| Ref | Part Number | Description |
|---|
| 1 |
5-2942 |
SHACKLE Price: $16.99 |
| 2 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 3 |
47-3430-01 |
BRACKET-LIFT This part replaces 47-3430. Price: $159.43 |
| 4 |
603773 |
LOCKNUT This part replaces 32153-2. Price: $2.09 |
| 6 |
283-10 |
PIN-CLEVIS Price: $7.43 |
| 7 |
323-8 |
SCREW-HH Price: $1.20 |
| 8 |
47-3280-01 |
NO. 4 LIFT ARM ASM This part replaces 47-3280. Price: $1,463.33 |
| 8 |
532193228 |
BOX.BATTERY.MNT.REAR.L Price: $24.99 |
| 9 |
3-4636 |
CHAIN Price: $22.51 |
| 10 |
3256-62 |
WASHER-FLAT Price: $0.75 |
| 11 |
23-2610-01 |
LINK ASM This part replaces 23-2610. Price: $211.99 |
| 12 |
3-0128 |
SHAFT Price: $75.98 |
| 13 |
5-1720 |
WASHER Price: $2.24 |
| 14 |
3253-5 |
WASHER-LOCK Price: $0.29 |
| 15 |
3211-4 |
SCREW-HH Price: $1.02 |
| 16 |
125-5196 |
BUSHING This part replaces 3-0348. Price: $6.00 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $19.99 |
| 21 |
532400252 |
HARNESS.LIGHT W/4152J BULBS Price: $19.99 |
| 22 |
532004152 |
LIGHTBULB Price: $3.99 |
| 25 |
581498001 |
CABLE.BATT.RED.8GA.17 Price: $7.99 |
| 26 |
532175158 |
FUSE 20AMP Price: $4.99 |
| 27 |
596133601 |
Hardware Price: $2.99 |
| 28 |
583390701 |
CABLE.GROUND.REAR.BATTERY.8GA This part replaces 532421686. Price: $8.99 |
| 29 |
532401545 |
SWITCH.SEAT.DELTA.OPC. Price: $34.99 |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $19.99 |
| 33 |
532411935 |
KEY.CHAIN.BLISTER.PACK.GEN.INT This part replaces 532411933. Price: $8.99 |
| 34 |
532110712 |
SWITCH LT Price: $7.99 |
| 40 |
581023101 |
HARNESS.TEX.DASH.MAN.REAR BATT Price: $32.99 |
| 43 |
582042802 |
Solenoids Price: $22.99 |
| 55 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 71 |
501133701 |
HARNESS.CHASSIS.RRBATT.RDYSTRT Price: $59.99 |
| 79 |
532175242 |
BULB HOLDER ASM. Price: $8.99 |
| 87 |
532197802 |
SWITCH.INTRLCK.CLUTCH. Price: $14.99 |
| 90 |
532435395 |
COVER.TERMINAL.BATTERY Price: $4.99 |
| 99 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 102 |
532404454 |
HARNESS PIGTAIL PCH TEX ROS Price: $14.99 |
| 105 |
532407568 |
REVERSE SWITCH Price: $12.99 |
