| Ref | Part Number | Description |
|---|
| 1 |
32152-10 |
LOCKNUT Price: $0.81 |
| 1 |
532850735 |
CONTROL BAR/BLACK This part replaces 532850758. Price: $4.69 |
| 2 |
585161003 |
GRIP.HANDLE.FOAM.438MM This part replaces 532850724. Price: $4.99 |
| 3 |
586122501 |
KIT.ROPE.GUIDE.T-KNOB This part replaces 532800357. Price: $7.99 |
| 4 |
532125161 |
HANDLE This part replaces 532125171. Price: $42.91 |
| 5 |
532157081 |
HANDLE.LOWER.BLACK This part replaces 532125173. Price: $54.99 |
| 6 |
532183724 |
KIT.KNOB.HANDLE.SERVICE This part replaces 532058714. Price: $9.99 |
| 7 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 532063601. Price: $1.99 |
| 8 |
532850733 |
BRACKET.UPSTOP This part replaces 532125162. Price: $4.99 |
| 9 |
817021008 |
SCREW This part replaces 532750097. Price: $3.99 |
| 10 |
532130861 |
CABLE.MZR.51.RT.SP./PU. This part replaces 532851809. Price: $10.99 |
| 11 |
874250434 |
SCREW.1/4-20.CROSS.RECESS. This part replaces 532085692. Price: $3.99 |
| 12 |
532051793 |
HAIRPIN COTTER Price: $5.99 |
| 13 |
532183724 |
KIT.KNOB.HANDLE.SERVICE This part replaces 532063688. Price: $9.99 |
| 14 |
532800627 |
HUBCAP Price: $2.38 |
| 15 |
532085179 |
RETAINER CLIP PM Price: $3.99 |
| 16 |
596040101 |
Washers This part replaces 532052160. Price: $2.99 |
| 17 |
532086884 |
Wheel & Tire Assembly 8.0 x 2.0 Price: Call Us |
| 18 |
532174719 |
BOLT SHOULDER 3/8 -16X1 This part replaces 532084921. Price: $7.99 |
| 19 |
532062335 |
WASHER.BELLEVILLE (3 2 LB) Price: $7.99 |
| 20 |
532125068 |
GRILL.PNT Price: $3.33 |
| 21 |
532077885 |
Selector Knob Price: Call Us |
| 22 |
532125079 |
SHAFT Price: $15.14 |
| 24 |
532088348 |
WASHER.FLAT.1/2 Price: $3.99 |
| 25 |
532401629 |
SPACER.HEIGHT.ADJUSTER This part replaces 532084920. Price: $3.99 |
| 26 |
532140058 |
BRACKET WHL ADJ This part replaces 532800370. Price: $4.99 |
| 27 |
532800368 |
WHL ADJ BRKT LF/RR Price: $5.99 |
| 28 |
532192983 |
KIT HANDLE BRACKET LH/RH This part replaces 532125047. Price: $27.99 |
| 29 |
581579101 |
DECAL.CUTFINGER.CE.02 This part replaces 532107339. Price: $3.99 |
| 30 |
532192983 |
KIT HANDLE BRACKET LH/RH This part replaces 532125049. Price: $27.99 |
| 31 |
596134901 |
GSPH This part replaces 532061537. Price: $2.99 |
| 32 |
596322601 |
Nuts This part replaces 532751592. Price: $2.99 |
| 33 |
532007192 |
WIRE TIE This part replaces 532066426. Price: $7.99 |
| 34 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 532055187. Price: $4.99 |
| 35 |
532851084 |
SCREW, HEX HD 3/8-24 X 1-3/8 Price: $2.50 |
| 36 |
596238701 |
Washers This part replaces 532850263. Price: $3.99 |
| 37 |
532851074 |
WASHER,HARDEN Price: $3.99 |
| 38 |
532145106 |
BLADE.20.MULCH.(50DK,6020MD) This part replaces 532129277. Price: $17.99 |
| 39 |
581547901 |
ADAPTOR.BLADE.7/8 This part replaces 532850977. Price: $14.99 |
| 40 |
532130665 |
SCREW Price: $3.33 |
| 41 |
532053998 |
WASHER Price: $3.71 |
| 42 |
532129404 |
Deflector Rod Price: Call Us |
| 43 |
532140544 |
REAR DEFLECTOR This part replaces 532751648. Price: $10.99 |
| 44 |
532700279 |
RETAINER CLIP Price: $2.99 |
| 45 |
532851461 |
THROTTLE CONTROL This part replaces 532851464. Price: $6.99 |
| 46 |
532085723 |
WASHER PM Price: $2.99 |
| 48 |
532107488 |
SCREW Price: $2.38 |
| 58875 |
Trim |
Plate Clips Price: Call Us 58875 |
| 62458 |
Trim |
Plate Rivets Price: Call Us 62458 |
| 800546 |
Trim |
Plate Price: Call Us 800546 |
| 532128431 |
Operator's |
Manual (French) Price: Call Us 532128431 |
| 532800569 |
ENG |
DECAL NLA Price: $2.52 532800569 |
| 532801607 |
OPER |
MANUAL NLA Price: $2.38 532801607 |
