| Ref | Part Number | Description |
|---|
| 1 |
27-7150 |
A/C CUP ASM Price: $82.89 |
| 1 |
532401042 |
SEAT.XG090.BLK.KB/BLT.NO-LOG This part replaces 532140839. Price: $149.99 |
| 2 |
27-7140 |
SKIRT-BAFFLE Price: $85.92 |
| 2 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 3 |
27-7120 |
NUT AND GASKET ASM Price: $15.55 |
| 3 |
871110616 |
BOLT, HEX 3/8-16X1 Price: $3.99 |
| 4 |
27-7130 |
CLAMP ASM Price: $49.80 |
| 4 |
819131610 |
WASHER PM Price: $4.99 |
| 5 |
32107-11 |
NUT-SQUARE Price: $0.22 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 6 |
3258-19 |
SCREW Price: $0.42 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 7 |
27-7170 |
MOUNTING BAND ASM Price: $48.11 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 8 |
108-3833 |
FILTER-AIR This part replaces 27-7110. Price: $26.73 |
| 8 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 9 |
596140201 |
Washers This part replaces 819131614. Price: $2.99 |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT This part replaces 532174894. Price: $17.99 |
| 10 |
62-6300 |
SLEEVE ASM Price: $31.93 |
| 11 |
33-1270 |
BOWL-CLEAR Price: $10.91 |
| 11 |
532166369 |
KNOB.SEAT.ADJ.WINGNUT Price: $6.99 |
| 12 |
33-1260 |
COVER ASM Price: $36.59 |
| 12 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT.BLACK This part replaces 532121246. Price: $8.99 |
| 13 |
43-3810-03 |
TUBE-CLEANER, AIR This part replaces 43-3810. Price: $89.59 |
| 13 |
532121248 |
BUSHING Price: $4.99 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $4.99 |
| 15 |
532134300 |
SPACER SPLIT 28X.96 Price: $3.99 |
| 16 |
532121250 |
SPRING Price: $3.99 |
| 17 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 22 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 24 |
819171912 |
WASHER Price: $3.99 |
