| Ref | Part Number | Description |
|---|
| 1 |
532166627 |
STEERING WHEEL Price: $64.99 |
| 1 |
95-8984 |
TUBE ASM Price: $185.98 |
| 2 |
340-70 |
NUT-LOCK Price: $2.10 |
| 2 |
532193542 |
AXLE.ASM.LT.CAST.LGHTWGHT This part replaces 532172393. Price: $119.99 |
| 3 |
340-68 |
FITTING-TEE, BULKHEAD Price: $36.00 |
| 3 |
596873901 |
KIT SPINDLE ASM.PNT.LH.15 This part replaces 532169840. Price: $14.99 |
| 4 |
596873801 |
KIT SPINDLE ASM.PNT.RH.15" This part replaces 532169839. Price: $27.99 |
| 4 |
95-8831 |
HOSE ASM Price: $86.26 |
| 5 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 5 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
532121748 |
WASHER Price: $3.99 |
| 6 |
95-8823 |
HOSE ASM Price: $156.23 |
| 7 |
95-8983 |
TUBE ASM Price: $82.83 |
| 8 |
340-154 |
UNION-BULKHEAD Price: $44.48 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
93-6762 |
SWITCH-BALL Price: $132.17 |
| 10 |
112-9916 |
HYD CYLINDER ASM Price: $752.66 |
| 10 |
532175121 |
DRAGLINK.15".TIRES.2001 Price: $59.99 |
| 11 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 11 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 12 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 12 |
95-8820 |
HOSE ASM Price: $166.08 |
| 13 |
340-127 |
NUT-BULKHEAD Price: $2.24 |
| 13 |
532136518 |
TUBE, PIVOT AXLE Price: $7.99 |
| 14 |
93-9151 |
FITTING-HYD Price: $40.90 |
| 15 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
| 15 |
95-8824 |
HOSE ASM Price: $145.29 |
| 16 |
115-3411 |
HOSE-HYD Price: $114.49 |
| 17 |
95-8980 |
TUBE ASM Price: $142.88 |
| 18 |
95-8981 |
TUBE ASM Price: $151.38 |
| 19 |
95-8982 |
TUBE ASM Price: $329.91 |
| 20 |
93-2509 |
CLAMP-TUBE Price: $14.32 |
| 21 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 22 |
321-11 |
SCREW-HH Price: $0.36 |
| 23 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 24 |
95-8990 |
SHAFT-PIVOT, REAR Price: $75.06 |
| 25 |
3220-9 |
NUT-JAM Price: $11.71 |
| 26 |
86-1480 |
WASHER Price: $4.82 |
| 27 |
136-3425 |
REAR LIFTARM ASM-RM310X This part replaces 115-3475. Price: $558.16 |
| 28 |
3234-27 |
SCREW-HHF Price: $5.97 |
| 29 |
75-7730 |
WASHER-THRUST Price: $2.88 |
| 29 |
817000612 |
SCREW, 3/8-16X3/4 This part replaces 817060612. Price: $3.99 |
| 31 |
104-1392 |
SHAFT-PIVOT Price: $99.73 |
| 32 |
323-6 |
SCREW-HH Price: $0.66 |
| 32 |
532171888 |
TIE ROD Price: $59.99 |
| 33 |
323-4 |
SCREW-HH Price: $1.02 |
| 33 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111216. Price: $2.99 |
| 34 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 34 |
63-7400 |
WASHER-REBOUND Price: $1.70 |
| 35 |
3-6781 |
WASHER-THRUST Price: $1.40 |
| 35 |
873540500 |
NUT, CROWNLOCK Price: $3.99 |
| 36 |
283-71 |
PIN-LYNCH Price: $2.73 |
| 36 |
532155106 |
KIT.BUSHING.STEERING This part replaces 532155099. Price: $8.99 |
| 37 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 37 |
95-8613 |
BRACKET-SWITCH Price: $21.12 |
| 38 |
3229-1 |
BOLT-CARR Price: $3.39 |
| 38 |
532172092 |
INSERT.CAP.STRG.WH (3 2) (L B) This part replaces 532166626. Price: $12.99 |
| 39 |
3217-5 |
NUT-HEX Price: $0.25 |
| 39 |
819182411 |
Washer 9/16 ID x 1 1/2 OD 11 Ga. Zin Price: $4.99 |
| 40 |
873610600 |
NUT This part replaces 532124701. Price: $2.99 |
| 41 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 41 |
532159945 |
STEERING WHEEL ADAPTOR Price: $6.99 |
| 42 |
121-3616-03 |
GUARD Price: $35.32 |
| 42 |
532145054 |
STEERING BOOT, GRAY This part replaces 532169634. Price: $11.99 |
| 43 |
32136-4 |
NUT-HEX,SLOTTED This part replaces 322-12. Price: $1.56 |
| 43 |
532121749 |
WASHER Price: $2.99 |
| 44 |
322-3 |
SCREW-HH Price: $0.79 |
| 44 |
532407600 |
KIT.RPLMNT.SHAFT.STRG. This part replaces 532180640. Price: $59.99 |
| 45 |
32128-20 |
NUT-HF Price: $0.99 |
| 46 |
32120-93 |
RING-RETAINING Price: $2.49 |
| 46 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 47 |
95-8575 |
PIN-CLEVIS Price: $15.31 |
| 48 |
63-0070 |
SPACER Price: $1.82 |
| 49 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 51 |
873540400 |
NUT.CROWNLOCK.1/4-28 Price: $4.99 |
| 54 |
871130420 |
Bolt Hex 1/4-28 unf x 1-1/4 Gr. 8 Price: $4.99 |
| 65 |
532414736 |
SPACER.BRACE.AXLE This part replaces 532160367. Price: $5.99 |
| 67 |
872110618 |
BOLT CARRIAGE This part replaces 872140618. Price: $4.99 |
| 68 |
531167401 |
SERVICE KIT BRACE.AXLE.1 This part replaces 532169827. Price: $19.99 |
| 71 |
531167801 |
SERVICE KIT STEERING ASM This part replaces 532175146. Price: $139.99 |
| 82 |
531170201 |
SERVICE.KIT BRACKET This part replaces 532169835. Price: $19.99 |
| 87 |
532173966 |
WASHER, FLAT .781 X 1 1/2" Price: $4.99 |
| 88 |
532175118 |
BOLT, SHOULDER 7/16-20 Price: $4.99 |
| 91 |
532175553 |
CLIP.STEERING Price: $9.99 |
| 99 |
3290-379 |
TIE-CABLE Price: $0.31 |
