| Ref | Part Number | Description |
|---|
| 1 |
100-3840 |
SHAFT-AXLE, LH Price: $885.27 |
| 1 |
100-3841 |
SHAFT-AXLE, RH Price: $728.15 |
| 1 |
140044 |
WHEEL STR AYP BLK Price: Call Us |
| 2 |
100-3842 |
SEAL-OIL Price: $23.39 |
| 2 |
142033 |
AXLE ASM FRONT Price: Call Us |
| 3 |
135227 |
SPINDLE LH Price: Call Us |
| 3 |
21-8180 |
BEARING ASM Price: $65.11 |
| 4 |
100-3843 |
SHIELD-DUST Price: $22.02 |
| 4 |
135228 |
SPINDLE RH Price: Call Us |
| 5 |
100-3844 |
SPIDER-TORQUE Price: $242.90 |
| 5 |
6266H |
WASHER .T Price: Call Us |
| 6 |
121748X |
WASHER Price: Call Us |
| 6 |
21-9390 |
SOCKET-SCREW, ADJUSTING Price: $5.56 |
| 7 |
19272016 |
WASHER Price: Call Us |
| 7 |
21-9370 |
SCREW-ADJUSTING Price: $18.80 |
| 8 |
12000029 |
RING Price: Call Us |
| 8 |
21-9380 |
NUT-PIVOT Price: $26.77 |
| 9 |
242-34 |
STUD-DRIVE Price: $11.61 |
| 9 |
3366R |
COL. SRTG. BEAR. Price: Call Us |
| 10 |
130468 |
SUB= 532130468 Price: Call Us |
| 10 |
21-8360 |
CLIP-RETAINING Price: $1.29 |
| 11 |
10040600 |
Washer, Lock Hvy. Hlcl. Spr. 3/8 Price: Call Us |
| 11 |
28-0680-03 |
DRUM-BRAKE This part replaces 28-0680. Price: $358.84 |
| 12 |
73610600 |
SUB= 7810H Price: Call Us |
| 13 |
100-3845 |
SEAL-GREASE Price: $7.52 |
| 13 |
110438X |
BEARING Price: Call Us |
| 14 |
21-9440 |
SPRING-SCREW, ADJUSTING Price: $11.92 |
| 14 |
74011056 |
BOLT HEX 5/8-11 Price: Call Us |
| 15 |
21-9460 |
RETAINER-LEVER, BRAKE Price: $2.18 |
| 16 |
132624 |
AXLE PIN Price: Call Us |
| 16 |
84-8600 |
SET-SHOES, LINED This part replaces 84-8590. Price: $131.50 |
| 17 |
140176 |
SHAFT ASM STEERIN Price: Call Us |
| 17 |
21-9420 |
SPRING-RETURN, LH Price: $19.96 |
| 18 |
21-9430 |
SPRING-RETURN, RH Price: $19.96 |
| 18 |
57079 |
THRUST WASHER Price: Call Us |
| 19 |
124035X |
SUPPORT.SHAFT Price: Call Us |
| 19 |
24-9180 |
STRUT AND LEVER ASM Price: $86.76 |
| 20 |
126684X |
SUB= 532126684 Price: Call Us |
| 21 |
100-3846 |
SCREW-SPECIAL Price: $1.90 |
| 21 |
10040400 |
LOCKWASHER Price: Call Us |
| 22 |
100-3847 |
RETAINER-BEARING Price: $86.16 |
| 23 |
100-3848 |
O-RING Price: $4.69 |
| 23 |
127501 |
SUB= 918127501 Price: Call Us |
| 24 |
100-3849 |
CAP-BEARING Price: $433.26 |
| 24 |
109816X |
NYLINER T Price: Call Us |
| 25 |
100-3850 |
ZERK-SPECIAL Price: $2.24 |
| 26 |
126847X |
BUSHING.DRAGLINK Price: Call Us |
| 27 |
136874 |
GEAR SECTOR Price: Call Us |
| 28 |
19131416 |
WASHER Price: Call Us |
| 29 |
17490612 |
SCREW Price: Call Us |
| 30 |
76020412 |
COTTER PIN Price: Call Us |
| 32 |
130465 |
TIE ROD Price: Call Us |
| 36 |
102803X |
SUB= 918102803X Price: Call Us |
| 37 |
17431008 |
SUB= 98000165 Price: Call Us |
| 38 |
140045 |
CAP STEER AYP Price: Call Us |
| 39 |
19133808 |
WASHER T Price: Call Us |
| 40 |
7810H |
GRIPCO NUT Price: Call Us |
| 41 |
104820X |
ADAPTER-WHEEL LT Price: Call Us |
| 42 |
140216 |
BOOT SHAFT STEER Price: Call Us |
| 43 |
121749X |
WASHER Price: Call Us |
| 44 |
140171 |
SHAFT EXT STEER Price: Call Us |
| 46 |
121232X |
CAP Price: Call Us |
| 47 |
6855M |
ZERK M Price: Call Us |
| 50 |
17490412 |
SCREW HEX CRT Price: Call Us |
| 51 |
73800500 |
NUT Price: Call Us |
| 54 |
74780520 |
BOLT Price: Call Us |
| 55 |
140285 |
CLIP TINNERMAN Price: Call Us |
