| Ref | Part Number | Description |
|---|
| 2 |
139-8416 |
FITTING-STRAIGHT Price: $25.31 |
| 5 |
133-5797-03 |
FRAME-ENGINE Price: $405.15 |
| 6 |
323-12 |
SCREW-HH Price: $1.14 |
| 9 |
127-2580 |
GENERATOR/CONTROLLER ASM Price: $7,179.45 |
| 10 |
137-8128 |
PULLEY-BELT Price: $243.19 |
| 11 |
5-0698 |
KEY Price: $2.30 |
| 12 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 13 |
3241-6 |
SCREW-SQH Price: $4.80 |
| 14 |
1-653313 |
GASKET-EXHAUST Price: $4.29 |
| 15 |
133-5745 |
MUFFLER Price: $344.77 |
| 16 |
133-5750 |
PIPE-EXHAUST, LH Price: $68.59 |
| 17 |
133-5751 |
PIPE-EXHAUST, RH Price: Call Us |
| 18 |
137-7828 |
BELT-TIMING Price: $74.55 |
| 19 |
137-8131 |
PULLEY ASM Price: $245.66 |
| 20 |
133-5737 |
BRACKET-SPRING Price: $14.29 |
| 21 |
114-4681 |
SCREW-HHF Price: $0.89 |
| 22 |
63-8410 |
WASHER Price: $1.76 |
| 23 |
133-0332 |
PIN-ADJUSTMENT, GENERATOR Price: $40.24 |
| 24 |
133-5738 |
SPRING-EXTENSION Price: $24.74 |
| 26 |
3211-4 |
SCREW-HH Price: $1.02 |
| 27 |
323-10 |
SCREW-HH Price: $0.89 |
| 28 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 29 |
104-7201 |
NUT-HF Price: $0.69 |
| 30 |
32105-18 |
SCREW-HHF Price: $0.47 |
| 32 |
104-4090 |
CLAMP-MUFFLER Price: $6.00 |
| 33 |
132-9908 |
SHIELD-DRIP Price: $36.83 |
| 34 |
119-8502 |
HOSE-VENT, FORMED Price: $3.72 |
| 35 |
119-8501 |
HOSE-VENT, FORMED Price: $3.72 |
| 36 |
110-5701 |
HOSE-FUEL Price: $14.62 |
| 37 |
116-2232 |
VALVE-CONTROL, VACUUM Price: $16.75 |
| 40 |
114-3550 |
WASHER-LOCK Price: $0.81 |
| 42 |
132-9915-03 |
SHIELD-EXHAUST, REAR Price: $45.69 |
| 43 |
114-3549 |
NUT Price: $2.02 |
| 44 |
3290-465 |
WASHER-BELLEVILLE Price: $2.89 |
| 45 |
132-9947 |
SCREW-HFH Price: $5.56 |
| 46 |
27-0410 |
SCREW-SHOULDER Price: $2.59 |
| 47 |
67-7490 |
KEY-SQUARE Price: $2.30 |
| 48 |
3220-3 |
NUT-HJ Price: $0.28 |
| 49 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 50 |
121-9076 |
MOUNT-ENGINE Price: $37.76 |
| 51 |
3234-29 |
SCREW-HHF Price: $1.84 |
| 52 |
131-1821 |
MOUNT-ENGINE Price: $105.39 |
| 53 |
3234-25 |
SCREW-HHF Price: $7.69 |
| 55 |
92-5753 |
CLAMP-HOSE Price: $2.10 |
| 56 |
137-7864 |
DRAIN HOSE ASM Price: $58.70 |
| 57 |
120-4654 |
SCREW-HHF Price: $0.34 |
| 58 |
2412-106 |
CLAMP-R Price: $2.04 |
| 60 |
3290-379 |
TIE-CABLE Price: $0.31 |
| 61 |
3256-67 |
WASHER Price: $0.49 |
| 62 |
139-8415 |
TUBING-CONVOLUTED, SLIT Price: $6.72 |
