TRANSMISSION
Parts (32)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 74610412 | BOLT Price: Call Us |
| 2 | 10040400 | LOCKWASHER Price: Call Us |
| 2 | 22-8370 | SEAT-VALVE Price: $88.05 |
| 3 | 19092016 | WASHER Price: Call Us |
| 3 | 22-8500 | O-RING Price: $18.87 |
| 4 | 105-7826 | SPOOL Price: $312.56 |
| 4 | 19091412 | WASHER Price: Call Us |
| 5 | 22-8380 | RETAINER Price: $17.86 |
| 5 | 74760544 | SUB= 74780544 Price: Call Us |
| 6 | 22-8400 | SPACER Price: $42.41 |
| 6 | 2606J505 | ENGINE BRKT RH Price: Call Us |
| 7 | 22-8390 | RETAINER Price: $56.56 |
| 7 | 9173R | SPLIT SPACER RT Price: Call Us |
| 8 | 132212X505 | ENGINE BRKT LH Price: Call Us |
| 8 | 22-8410 | SPRING Price: $17.61 |
| 9 | 10040500 | LOCKWASHER Price: Call Us |
| 9 | 22-8480 | RING-SNAP Price: $49.87 |
| 10 | 22-8490 | RING-SNAP Price: $6.51 |
| 10 | 73220500 | NUT.HEX.5/16-18 Price: Call Us |
| 11 | 19131311 | WASHER Price: Call Us |
| 11 | 22-8360 | PIN Price: $43.02 |
| 12 | 22-8350 | BALL Price: $12.28 |
| 13 | 73800600 | NUT Price: Call Us |
| 14 | 105391X | SUB= 918105391X Price: Call Us |
| 15 | 106-8070 | DETENT BARREL ASM This part replaces 105-7828. Price: $128.27 |
| 15 | 73510500 | NUT Price: Call Us |
| 16 | 105-7829 | BALL-STEEL Price: $18.26 |
| 16 | 74780652 | BOLT HEX 3/8-16 Price: Call Us |
| 17 | 105-7830 | SPRING Price: $32.46 |
| 18 | 105-7831 | SCREW-SET Price: $19.52 |
| 19 | 105-7832 | STUD-DETENT Price: $50.21 |
| 20 | 105-7833 | SCREW-HSH Price: $14.53 |
