| Ref | Part Number | Description |
|---|
| 1 |
140044X428 |
Wheel Steering Ayp/P/L Blk Price: Call Us |
| 1 |
3220-2 |
NUT-JAM Price: $0.50 |
| 2 |
175131 |
Axle Asm Price: Call Us |
| 2 |
76-7010 |
RING-RETAINING This part replaces 60-6260. Price: $3.66 |
| 3 |
169840 |
Spindle Asm LH Price: Call Us |
| 3 |
76-7000 |
RING-RETAINING Price: $7.46 |
| 4 |
169839 |
Spindle Asm RH Price: Call Us |
| 4 |
94-3027 |
WASHER-SEAL Price: $32.38 |
| 5 |
6266H |
Bearing Race Thrust Harden Price: Call Us |
| 5 |
93-6337 |
SCREW Price: $9.77 |
| 6 |
121748X |
Washer 25/32 X 1-5/8 X 16 Ga Price: Call Us |
| 6 |
99-8701 |
ROTATING KIT This part replaces 93-6322. Price: $1,722.95 |
| 7 |
105-2856 |
PISTON-SERVO Price: $739.56 |
| 7 |
19272016 |
Washer 27/32 X 1-1/4 X 16 Ga Price: Call Us |
| 8 |
12000029 |
Ring Klip #t5304-75 Price: Call Us |
| 8 |
94-3032 |
FOLLOWER-PISTON Price: $574.71 |
| 9 |
3366R |
Bearing Col Strg Blk Price: Call Us |
| 9 |
94-3033 |
PLATE-COVER Price: $121.09 |
| 10 |
175121 |
Link Drag Price: Call Us |
| 10 |
93-6339 |
GASKET Price: $14.34 |
| 11 |
10040600 |
Washer, Lock Hvy. Hlcl. Spr. 3/8 Price: Call Us |
| 11 |
105-2900 |
GASKET-HOUSING Price: $46.30 |
| 12 |
105-2901 |
GASKET-HOUSING, CONTROL Price: $38.61 |
| 12 |
73940800 |
Nut Hex Jam Toplock 1/2-20 Unf Price: Call Us |
| 13 |
105-9853 |
PLATE-COVER This part replaces 94-3034. Price: $142.29 |
| 13 |
136518 |
Spacer earing Axle Front Price: Call Us |
| 14 |
94-3026 |
CAMPLATE ASM Price: $1,164.81 |
| 15 |
145212 |
Hex flange Lock Price: Call Us |
| 15 |
76-6950 |
RACE-THRUST Price: $25.65 |
| 16 |
76-6960 |
BEARING-THRUST This part replaces 60-6170. Price: $23.23 |
| 17 |
105-2858 |
VALVE-RELIEF Price: $1,100.81 |
| 17 |
180641 |
Shaft Asm Strg Price: Call Us |
| 19 |
323-15 |
SCREW-HH Price: $1.53 |
| 20 |
323-16 |
SCREW-HH Price: $2.89 |
| 21 |
93-6324 |
SCREW Price: $8.89 |
| 22 |
105-2902 |
PLATE-VALVE Price: $561.90 |
| 23 |
105-2903 |
HOUSING Price: $2,233.91 |
| 24 |
105-8149 |
ENDCOVER ASM Price: $1,565.24 |
| 25 |
94-3020 |
SHAFT-DRIVE Price: $627.17 |
| 26 |
105-2905 |
O-RING Price: $26.38 |
| 26 |
126847X |
Bushing Link Drag Blk LR Price: Call Us |
| 27 |
3217-5 |
NUT-HEX Price: $0.25 |
| 28 |
19131416 |
Washer 13/32 X 7/8 X 16 Ga Price: Call Us |
| 28 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 29 |
17060612 |
Screw 3/8-16 x 3/4 Price: Call Us |
| 29 |
60-6240 |
WASHER This part replaces 94-3007. Price: $15.20 |
| 30 |
105-2906 |
DISCONTINUED(ORDER KIT 107-4445) Price: Call Us |
| 30 |
76020412 |
Pin Cotter 1/8 X 3/4 Cad Price: Call Us |
| 31 |
105-3331 |
SEAL-SHAFT Price: $35.63 |
| 32 |
105-2907 |
CHARGE PUMP ADAPTER ASM Price: $1,126.94 |
| 32 |
130465 |
Rod Tie Wire Form 19 75 Mech Price: Call Us |
| 33 |
94-3031 |
ARM-CONTROL Price: $32.40 |
| 34 |
93-6306 |
CONTROL ASM Price: $1,822.55 |
| 35 |
105-2908 |
DISCONTINUED Price: Call Us |
| 36 |
107-4445 |
DISCONTINUED This part replaces 99-8707. Price: $568.49 |
| 36 |
155099 |
Bushing Strg 5/8 Id Dash Price: Call Us |
| 37 |
105-2909 |
ORIFICE-CONTROL, .036 DIA Price: $20.39 |
| 37 |
152927 |
Screw Price: Call Us |
| 38 |
105-2910 |
ORIFICE-VALVE, CONTROL Price: $42.23 |
| 38 |
140045X428 |
Cap Wheel Steer Ayp Price: Call Us |
| 39 |
19183812 |
Washer 9/16 ID X 2-3/8 OD 12 Ga Price: Call Us |
| 40 |
105-2911 |
DISCONTINUED(ORDER KIT 107-4445) Price: Call Us |
| 40 |
7810H |
Nut Lock Center 3/8-24un Price: Call Us |
| 41 |
100711L |
Adaptor Wheel Strg Price: Call Us |
| 41 |
105-2912 |
RING-RETAINING Price: $23.48 |
| 42 |
105-2913 |
VALVE-BYPASS Price: $91.51 |
| 42 |
145054X428 |
Boot Dash Mtl Steering Blk Price: Call Us |
| 43 |
121749X |
Washer 25/32 X 1 1/4 X 16 Ga Price: Call Us |
| 43 |
94-3030 |
WASHER Price: $6.24 |
| 44 |
180640 |
Extension Steering Price: Call Us |
| 44 |
93-6336 |
WASHER Price: $3.19 |
| 46 |
121232X |
Cap Spindle Fr Top Blk Price: Call Us |
| 47 |
183226 |
Fitting Grease Price: Call Us |
| 51 |
73540400 |
Nut Crownlock 1/4-28 Price: Call Us |
| 54 |
71130420 |
Bolt Hex 1/4-28unf x 1-1/4 Gr.8 Price: Call Us |
| 65 |
160367 |
Spacer Brace Axle Price: Call Us |
| 67 |
72140618 |
Bolt Fin Hex 5/8-11 unc x 2-3/4 Price: Call Us |
| 68 |
169827 |
Brace Axle Price: Call Us |
| 71 |
175146 |
Steering Asm. Price: Call Us |
| 82 |
169835 |
Bracket Susp Chassis Front Price: Call Us |
| 85 |
133835 |
Fastener Christmas Tree Price: Call Us |
| 88 |
175118 |
Bolt Shoulder 7/16-20 Price: Call Us |
