| Ref | Part Number | Description |
|---|
| 1 |
302-55 |
FITTING-GREASE Price: $3.09 |
| 2 |
67-5480 |
SHAFT WITH CLEVIS Price: $194.96 |
| 3 |
67-5500 |
SEAL KIT Price: $144.97 |
| 4 |
67-5470 |
RING-SNAP Price: $8.82 |
| 5 |
67-5460 |
HEAD Price: $251.72 |
| 6 |
67-5450 |
PISTON Price: $202.80 |
| 501220001 |
501220001 |
SCREEN Price: $0.99 |
| 501220101 |
501220101 |
LOCKING RING Price: $0.69 |
| 501220201 |
501220201 |
PLUG (TIL 179-60X) Price: $2.25 |
| 501220301 |
501220301 |
Plug Price: $0.85 |
| 501220401 |
501220401 |
BALL Price: $11.99 |
| 501220501 |
501220501 |
SPRING Price: $3.99 |
| 501220801 |
501220801 |
GASKET, METERING SIDE Price: $3.99 |
| 501220901 |
501220901 |
METERING DIAPHRAGM Price: $14.99 |
| 501221001 |
501221001 |
CAP Price: $5.99 |
| 501221101 |
503486301 |
COVER SCREW This part replaces 501221101. Price: $3.99 |
| 501221201 |
501221201 |
FUEL PUMP DIAPHRAGM Price: $7.99 |
| 501221301 |
501221301 |
GASKET, PUMP SIDE Price: $3.99 |
| 501221401 |
501221401 |
CAP Price: $27.99 |
| 501221501 |
501221501 |
SCREW Price: $3.99 |
| 501221701 |
501221701 |
SPRING Price: $3.99 |
| 501222001 |
501222001 |
LEVER Price: $4.99 |
| 501222101 |
501222101 |
SHAFT Price: $6.99 |
| 501222201 |
501222201 |
SCREW Price: $1.30 |
| 501222401 |
578004601 |
FILTER This part replaces 501222401. Price: $0.99 |
| 501222501 |
501222501 |
SPRING Price: $3.99 |
| 501223001 |
503652701 |
SCREW This part replaces 501223001. Price: $4.99 |
| 501238801 |
503534001 |
NIPPLE This part replaces 501238801. Price: $14.99 |
| 501268501 |
501268501 |
IDLE ADJ. SCREW Price: $17.99 |
| 501268901 |
501268901 |
NEEDLE H Price: $6.99 |
| 501269001 |
501269001 |
SPRING Price: $4.99 |
| 501427101 |
501427101 |
Bushing Price: $1.00 |
| 501466701 |
503117001 |
VALVE/INLET. This part replaces 501466701. Price: $19.99 |
| 501485001 |
501485001 |
GASKET Price: $0.67 |
| 501494802 |
501494802 |
DIAPHRAGM SET Price: $17.99 |
| 501576101 |
501576101 |
CHOKE SHAFT AND LEVER Price: $9.99 |
| 501814401 |
501814401 |
THROTTLE SHAFT Price: $6.99 |
| 501815801 |
501815801 |
SPRING Price: $2.07 |
| 501819001 |
501819001 |
Price: $2.34 |
| 501821701 |
501821701 |
WASHER Price: $2.99 |
| 501821801 |
501821801 |
RETAINING RING Price: $7.99 |
| 501914801 |
501914801 |
Price: Call Us |
| 502012201 |
502012201 |
CHOKE FLAP Price: $2.62 |
| 504860005 |
504860005 |
Price: $12.05 |
