| Ref | Part Number | Description |
|---|
| 1 |
144393 |
DECK.WELD.42. Price: Call Us |
| 1 |
32121-10 |
PIN-ROLL Price: $6.99 |
| 2 |
72140506 |
BOLT Price: Call Us |
| 2 |
74-5790 |
SHAFT-PIVOT Price: $75.26 |
| 3 |
138017 |
BRKT ASM SWAY BAR Price: Call Us |
| 3 |
32121-123 |
PIN-ROLL Price: $0.81 |
| 4 |
10-8110 |
WASHER-THRUST Price: $1.09 |
| 4 |
138440 |
BRKT DECK SW BAR Price: Call Us |
| 5 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 5 |
4939M |
SUB= 85902 Price: Call Us |
| 6 |
130832 |
SUB= 130833 Price: Call Us |
| 6 |
2411-36 |
BEARING-END, ROD Price: $32.13 |
| 7 |
3220-3 |
NUT-HJ Price: $0.28 |
| 8 |
233-17 |
KNOB Price: $10.58 |
| 8 |
850857 |
BLADE BOLT Price: Call Us |
| 9 |
10030600 |
SUB= 10040600 Price: Call Us |
| 9 |
72-0130 |
DISCONTINUED Price: Call Us |
| 10 |
107-2561 |
NUT-HEX This part replaces 47-6990. Price: $14.65 |
| 10 |
140296 |
WASHER.HARD.BLADE Price: Call Us |
| 11 |
68-8080 |
WHEEL-STEERING Price: $273.84 |
| 12 |
129895 |
BEARING.BALL Price: Call Us |
| 12 |
32144-4 |
SCREW-HWH Price: $1.29 |
| 13 |
137645 |
SUB= 137646 Price: Call Us |
| 13 |
93-9415 |
PANEL-CONTROL, TOWER Price: $68.85 |
| 14 |
128774 |
HSG ASM MANDREL Price: Call Us |
| 14 |
76-9450 |
DISCONTINUED Price: Call Us |
| 15 |
110485X |
BEARING Price: Call Us |
| 15 |
32144-11 |
SCREW-THD ROLL, HWH Price: $6.99 |
| 16 |
140329 |
STRIPPER RND MWR Price: Call Us |
| 16 |
323-8 |
SCREW-HH Price: $1.20 |
| 17 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 17 |
72110610 |
BOLT RDHD 3/8-16 Price: Call Us |
| 18 |
72140505 |
BOLT Price: Call Us |
| 18 |
95-1821 |
SPRING-COMPRESSION This part replaces 95-1821-03. Price: $6.71 |
| 19 |
132827 |
BOLT SHD 5/16-18 Price: Call Us |
| 19 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 20 |
136888 |
SUB= 918136888 Price: Call Us |
| 20 |
69-1560-03 |
DISCONTINUED Price: Call Us |
| 21 |
3272-5 |
PIN-COTTER Price: $1.39 |
| 21 |
73680500 |
SUB= 73690500 Price: Call Us |
| 22 |
134753 |
STIFFENER BRKT Price: Call Us |
| 22 |
76-9050 |
ROD-BRAKE, PARK Price: $33.40 |
| 23 |
131267 |
DEFLECTOR BRKT Price: Call Us |
| 23 |
84-0680 |
LINK-SHIFT V Price: $32.00 |
| 24 |
105304X |
CAP-SLEEVE LT Price: Call Us |
| 24 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 25 |
123713X |
SPRING TORSION Price: Call Us |
| 25 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 26 |
110452X |
NUT PUSH M Price: Call Us |
| 26 |
63-7900-03 |
RACK Price: $144.55 |
| 27 |
130968 |
DEFLECTOR.SHIELD Price: Call Us |
| 27 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 28 |
19111016 |
WASHER Price: Call Us |
| 28 |
20-9500 |
WASHER Price: $3.53 |
| 29 |
131491 |
HINGE ROD Price: Call Us |
| 29 |
83-0740 |
DISC-FRICTION Price: $12.57 |
| 30 |
76-8340 |
SHAFT-PIVOT, STEERING Price: $89.60 |
| 31 |
129963 |
WASHER Price: Call Us |
| 31 |
2410-64 |
PLUG-BUTTON Price: $0.74 |
| 32 |
153535 |
PULLEY.MANDREL.42 Price: Call Us |
| 32 |
76-8150-03 |
SUPPORT-SHAFT, STEERING Price: $25.87 |
| 33 |
137266 |
SUB= 139729 Price: Call Us |
| 33 |
92-9729 |
DISCONTINUED Price: Call Us |
| 34 |
340-138 |
FITTING-HYD, 45 DEG Price: $31.15 |
| 34 |
72110614 |
BOLT Price: Call Us |
| 35 |
133835 |
XMAS TREE FASTNER Price: Call Us |
| 35 |
86-3210 |
DISCONTINUED Price: Call Us |
| 36 |
131494 |
FLAT IDLER PULLEY Price: Call Us |
| 36 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 37 |
19131316 |
WASHER Price: Call Us |
| 37 |
59-6430 |
DISCONTINUED Price: Call Us |
| 38 |
86-5570 |
HOSE ASM Price: $151.86 |
| 39 |
86-3220 |
HOSE ASM Price: $68.45 |
| 40 |
73680600 |
SUB= 73690600 Price: Call Us |
| 40 |
76-8140-03 |
BRACKET-GEAR, STEERING Price: $70.53 |
| 41 |
133551 |
PIVOT ROD Price: Call Us |
| 41 |
76-8160-03 |
SUPPORT-GEAR, STEERING Price: $25.24 |
| 42 |
323-6 |
SCREW-HH Price: $0.66 |
| 43 |
140083 |
ROD CLUTCH W/NIBS Price: Call Us |
| 43 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 44 |
140088 |
GUARD MAND LH BLK Price: Call Us |
| 44 |
74-3670 |
DISCONTINUED Price: Call Us |
| 45 |
4497H |
RETAINER M Price: Call Us |
| 45 |
76-9100 |
SPACER Price: $4.07 |
| 46 |
137729 |
SCREW.1/4-20X5/8 Price: Call Us |
| 46 |
82-4950 |
PLUNGER-SPRING Price: $145.10 |
| 47 |
74-5770-03 |
DISCONTINUED Price: Call Us |
| 48 |
104-7415 |
DISCONTINUED Price: Call Us |
| 48 |
133944 |
HARD SMALL WASHER Price: Call Us |
| 49 |
155066 |
ROLLER ASM-CAM Price: Call Us |
| 49 |
21-9260 |
COVER-DUST Price: $8.19 |
| 50 |
131340 |
SHOULDER BOLT Price: Call Us |
| 50 |
340-70 |
NUT-LOCK Price: $2.10 |
| 51 |
340-71 |
FITTING-STRAIGHT, BULKHEAD Price: $20.74 |
| 51 |
69180 |
LOCKNUT Price: Call Us |
| 52 |
139888 |
BOLT.SHLD.5/16-18 Price: Call Us |
| 52 |
2412-74 |
R-CLAMP Price: $2.37 |
| 53 |
131845 |
BRAKE PAD ARM ASM Price: Call Us |
| 53 |
340-159 |
FITTING-HYD, 90 DEG Price: $55.33 |
| 54 |
133943 |
HARDENED WASHER Price: Call Us |
| 54 |
32144-57 |
SCREW Price: $1.04 |
| 55 |
155046 |
ARM-IDLER Price: Call Us |
| 55 |
3256-71 |
WASHER-FLAT Price: $0.81 |
| 56 |
122052X |
SPACER RETAINER Price: Call Us |
| 56 |
56-7973 |
CLAMP-TUBE Price: $15.56 |
| 57 |
94-8299 |
STEERING TUBE ASM Price: $135.28 |
| 58 |
140086 |
SPRING TORSN BRAK Price: Call Us |
| 58 |
86-5730 |
RH FRONT TUBE ASM Price: $85.91 |
| 59 |
141043 |
GUARD IDLER TUV Price: Call Us |
| 59 |
86-5740 |
LH FRONT TUBE ASM Price: $126.12 |
| 60 |
2412-104 |
CLAMP-R Price: $2.37 |
| 61 |
2412-147 |
CLAMP-R Price: $2.51 |
| 62 |
29-6163 |
SWITCH-MICRO Price: $91.23 |
| 63 |
3249-11 |
SCREW-MACHINE Price: $0.54 |
| 67 |
106932X |
KNOB T(3/8 HOLE) Price: Call Us |
| 68 |
144200 |
BELT.V.T-PATH Price: Call Us |
| 71 |
142427 |
ROD CLUTCH 38/42 Price: Call Us |
| 72 |
131870 |
RETURN SPRING Price: Call Us |
| 73 |
127847 |
CLUTCH ARM SECOND Price: Call Us |
| 74 |
121748X |
WASHER Price: Call Us |
| 75 |
12000029 |
RING Price: Call Us |
| 76 |
128903 |
SHOULDER BOLT Price: Call Us |
| 77 |
127845 |
SPRING KEEPER Price: Call Us |
| 78 |
154809 |
LEVER ASM-CLUTCH Price: Call Us |
| 79 |
127498 |
BUSHING Price: Call Us |
| 80 |
153701 |
SPRING.CLUTCH.MWR Price: Call Us |
| 81 |
73350600 |
NUT Price: Call Us |
| 82 |
142028 |
TRUNION ADJ Price: Call Us |
| 83 |
120958X |
WASHER Price: Call Us |
| 85 |
72140618 |
BOLT RDHD 3/8-16 Price: Call Us |
| 92 |
73800600 |
NUT Price: Call Us |
| 102 |
71161010 |
SCREW Price: Call Us |
| 103 |
19061216 |
WASHER #10 Price: Call Us |
| 104 |
10071000 |
LOCKWASHER Price: Call Us |
| 105 |
130758 |
SUB= 160793 Price: Call Us |
| 106 |
2029J |
WELDNUT Price: Call Us |
| 111 |
155197 |
BRACKET.GWHL.LH. Price: Call Us |
| 112 |
155198 |
BRACKET.GWHL.RH. Price: Call Us |
| 113 |
17490512 |
SCREW Price: Call Us |
| 114 |
73510500 |
NUT Price: Call Us |
| 115 |
72110504 |
SUB= 872110504 Price: Call Us |
| 116 |
4898H |
BOLT M Price: Call Us |
| 117 |
105455X |
WHEEL.GAGE.BLK.PL Price: Call Us |
| 118 |
73930600 |
LOCKNUT Price: Call Us |
| 119 |
19121414 |
WASHER Price: Call Us |
| 120 |
19171512 |
WASHER Price: Call Us |
| 121 |
143723 |
BRACKET.EXTRD.GWL Price: Call Us |
| 128 |
153390 |
WASHER.FELT. Price: Call Us |
| 132 |
19132203 |
WASHER GT Price: Call Us |
| 130794 |
MANDREL |
ASM Price: Call Us 130794 |
