| Ref | Part Number | Description |
|---|
| 1 |
3-6430 |
TONGUE MEMBER WA Price: $561.73 |
| 1 |
532186094 |
STEERING WHEEL.PREM.2.BLK This part replaces 532193651. Price: $169.99 |
| 2 |
325-10 |
SCREW-HH Price: $1.82 |
| 2 |
532193542 |
AXLE.ASM.LT.CAST.LGHTWGHT This part replaces 532184706. Price: $119.99 |
| 3 |
12-0190 |
DISCONTINUED Price: Call Us |
| 3 |
596873901 |
KIT SPINDLE ASM.PNT.LH.15 This part replaces 532169840. Price: $14.99 |
| 4 |
4-8569 |
DISCONTINUED Price: Call Us |
| 4 |
596873801 |
KIT SPINDLE ASM.PNT.RH.15" This part replaces 532169839. Price: $27.99 |
| 5 |
32153-5 |
NUT-HEX Price: $1.59 |
| 6 |
5-1116-01 |
DISCONTINUED This part replaces 5-1116. Price: Call Us |
| 6 |
532121748 |
WASHER Price: $3.99 |
| 7 |
325-6 |
SCREW-HH Price: $1.42 |
| 8 |
323-6 |
SCREW-HH Price: $0.66 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
12-0030 |
DISCONTINUED Price: Call Us |
| 10 |
532175121 |
DRAGLINK.15".TIRES.2001 Price: $59.99 |
| 10 |
6-0860 |
TRLG&3UNIT DRAWBAR WA*R Price: $840.26 |
| 11 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 11 |
603773 |
LOCKNUT This part replaces 32153-2. Price: $2.09 |
| 12 |
12-0010 |
U BOLT W.A. Price: $81.76 |
| 13 |
48669 |
Drawbar (Incl. Ref. #33) Price: Call Us |
| 13 |
532136518 |
TUBE, PIVOT AXLE Price: $7.99 |
| 14 |
323-7 |
SCREW-HH Price: $0.65 |
| 15 |
323-5 |
SCREW-HH Price: $0.41 |
| 15 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
| 16 |
5-1092 |
DISCONTINUED Price: Call Us |
| 17 |
5-1093 |
DISCONTINUED Price: Call Us |
| 17 |
532190753 |
SHAFT STEERING SPLINE Price: $37.99 |
| 18 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 19 |
5-1094 |
FORK *R Price: $31.80 |
| 20 |
5-9390 |
LIFT HANDLE *B Price: $45.72 |
| 21 |
3-7877 |
GRIP-HANDLE Price: $10.69 |
| 22 |
287-2 |
DISCONTINUED Price: Call Us |
| 23 |
5-1096 |
CHAIN-LIFT Price: $18.82 |
| 24 |
3272-16 |
PIN-COTTER Price: $0.31 |
| 25 |
283-15 |
PIN-CLEVIS Price: $4.07 |
| 26 |
5-2942 |
SHACKLE Price: $16.99 |
| 27 |
325-4 |
SCREW-HH Price: $0.95 |
| 28 |
12-0120 |
DISCONTINUED Price: Call Us |
| 29 |
3-7254-01 |
DRAW BAR BRACKET This part replaces 3-7254. Price: $227.92 |
| 29 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 30 |
32121-15 |
PIN-ROLL Price: $1.60 |
| 31 |
5-1091 |
SPACER Price: $4.98 |
| 32 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 32 |
532171888 |
TIE ROD Price: $59.99 |
| 33 |
5-1111 |
CASTOR WHEEL BUSHING Price: $10.11 |
| 33 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111216. Price: $2.99 |
| 34 |
5-1112 |
DRAWBAR PIN Price: $9.77 |
| 34 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 35 |
12-0060 |
DISCONTINUED Price: Call Us |
| 35 |
873540500 |
NUT, CROWNLOCK Price: $3.99 |
| 36 |
5-1105-01 |
HINGE-BALL, LH This part replaces 5-1105. Price: $57.25 |
| 36 |
532155106 |
KIT.BUSHING.STEERING This part replaces 532155099. Price: $8.99 |
| 37 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 37 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 38 |
325-5 |
SCREW-HH Price: $1.20 |
| 38 |
532193652 |
INSERT.CAP.STRG.WH.GRAY Price: $11.99 |
| 39 |
5-1103-01 |
SOCKET ASM-HINGE, LH This part replaces 5-1103. Price: $146.47 |
| 39 |
596040001 |
Washers This part replaces 819113812. Price: $6.99 |
| 40 |
5-1107-01 |
HINGE CAP ASM This part replaces 5-1107. Price: $161.71 |
| 40 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 41 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 41 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 42 |
5-1108 |
BOLT-HINGE CLAMP Price: $42.89 |
| 42 |
532145054 |
STEERING BOOT, GRAY This part replaces 532169634. Price: $11.99 |
| 43 |
3272-38 |
PIN-COTTER Price: $3.05 |
| 43 |
532121749 |
WASHER Price: $2.99 |
| 44 |
3-6440 |
DISCONTINUED Price: Call Us |
| 44 |
532190752 |
SHAFT.EXTEN.STRG.SPLINE Price: $11.99 |
| 45 |
325-9 |
SCREW-HH Price: $1.87 |
| 46 |
5-1088 |
DISCONTINUED Price: Call Us |
| 46 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 47 |
5-1087 |
DISCONTINUED Price: Call Us |
| 48 |
3290-256 |
PIN-HAIR Price: $1.01 |
| 49 |
5-1085 |
DRAWBAR COUPLER *R Price: $231.54 |
| 65 |
532414736 |
SPACER.BRACE.AXLE This part replaces 532160367. Price: $5.99 |
| 67 |
872110618 |
BOLT CARRIAGE Price: $4.99 |
| 68 |
531167401 |
SERVICE KIT BRACE.AXLE.1 This part replaces 532169827. Price: $19.99 |
| 71 |
531167801 |
SERVICE KIT STEERING ASM This part replaces 532175146. Price: $139.99 |
| 82 |
531170201 |
SERVICE.KIT BRACKET This part replaces 532169835. Price: $19.99 |
| 87 |
532173966 |
WASHER, FLAT .781 X 1 1/2" Price: $4.99 |
| 88 |
532175118 |
BOLT, SHOULDER 7/16-20 Price: $4.99 |
| 91 |
532175553 |
CLIP.STEERING Price: $9.99 |
| 95 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 97 |
874780564 |
BOLT Price: $4.99 |
