| Ref | Part Number | Description |
|---|
| 1 |
323-7 |
SCREW-HH Price: $0.65 |
| 2 |
323-6 |
SCREW-HH Price: $0.66 |
| 3 |
3290-467 |
PIN-HAIR Price: $0.27 |
| 4 |
61-3810 |
PLATE-REAR, 5 BLADE Price: $12.60 |
| 5 |
61-0790 |
SCREW-HH Price: $2.57 |
| 6 |
61-0420-01 |
SUPPORT-HOC This part replaces 61-0420. Price: $31.94 |
| 7 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 8 |
71-3690 |
SPADE-BENT Price: $16.90 |
| 9 |
3290-55 |
RIVET-POP Price: $0.25 |
| 10 |
61-0910 |
BRACKET-ANGLE Price: $12.36 |
| 11 |
61-0380-01 |
CAP-END,ROLLER This part replaces 61-0380. Price: $64.74 |
| 12 |
105-0156 |
SHAFT-ROLLER This part replaces 61-0400. Price: $88.81 |
| 13 |
253-152 |
SEAL-OIL Price: $4.54 |
| 14 |
254-79 |
BEARING-ROLLER, CUP Price: $6.39 |
| 15 |
3231-2 |
BOLT-CARR Price: $0.81 |
| 16 |
14-4479 |
REAR HOC BRACKET AND BUSHING ASM This part replaces 61-0430. Price: $79.03 |
| 17 |
56-9520 |
BUSHING-FLANGED Price: $2.15 |
| 18 |
56-9510 |
BUSHING ASM Price: $12.89 |
| 19 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 20 |
71-3590 |
NUT-ADJUSTMENT Price: $19.21 |
| 21 |
105-0150 |
SEAL-GREASE This part replaces 253-153. Price: $4.88 |
| 22 |
254-78 |
BEARING-CONE Price: $12.22 |
| 23 |
03446 |
Kit-Front Skid (Incl. 3 Assemblies) Price: Call Us |
| 501220001 |
501220001 |
SCREEN Price: $0.99 |
| 501220101 |
501220101 |
LOCKING RING Price: $0.69 |
| 501220201 |
501220201 |
PLUG (TIL 179-60X) Price: $2.25 |
| 501220301 |
501220301 |
Plug Price: $0.85 |
| 501220401 |
501220401 |
BALL Price: $11.99 |
| 501220501 |
501220501 |
SPRING Price: $3.99 |
| 501220801 |
501220801 |
GASKET, METERING SIDE Price: $3.99 |
| 501220901 |
501220901 |
METERING DIAPHRAGM Price: $14.99 |
| 501221201 |
501221201 |
FUEL PUMP DIAPHRAGM Price: $7.99 |
| 501221301 |
501221301 |
GASKET, PUMP SIDE Price: $3.99 |
| 501221401 |
501221401 |
CAP Price: $27.99 |
| 501221701 |
501221701 |
SPRING Price: $3.99 |
| 501222001 |
501222001 |
LEVER Price: $4.99 |
| 501222101 |
501222101 |
SHAFT Price: $6.99 |
| 501222201 |
501222201 |
SCREW Price: $1.30 |
| 501222401 |
578004601 |
FILTER This part replaces 501222401. Price: $0.99 |
| 501222501 |
501222501 |
SPRING Price: $3.99 |
| 501223001 |
503652701 |
SCREW This part replaces 501223001. Price: $4.99 |
| 501223201 |
501223201 |
THROTTLE FLAP Price: $4.99 |
| 501268501 |
501268501 |
IDLE ADJ. SCREW Price: $17.99 |
| 501268901 |
501268901 |
NEEDLE H Price: $6.99 |
| 501269001 |
501269001 |
SPRING Price: $4.99 |
| 501427101 |
501427101 |
Bushing Price: $1.00 |
| 501466701 |
503117001 |
VALVE/INLET. This part replaces 501466701. Price: $19.99 |
| 501494802 |
501494802 |
DIAPHRAGM SET Price: $17.99 |
| 501527701 |
501527701 |
Price: $86.94 |
| 501576101 |
501576101 |
CHOKE SHAFT AND LEVER Price: $9.99 |
| 501696901 |
503801301 |
CONNECTION This part replaces 501696901. Price: $8.99 |
| 501814401 |
501814401 |
THROTTLE SHAFT Price: $6.99 |
| 501815801 |
501815801 |
SPRING Price: $2.07 |
| 501821701 |
501821701 |
WASHER Price: $2.99 |
| 501821801 |
501821801 |
RETAINING RING Price: $7.99 |
| 502012201 |
502012201 |
CHOKE FLAP Price: $2.62 |
| 503486301 |
503486301 |
COVER SCREW Price: $3.99 |
| 503533601 |
503533601 |
COVER Price: $5.99 |
