 |
WASHER-LOCK Price: $0.29 |
| 17 |
539101232 |
BUSHING, FLANGED Price: $11.99 |
| 18 |
353-949 |
O-RING Price: $3.49 |
| 18 |
539104761 |
GREASE ZERK LONG Price: $2.99 |
| 19 |
539108354 |
SHAFT LIFT REAR Price: $108.99 |
| 19 |
60-6990 |
WASHER Price: $4.62 |
| 20 |
327-3 |
SCREW-HH Price: $1.49 |
| 20 |
539976982 |
WASHER 5/8 FLAT Price: $3.99 |
| 21 |
539990654 |
COTTER PIN Price: $2.99 |
| 21 |
58-5530 |
DISCONTINUED X-REF Price: Call Us |
| 22 |
3247-10 |
SETSCREW Price: $0.55 |
| 22 |
539104808 |
PILLOW BLOCK Price: $7.99 |
| 23 |
3219-5 |
NUT-HEX Price: $1.22 |
| 23 |
584392702 |
REINFORCEMENT.PLATEX431 This part replaces 539104807. Price: $11.99 |
| 24 |
539991046 |
BOLT 5/16C X 2 1/2 Price: $3.99 |
| 24 |
58-5610 |
RIM Price: $360.43 |
| 25 |
539108355 |
LIFT SHAFT Price: $108.99 |
| 25 |
58-5620 |
TUBE Price: $89.16 |
| 26 |
136-3327 |
TIRE This part replaces 63-4480. Price: $404.86 |
| 26 |
596580701 |
Nuts This part replaces 539990184. Price: $2.99 |
| 27 |
323-20 |
SCREW-HH Price: $1.28 |
| 27 |
539101982 |
EYEBOLT, RH Price: $37.99 |
| 28 |
58-3780 |
TUBE-SPACE Price: $25.99 |
| 28 |
596039201 |
GSPW Hardware This part replaces 539990585. Price: $2.99 |
| 29 |
29-1060 |
BRACKET-SECONDARY Price: $135.49 |
| 29 |
539104760 |
DECK LIFT SPRING Price: $5.99 |
| 30 |
539101050 |
GRIP Price: $2.99 |
| 31 |
539104523 |
PIN Price: $7.99 |
| 32 |
539103534 |
PIN MT, UPPER Price: $22.99 |
| 32 |
58-0110-03 |
BRACKET-CALIPER, BRAKE This part replaces 58-0110. Price: $142.37 |
| 33 |
3296-39 |
NUT-LOCK, NI This part replaces 3296-17. Price: $2.29 |
| 33 |
539101058 |
SPRING Price: $3.99 |
| 34 |
29-1070 |
LEVER ASM Price: $64.17 |
| 34 |
539923787 |
BSHG .875 X 1.375 X .074 ZD Price: $2.99 |
| 35 |
3272-2 |
PIN-COTTER Price: $2.29 |
| 35 |
539990761 |
NUT 1/4C CENTER LOCK Price: $2.99 |
| 36 |
539101082 |
ROLL PIN 3/16 X 1-1/4 ZD Price: $2.99 |
| 36 |
60-1740 |
NUT Price: $1.53 |
| 37 |
58-2300 |
LINK-BRAKE Price: $30.30 |
| 37 |
596230901 |
Screws This part replaces 539990580. Price: $2.99 |
| 38 |
539101802 |
E-RING 7/8 Price: $2.99 |
| 38 |
60-1730 |
PIN-CLEVIS Price: $0.65 |
| 39 |
29-1080 |
BRAKE PAD Price: $66.87 |
| 39 |
539104310 |
CONNECTING LINK Price: $22.99 |
| 40 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 40 |
539990655 |
HCS 3/8C X 1 1/2 Price: $3.99 |
| 41 |
3256-27 |
WASHER-FLAT Price: $0.47 |
| 41 |
539105181 |
LIFT PEDAL BLK Price: $84.99 |
| 42 |
539105187 |
ANTI-SKID PAD Price: $2.99 |
| 42 |
82-9280 |
DISC WA Price: $599.98 |
| 43 |
539105184 |
TIGHTENING PLATE BLK Price: $37.99 |
| 44 |
596240901 |
GSPW Nuts This part replaces 539976979. Price: $2.99 |
