| Ref | Part Number | Description |
|---|
| 1 |
120-8001-0P |
MOUNT-ENGINE,LH,FRONT This part replaces 120-8001-03. Price: $32.33 |
| 1 |
532166627 |
STEERING WHEEL Price: $64.99 |
| 2 |
120-8002-0P |
MOUNT-ENGINE, RH FRONT This part replaces 120-8002-03. Price: $26.44 |
| 2 |
532193542 |
AXLE.ASM.LT.CAST.LGHTWGHT This part replaces 532184706. Price: $119.99 |
| 3 |
120-8003-0P |
MOUNT-ENGINE, LH REAR This part replaces 120-8003-03. Price: $41.80 |
| 3 |
596873901 |
KIT SPINDLE ASM.PNT.LH.15 This part replaces 532169840. Price: $14.99 |
| 4 |
120-8004-0P |
MOUNT-ENGINE, RH REAR This part replaces 120-8004-03. Price: $43.35 |
| 4 |
596873801 |
KIT SPINDLE ASM.PNT.RH.15" This part replaces 532169839. Price: $27.99 |
| 5 |
48-9590 |
WASHER-LOCK Price: $0.25 |
| 5 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
33115-025 |
SCREW-HH Price: $0.61 |
| 6 |
532121748 |
WASHER Price: $3.99 |
| 7 |
53-9682 |
MOUNT-ENGINE Price: $108.69 |
| 8 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 10 |
532175121 |
DRAGLINK.15".TIRES.2001 Price: $59.99 |
| 10 |
63-7400 |
WASHER-REBOUND Price: $1.70 |
| 11 |
3255-9 |
WASHER-LOCK Price: $0.28 |
| 11 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 12 |
104-5420-0P |
BATTERY SUPPORT ASM [PRIMED] This part replaces 104-5420-03. Price: $125.91 |
| 12 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 13 |
3234-29 |
SCREW-HHF Price: $1.84 |
| 13 |
532136518 |
TUBE, PIVOT AXLE Price: $7.99 |
| 14 |
32128-20 |
NUT-HF Price: $0.99 |
| 15 |
114-8134-03 |
BRACKET-SUPPORT Price: $100.05 |
| 15 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
| 16 |
323-10 |
SCREW-HH Price: $0.89 |
| 17 |
32128-21 |
NUT-HF Price: $0.39 |
| 18 |
119-4162 |
SCREW-CARR This part replaces 323-13. Price: $1.73 |
| 19 |
136-3615-0P |
A/C MOUNT ASM [PRIMED] This part replaces 121-3140-03. Price: $295.77 |
| 20 |
121-3102-0P |
BRACKET-CONTROLLER [PRIMED] This part replaces 121-3102-03. Price: $43.43 |
| 21 |
121-3098-03 |
SUPPORT-TAILPIPE Price: $113.25 |
| 23 |
120-9738 |
SCREW-HH This part replaces 322-11. Price: $0.84 |
| 24 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 25 |
323-6 |
SCREW-HH Price: $0.66 |
| 26 |
18-2130 |
CLAMP Price: $5.63 |
| 27 |
99-7435 |
RELAY Price: $32.43 |
| 28 |
99-7430 |
RELAY-MINI Price: $22.99 |
| 29 |
321-3 |
SCREW-HH Price: $0.28 |
| 29 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 31 |
3290-134 |
SCREW Price: $0.27 |
| 32 |
3290-277 |
NUT-SPEED Price: $0.61 |
| 32 |
532171888 |
TIE ROD Price: $59.99 |
| 33 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111216. Price: $2.99 |
| 34 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 35 |
873540500 |
NUT, CROWNLOCK Price: $3.99 |
| 36 |
532155106 |
KIT.BUSHING.STEERING This part replaces 532155099. Price: $8.99 |
| 37 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 38 |
532172092 |
INSERT.CAP.STRG.WH (3 2) (L B) This part replaces 532166626. Price: $12.99 |
| 39 |
819182411 |
Washer 9/16 ID x 1 1/2 OD 11 Ga. Zin Price: $4.99 |
| 40 |
873610600 |
NUT This part replaces 532124701. Price: $2.99 |
| 41 |
532159945 |
STEERING WHEEL ADAPTOR Price: $6.99 |
| 42 |
532145054 |
STEERING BOOT, GRAY This part replaces 532169634. Price: $11.99 |
| 43 |
532121749 |
WASHER Price: $2.99 |
| 44 |
532407600 |
KIT.RPLMNT.SHAFT.STRG. This part replaces 532180640. Price: $59.99 |
| 46 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 51 |
873540400 |
NUT.CROWNLOCK.1/4-28 Price: $4.99 |
| 54 |
871130420 |
Bolt Hex 1/4-28 unf x 1-1/4 Gr. 8 Price: $4.99 |
| 65 |
532414736 |
SPACER.BRACE.AXLE This part replaces 532160367. Price: $5.99 |
| 67 |
872110618 |
BOLT CARRIAGE Price: $4.99 |
| 68 |
531167401 |
SERVICE KIT BRACE.AXLE.1 This part replaces 532169827. Price: $19.99 |
| 71 |
531167801 |
SERVICE KIT STEERING ASM This part replaces 532175146. Price: $139.99 |
| 82 |
531170201 |
SERVICE.KIT BRACKET This part replaces 532169835. Price: $19.99 |
| 87 |
532173966 |
WASHER, FLAT .781 X 1 1/2" Price: $4.99 |
| 88 |
532175118 |
BOLT, SHOULDER 7/16-20 Price: $4.99 |
| 91 |
532175553 |
CLIP.STEERING Price: $9.99 |
