| Ref | Part Number | Description |
|---|
| 1 |
131-0904 |
SPEED CONTROL ASM Price: $213.51 |
| 2 |
127-0115 |
ROD-HYDRO, RH Price: $9.34 |
| 3 |
127-0116 |
ROD-HYDRO, LH Price: $9.34 |
| 4 |
2411-33 |
BALLJOINT-RH (W/GROMMET) Price: $24.45 |
| 5 |
3220-2 |
NUT-JAM Price: $0.50 |
| 6 |
130-6887 |
MOUNT-PEDAL PIVOT Price: $9.73 |
| 7 |
125-5517 |
PIVOT LEVER ASM Price: $28.67 |
| 8 |
127-3397 |
ROLLER Price: $5.18 |
| 9 |
136-7198 |
BOLT-SHOULDER This part replaces 56-6590. Price: $1.49 |
| 10 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 11 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 12 |
1-543017 |
BALLJOINT-RH Price: $19.99 |
| 13 |
130-6906 |
ROD-THREADED Price: $2.26 |
| 14 |
131-0958 |
DAMPER-NON CAVITATING Price: $53.36 |
| 15 |
3234-47 |
SCREW-HHF Price: $1.79 |
| 16 |
32151-48 |
E-RING Price: $1.41 |
| 17 |
125-3065-01 |
PEDAL-TRACTION Price: $34.67 |
| 18 |
120-4654 |
SCREW-HHF Price: $0.34 |
| 19 |
131-0903 |
NEUTRAL RETURN ASM Price: $93.40 |
| 20 |
131-1034 |
SPACER Price: $1.80 |
| 21 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 22 |
322-10 |
SCREW-HH Price: $0.70 |
| 23 |
70-1160 |
WASHER Price: $3.59 |
| 24 |
324-4 |
SCREW-HH Price: $0.95 |
| 25 |
84-1560 |
WASHER-THRUST Price: $2.71 |
| 26 |
98-9040 |
PAD-TOE, HYDRO PEDAL Price: $7.60 |
| 27 |
98-9039 |
PAD-HEEL, HYDRO PEDAL Price: $7.60 |
| 28 |
32112-6 |
NUT-PUSH Price: $3.67 |
| 29 |
110-6810 |
STUD-DAMPER Price: $3.50 |
| 30 |
3296-4 |
NUT-LOCK Price: $0.25 |
| 31 |
130-6910-03 |
BRACKET-DAMPER Price: $5.06 |
| 32 |
131-1041 |
COVER-END ROD Price: $1.28 |
| 33 |
32144-44 |
SCREW-HWH, THREAD ROLL Price: $1.39 |
| 34 |
32144-70 |
SCREW-HWHTF Price: $1.99 |
| 35 |
131-8736 |
SPACER-BEARING Price: $1.67 |
