| Ref | Part Number | Description |
|---|
| 1 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 1 |
94-2672 |
CHUTE ASSEMBLY This part replaces 44-5300. Price: $596.99 |
| 2 |
3290-409 |
RIVET Price: $0.34 |
| 2 |
532442869 |
SHIELD.SIDE.OUTER.LH.RED Price: $14.99 |
| 3 |
532008393 |
STAKE PIN TI Price: $19.99 |
| 4 |
812000035 |
RING, KLIP Price: $3.99 |
| 4 |
82-5510 |
DECAL-WARNING Price: $7.09 |
| 5 |
56-4780-03 |
IMPELLER ASM This part replaces 56-4780. Price: $926.99 |
| 5 |
595901601 |
GSPW Bolts This part replaces 532180847. Price: $2.99 |
| 6 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 6 |
532008394 |
SPRING TI Price: $7.99 |
| 7 |
532008392 |
BRACKET.LATCH.STAKE.3.20.BLACK Price: $4.99 |
| 7 |
59-5070-03 |
MTG PLATE ASM This part replaces 59-5070. Price: $328.99 |
| 8 |
532109230 |
SPRING CRT Price: $4.99 |
| 8 |
74-0910-03 |
BRACKET This part replaces 59-4980. Price: $63.99 |
| 9 |
581812705 |
SHIELD.SIDE.PNT.RED This part replaces 532442868. Price: $7.99 |
| 9 |
59-5050 |
LH BRACKET ASM, WELDED Price: $122.99 |
| 10 |
59-5140-03 |
BLOWER MT ASM This part replaces 59-5140. Price: $186.99 |
| 11 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 12 |
62-6520 |
KNOB Price: $7.79 |
| 13 |
3257-40 |
KEY Price: $7.99 |
| 13 |
872110510 |
BOLT.CARRIAGE.5/16-18 Price: $4.99 |
| 14 |
53-4530-03 |
GEAR BOX ASM This part replaces 53-4530. Price: $1,650.99 |
| 14 |
581813501 |
BRACKET.TINE.SHIELD.TILLER.BLA This part replaces 532124311. Price: $11.99 |
| 15 |
532442870 |
SHIELD.SIDE.OUTER.RH.RED Price: $17.99 |
| 15 |
59-5150-01 |
GEARBOX COVER This part replaces 59-5150. Price: $41.91 |
| 16 |
3255-17 |
WASHER-LOCK, EXT Price: $0.29 |
| 16 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873900400. Price: $3.99 |
| 17 |
3290-134 |
SCREW Price: $0.27 |
| 18 |
323-7 |
SCREW-HH Price: $0.65 |
| 18 |
872040410 |
BOLT Price: $3.99 |
| 19 |
532102701 |
GRIP CRT Price: $9.99 |
| 19 |
74-0910-03 |
BRACKET This part replaces 59-5000. Price: $63.99 |
| 20 |
32152-1 |
NUT-LOCK, CONE Price: $1.49 |
| 20 |
873220600 |
NUT.HEX.3/8-16UNC Price: $4.99 |
| 21 |
3218-3 |
NUT-JAM Price: $0.25 |
| 21 |
531154801 |
SERVICE KIT STAKE STAKE.DEPTH. This part replaces 532102156. Price: $8.99 |
| 22 |
59-5090 |
RH BRACKET ASM, WELDED Price: $129.99 |
| 22 |
874930632 |
BOLT.375-16 Price: $5.99 |
| 23 |
322-3 |
SCREW-HH Price: $0.79 |
| 23 |
532004440 |
HINGE CRT Price: $3.99 |
| 24 |
44-5460-03 |
LH PLT BRKT This part replaces 44-5460. Price: $16.99 |
| 24 |
596133401 |
Bolts This part replaces 872140404. Price: $1.99 |
| 25 |
3230-1 |
BOLT-CARR Price: $1.49 |
| 25 |
532006712 |
VINYL CAP This part replaces 532124717. Price: $3.99 |
| 26 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 26 |
532109227 |
PAD IDLER TI Price: $3.99 |
| 27 |
3296-44 |
NUT-LOCK, NI Price: $2.46 |
| 27 |
532442871 |
SHIELD.LEVELING.TILLER.RED Price: $29.99 |
| 28 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 28 |
532120588 |
PIN.HINGE.TILLER Price: $6.99 |
| 29 |
581812705 |
SHIELD.SIDE.PNT.RED This part replaces 532442868. Price: $7.99 |
| 29 |
63-9710 |
SPACER-BEARING Price: $10.24 |
| 30 |
321-3 |
SCREW-HH Price: $0.28 |
| 30 |
596040501 |
Hardware This part replaces 873970500. Price: $2.99 |
| 31 |
13-0269 |
BLOWER HOUSING ASM Price: $579.99 |
| 32 |
37-6730 |
CUP-BEARING Price: $15.84 |
| 32 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 873220400. Price: $2.99 |
| 33 |
38-7820 |
BEARING-BALL Price: $13.99 |
| 33 |
596029801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040400. Price: $2.99 |
| 34 |
63-9700-03 |
PLATE-COVER This part replaces 63-9700. Price: $18.43 |
| 35 |
43-0940 |
SPACER Price: $1.25 |
| 35 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 872110505. Price: $2.99 |
| 36 |
3235-22 |
SCREW-HH, LOCK Price: $2.59 |
| 37 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 37 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 38 |
43-0960-03 |
BRACKET-CHUTE This part replaces 43-0960. Price: $18.26 |
