| Ref | Part Number | Description |
|---|
| A |
530027432 |
Safety Label Decal (Upper) Price: $3.33 |
| B |
530027433 |
Safety Label Decal (Lower) Price: $3.33 |
| C |
530027348 |
Shield Warning Decal Price: $3.33 |
| 1 |
3296-33 |
NUT-LOCK, NI Price: $2.39 |
| 1 |
530071781 |
GEAR BOX REPLACEMENT KIT This part replaces 530094568. Price: $74.99 |
| 1 |
530094495 |
XR-105 Price: $99.99 |
| 2 |
3256-7 |
WASHER-FLAT Price: $0.75 |
| 2 |
530094206 |
Washer Price: $3.33 |
| 3 |
20-4070 |
DISCONTINUED Price: Call Us |
| 3 |
530094449 |
Lockwasher Price: $3.33 |
| 4 |
325-5 |
SCREW-HH Price: $1.20 |
| 4 |
530094208 |
Screw Price: $3.33 |
| 5 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 5 |
530094205 |
Screw Price: $3.33 |
| 6 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 6 |
530094499 |
Line Limiter Price: $3.33 |
| 7 |
20-4030 |
DISCONTINUED Price: Call Us |
| 7 |
530094485 |
Screw Price: $3.33 |
| 8 |
3272-2 |
PIN-COTTER Price: $2.29 |
| 8 |
530091582 |
Washer Price: $3.33 |
| 9 |
20-4190 |
ACTUATOR LINK Price: $31.04 |
| 10 |
3290-250 |
PIN-COTTER Price: $5.59 |
| 10 |
530093984 |
Upper Adaptor Price: $27.99 |
| 11 |
3290-256 |
PIN-HAIR Price: $1.01 |
| 11 |
530093985 |
Lower Adaptor Price: $11.99 |
| 12 |
323-4 |
SCREW-HH Price: $1.02 |
| 13 |
5-1720 |
WASHER Price: $2.24 |
| 13 |
530094496 |
XR-105 Price: $22.99 |
| 13 |
530094594 |
XR-125 Price: $3.33 |
| 14 |
20-4230 |
DISCONTINUED Price: Call Us |
| 14 |
530015539 |
Screw Price: $1.99 |
| 15 |
20-3980 |
DISCONTINUED Price: Call Us |
| 15 |
530015328 |
Washer Price: $1.99 |
| 16 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 16 |
530001543 |
Nut Price: Call Us |
| 17 |
325-2 |
SCREW-HH Price: $1.02 |
| 18 |
323-7 |
SCREW-HH Price: $0.65 |
| 18 |
530094417 |
Shoulder Strap Price: $20.65 |
| 19 |
3217-7 |
NUT-HEX Price: $0.28 |
| 19 |
530092231 |
Shoulder Strap Key Ring Price: $1.99 |
| 20 |
20-3970 |
DISCONTINUED Price: Call Us |
| 20 |
530094487 |
Screw Price: $3.33 |
| 21 |
256-156 |
BUSHING-FLANGE Price: $12.99 |
| 21 |
530069496 |
Cushioned Assist Handle Kit, GTI 16 SUPER, GTI 17LE, GTI 16D & GTI 16 Type 3 This part replaces 530010618. Price: $14.99 |
| 22 |
3272-7 |
PIN-COTTER Price: $0.25 |
| 22 |
530091373 |
Wing Nut "D" Handle Price: $1.99 |
| 23 |
20-4200 |
DISCONTINUED Price: Call Us |
| 23 |
530092062 |
Washer Price: $1.99 |
| 24 |
20-4090 |
DISCONTINUED Price: Call Us |
| 24 |
530015737 |
Screw Price: $3.33 |
| 25 |
325-4 |
SCREW-HH Price: $0.95 |
| 25 |
530001642 |
Lockwasher Price: $1.99 |
| 26 |
20-4020 |
DISCONTINUED Price: Call Us |
| 26 |
530001711 |
Screw Price: $1.99 |
| 27 |
530016107 |
Screw This part replaces 530015790. Price: $1.99 |
| 28 |
530403094 |
Nut This part replaces 530015653. Price: $1.99 |
| 29 |
530094612 |
Screw Price: $0.99 |
| 30 |
530094616 |
Screw Price: Call Us |
| 31 |
530015037 |
Screw Price: $1.99 |
| 32 |
530027682 |
Drive Shaft Hsg. Grip Price: $3.33 |
| 33 |
530010959 |
Throttle Control Ass'y. Price: $6.99 |
| 34 |
530015768 |
Nut Price: $1.99 |
| 35 |
530015774 |
Screw Price: $1.99 |
| 36 |
530015197 |
Nut Price: $1.99 |
| 37 |
530094686 |
Clamp Harness Ass'y. This part replaces 530094598. Price: $4.99 |
| 38 |
530094443 |
XR-105 Price: $3.33 |
| 38 |
530094566 |
XR-125 Price: $54.99 |
| 39 |
530094454 |
XR-105 Price: $74.99 |
| 39 |
530094611 |
XR-125 Price: $3.33 |
| 40 |
530094430 |
Cutting Hd. Ass'y. (Inc.#41-48) XR-105 Price: $39.99 |
| 41 |
530071295 |
Hub This part replaces 530093896. Price: $14.99 |
| 42 |
530093898 |
Line Saver Price: $3.99 |
| 43 |
530340007 |
Spring This part replaces 530092067. Price: $1.99 |
| 44 |
530328929 |
Cap Spring This part replaces 530092068. Price: $1.99 |
| 45 |
530094429 |
Drive Gear Price: $3.33 |
| 46 |
952701589 |
Spool w/Line Price: $5.95 |
| 47 |
530401183 |
Tap Button This part replaces 530093387. Price: $2.99 |
| 48 |
530092133 |
Cover Price: $5.99 |
| 49 |
530092258 |
Wrench Price: $3.33 |
| 50 |
530094570 |
Line Limiter Price: $1.99 |
| 51 |
530094640 |
Seal Price: $6.94 |
| 52 |
530094639 |
Dust Cup Price: $7.99 |
| 53 |
530094571 |
Grass Washer Price: $1.99 |
| 54 |
952711550 |
Accy--Cutting Head This part replaces 530094557. Price: $18.95 |
| 55 |
952701607 |
Spool w/Line Price: Call Us |
| 56 |
530094494 |
Cover Price: $4.99 |
| 57 |
952701608 |
Cutting Head Ass'y. (Inc. #54- 56)-Model XR-125 Price: $1.00 |
| 58 |
530069256 |
Shield Kit Ass'y. Price: $9.99 |
| 59 |
530069347 |
HANDLE KIT This part replaces 530069252. Price: $4.99 |
