94CM CUTTING DECK
Parts (59)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 132-6259-0P | SWITCH MOUNT ASM This part replaces 132-6259-03. Price: $105.94 |
| 2 | 117-5458 | SCREW-HHF Price: $0.22 |
| 3 | 99-3410 | SWITCH Price: $95.63 |
| 4 | 108-9824 | NUT-SWITCH Price: $1.97 |
| 5 | 3256-23 | WASHER-PLAIN Price: $0.28 |
| 6 | 32144-69 | SCREW-HWHTF Price: $1.58 |
| 7 | 2412-4 | CLAMP-R Price: $4.22 |
| 8 | 256-236 | BEARING-MOUNT, FLANGE Price: $27.99 |
| 9 | 120-8899 | CABLE-BRAKE, LH Price: $97.43 |
| 10 | 322-13 | SCREW-HH Price: $2.73 |
| 11 | 132-6290-0P | RACK ASM This part replaces 132-6290-03. Price: $114.51 |
| 12 | 3256-69 | WASHER-FLAT Price: $0.62 |
| 13 | 63-7880 | PIN-LATCH, BRAKE Price: $6.04 |
| 14 | 32121-50 | PIN-SPRING Price: $1.21 |
| 15 | 93-8742 | FOOTPAD-BRAKE Price: $27.95 |
| 16 | 132-6288-01 | PEDAL-BRAKE, LH Price: $132.21 |
| 17 | 120-8898 | CABLE-BRAKE, RH Price: $104.62 |
| 18 | 94-3088 | SPRING-COMPRESSION Price: $8.24 |
| 19 | 120-9694 | PIN-CLEVIS Price: $2.17 |
| 21 | 132-6252 | PEDAL-BRAKE, RH Price: $122.77 |
| 22 | 3272-6 | PIN-COTTER Price: $0.25 |
| 23 | 104-8300 | NUT-HF, NI Price: $0.39 |
| 24 | 3231-21 | SCREW-CARR Price: $0.76 |
| 25 | 94-3050 | PLATE-SPRING Price: $7.88 |
| 29 | 3230-23 | SCREW-CARR Price: $0.89 |
| 30 | 132-6247-01 | MOUNT-BEARING Price: $13.60 |
| 31 | 121-4600 | NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 32 | 137-1632 | HUB-BRAKE This part replaces 132-6229. Price: $43.71 |
| 33 | 4-2390 | WASHER-FLAT Price: $0.62 |
| 34 | 32121-125 | PIN-SPRING Price: $0.54 |
| 35 | 104-8301 | NUT-HF, NI Price: $1.09 |
| 36 | 88-7970 | CLIP Price: $2.51 |
| 40 | 544220701 | Price: Call Us |
| 41 | 544225901 | NEEDS DESCRIPTION Price: Call Us |
| 42 | 506869601 | BEARING Price: $8.99 |
| 43 | 506813801 | PLATE Price: $5.99 |
| 44 | 578856101 | Price: Call Us |
| 47 | 725246151 | BOLT Price: $4.99 |
| 48 | 732211801 | LOCKNUT M8 Price: $3.99 |
| 49 | 544226901 | Price: Call Us |
| 50 | 544451401 | Price: Call Us |
| 51 | 544451501 | Price: Call Us |
| 52 | 506897601 | NUT Price: $3.99 |
| 53 | 731232001 | Nut This part replaces 731232051. Price: $3.99 |
| 54 | 578177801 | Price: Call Us |
| 55 | 544213901 | Price: Call Us |
| 56 | 544214101 | SPRING Price: $2.99 |
| 57 | 735311320 | E-RING Price: $2.99 |
| 59 | 732211801 | LOCKNUT M8 Price: $3.99 |
| 60 | 506963001 | DECK ROLLER, FRONT Price: $54.99 |
| 61 | 535464101 | WASHER Price: $3.99 |
| 62 | 735311700 | RETAINING RING SGA 15 Price: $2.99 |
| 63 | 578176701 | Price: Call Us |
| 64 | 594020601 | Springs This part replaces 506976801. Price: $14.99 |
| 65 | 506992001 | BUSHING Price: $9.99 |
| 66 | 725246351 | SCREW This part replaces 725246051. Price: $4.99 |
| 67 | 734116441 | SPACER Price: $3.99 |
| 68 | 544362401 | COLLAR SCREW Price: $1.99 |
| 69 | 503894703 | CLIP GRAY Price: $9.99 |
