| Ref | Part Number | Description |
|---|
| 1 |
163465 |
Battery 12 Volt 25 Amp Price: Call Us |
| 1 |
94-3145 |
SCREW-PULLEY Price: $9.84 |
| 2 |
74-8080 |
WASHER Price: $4.77 |
| 2 |
74760412 |
Bolt Hex Hd 1/4-20unc x 3/4 Price: Call Us |
| 3 |
94-3144 |
PULLEY-CRANKSHAFT Price: $766.47 |
| 4 |
74-8100 |
GEAR-PINION Price: $58.79 |
| 5 |
98-3833 |
GEAR - OIL PUMP This part replaces 74-8110. Price: $26.24 |
| 6 |
74-8120 |
KEY-WOODRUFF Price: $3.36 |
| 7 |
94-3150 |
SCREW-HH Price: $1.50 |
| 8 |
176689 |
Box Battery Price: Call Us |
| 8 |
74-7560 |
LOCKWASHER This part replaces 94-3151. Price: $0.67 |
| 9 |
74-8140 |
COVER Price: $137.43 |
| 10 |
74-8150 |
GASKET-COVER Price: $4.08 |
| 11 |
94-3148 |
SEAL Price: $33.41 |
| 12 |
74-8170 |
BEARING SET (STD) Price: $208.01 |
| 13 |
94-3141 |
DISCONTINUED Price: Call Us |
| 14 |
74-8230 |
SHAFT-CRANK Price: $3,552.00 |
| 15 |
74-8240 |
DISCONTINUED Price: Call Us |
| 16 |
176138 |
Switch Interlock Push -In Price: Call Us |
| 16 |
74-8250 |
PIN This part replaces 74-7990. Price: $0.97 |
| 17 |
94-3149 |
GEAR-FLYWHEEL Price: $113.49 |
| 18 |
74-8270 |
DISCONTINUED Price: Call Us |
| 19 |
74-8280 |
SCREW-HH Price: $4.63 |
| 20 |
74-8290 |
DISCONTINUED Price: Call Us |
| 21 |
175685 |
Harness Asm Light W/4152J Price: Call Us |
| 21 |
74-8300 |
CLIP-PIN, PISTON Price: $2.96 |
| 22 |
4152J |
Bulb Light #1156 Price: Call Us |
| 22 |
74-8310 |
PIN-PISTON Price: $24.33 |
| 23 |
94-3158 |
PISTON RING SET Price: $233.60 |
| 24 |
4799J |
Cable Battery 6 Ga 11" red Price: Call Us |
| 24 |
98-9965 |
DISCONTINUED Price: Call Us |
| 25 |
146147 |
Cable Battery 6 Ga w/16 wire, red Price: Call Us |
| 25 |
74-8360 |
CONNECTING ROD Price: $1,118.95 |
| 26 |
175158 |
Fuse 20 AMP Price: Call Us |
| 27 |
73510400 |
Nut Keps Hex 1/4-20 Unc Price: Call Us |
| 27 |
74-8380 |
DISCONTINUED Price: Call Us |
| 28 |
4207J |
Cable Ground 6 Ga 12" black Price: Call Us |
| 28 |
74-8400 |
BOLT-ROD, CONNECTING Price: $23.09 |
| 29 |
121305X |
Switch Plunger Nc Gray Price: Call Us |
| 29 |
74-8420 |
PISTON SET Price: $3,551.52 |
| 29 |
94-3157 |
PISTON SET Price: $3,570.53 |
| 30 |
175566 |
Switch Ign Price: Call Us |
| 33 |
140401 |
Key Ign Price: Call Us |
| 33 |
94-3152 |
SCREW-HH Price: $2.62 |
| 40 |
179720 |
Harness Ign Price: Call Us |
| 41 |
71110408 |
Bolt Blk Fin Hex 1/4-20 x 1/2 Price: Call Us |
| 42 |
131563 |
Cover Terminal Red Price: Call Us |
| 43 |
178861 |
Solenoid Price: Call Us |
| 48 |
140844 |
Adapter Ammeter Price: Call Us |
| 52 |
141940 |
Protection Wire Loop Price: Call Us |
