| Ref | Part Number | Description |
|---|
| 1 |
105-7902 |
HYD HOSE ASM This part replaces 92-7556. Price: $77.63 |
| 1 |
719-3100 |
FRONT AXLE Not Available Price: |
| 2 |
532188655 |
MUFFLER.SINGLE.CYL.KOHL/B&S Price: $39.99 |
| 2 |
92-7560 |
HYD HOSE ASM Price: $99.17 |
| 2 |
937-3000 |
Grease Fitting This part replaces 7373000. Price: $4.04 |
| 3 |
120-6272 |
HYD MOTOR ASM This part replaces 92-7387. Price: $846.73 |
| 3 |
603-0007 |
STEERING KNUCKLE (LH) Not Available Price: |
| 4 |
237-79 |
O-RING Price: $5.46 |
| 4 |
603-0006 |
STEERING KNUCKLE (RH) Not Available Price: |
| 5 |
340-98 |
FITTING-ELBOW, 90 DEG Price: $31.91 |
| 5 |
736-0163 |
Washer, Thrust, 1.03 X 1.62 X .03 Thk HDN Price: $4.05 |
| 6 |
237-30 |
O-RING Price: $2.50 |
| 6 |
703-1884 |
STEERING ARM Not Available Price: |
| 7 |
105-7901 |
HYD HOSE ASM This part replaces 92-7555. Price: $185.30 |
| 7 |
736-0247 |
Washer, Flat, .406 X 1.25 X .157 Thk Price: $8.82 |
| 8 |
710-1039 |
Screw, Hex Cap 3/8-24 x 1.0 GR8 This part replaces 710-0152. Price: $4.02 |
| 8 |
92-7559 |
HYD HOSE ASM Price: $121.91 |
| 9 |
596501502 |
Keepers This part replaces 532194320. Price: $9.99 |
| 9 |
69-8930 |
WASHER Price: $0.81 |
| 9 |
712-3053 |
L-NUT 1/2-20 Not Available Price: |
| 10 |
340-127 |
NUT-BULKHEAD Price: $2.24 |
| 10 |
710-3210 |
SCREW-SOCKET HD 1/4-20X1.0L Not Available Price: |
| 11 |
583389701 |
KIT.SVC.CLUTCH.ELE.180505 This part replaces 532180505. Price: $299.99 |
| 11 |
69-8960 |
SPACER Price: $5.29 |
| 11 |
912-0107 |
Hex L-Nut 1/4-20 Thd This part replaces 712-0107. Price: $4.06 |
| 12 |
240-5 |
GROMMET Price: $13.66 |
| 12 |
532405097 |
PULLEY.ENGINE.TUFFTORQ Price: $49.99 |
| 12 |
923-3015 |
BALL JOINT Not Available This part replaces 723-3015. Price: |
| 13 |
340-70 |
NUT-LOCK Price: $2.10 |
| 13 |
712-3029 |
Nut, Hex Jam, 1/2-20 GR5 Price: $6.01 |
| 14 |
747-3162 |
DRAG LINK Not Available Price: |
| 14 |
93-4216 |
TUBE ASM Price: $98.51 |
| 15 |
532193499 |
TANK.FUEL.4GAL Price: $69.99 |
| 15 |
712-3012A |
HEX NUT This part replaces 712-3012. Price: $11.49 |
| 15 |
93-4223 |
FRONT DRAIN TUBE ASM Price: $94.84 |
| 16 |
714-3004 |
Pin, Cotter, 3/32 Dia X 1.25 Lg Price: $4.20 |
| 16 |
93-4222 |
DRAIN RETURN TUBE ASM Price: $85.32 |
| 17 |
747-3139 |
TIE ROD Not Available Price: |
| 17 |
93-4219 |
TUBE ASM Price: $116.65 |
| 18 |
105-7903 |
HYD HOSE ASM This part replaces 92-7649. Price: $174.38 |
| 18 |
584248702 |
CAP.ASSY.FUEL.3".N-EPA.GRY.498 This part replaces 532194267. Price: $14.99 |
| 18 |
710-1039 |
Screw, Hex Cap 3/8-24 x 1.0 GR8 This part replaces 710-0152. Price: $4.02 |
| 19 |
736-0169 |
Washer, Lock, 3/8 Price: $3.33 |
| 19 |
99-5614 |
HYD HOSE ASM This part replaces 93-4201. Price: $103.23 |
| 20 |
237-22 |
O-RING Price: $2.43 |
| 20 |
532401508 |
CONTROL.TH/CK.COBRA.KO Price: $24.99 |
| 20 |
736-3039 |
Washer, Flat, .406 X 1.5 X .12 Thk Price: $4.42 |
| 21 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 21 |
736-0921 |
Washer, Lock, 1/2 Price: $3.90 |
| 21 |
93-9151 |
FITTING-HYD Price: $40.90 |
| 22 |
237-21 |
O-RING Price: $0.70 |
| 22 |
712-3012A |
HEX NUT This part replaces 712-3012. Price: $11.49 |
| 23 |
340-68 |
FITTING-TEE, BULKHEAD Price: $36.00 |
| 23 |
714-3004 |
Pin, Cotter, 3/32 Dia X 1.25 Lg Price: $4.20 |
| 24 |
237-78 |
O-RING Price: $3.85 |
| 24 |
710-3019 |
BOLT-PIVOT 3/4-10 x 5.0 GR5 W Not Available Price: |
| 25 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 25 |
712-3011 |
HEX NUT Not Available Price: |
| 26 |
93-4217 |
DISCONTINUED Price: Call Us |
| 27 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 28 |
587044864 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532401135. Price: $17.99 |
| 28 |
93-9783 |
O-RING Price: $2.30 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 29 |
56-7972 |
CLAMP-TUBE Price: $13.55 |
| 30 |
322-7 |
SCREW-HH Price: $0.89 |
| 31 |
3296-47 |
NUT-LOCK, NI Price: $3.59 |
| 31 |
532145005 |
DECAL BTRY SYMBOLS Price: $3.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 64 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 69 |
532185909 |
GASKET.EXHAUST.KOHLER Price: $7.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN This part replaces 532181654. Price: $14.99 |
| 86 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 94 |
583955301 |
TUBE.EXHAUST.KOHLER.COURAGE This part replaces 532188654. Price: $27.99 |
| 95 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
