| Ref | Part Number | Description |
|---|
| 1 |
04110-01 |
U-Nut 1/4-20 Price: Call Us |
| 2 |
48136-13 |
Hose Clamp, 0.69" Dia. Price: Call Us |
| 3 |
04001-03 |
Bolt, Hex Head 1/4-20 x 2.0" Price: Call Us |
| 4 |
48811 |
Hose, 3/8" ID Pushlock - (order by inch) Price: Call Us |
| 5 |
48136-07 |
Clamp, Hose 1/2" Price: Call Us |
| 6 |
481301-03 |
Elbow, 90 Degree - 1/4" NPT x 3/8" Hose Price: Call Us |
| 7 |
482266-01 |
Elbow, 90 Degree - 9/16" O-Ring x 3/8" Hose Price: Call Us |
| 8 |
48471-02 |
Oil Filter Base Price: Call Us |
| 9 |
482606 |
Hose Assembly, 1/2" ID (Tank to Filter Base) Price: Call Us |
| 10 |
425437 |
Mounting Bracket - LH, Oil Cooler Price: Call Us |
| 10 |
425438 |
Mounting Bracket - RH, Oil Cooler Price: Call Us |
| 10 |
425490 |
Mounting Bracket - LH, Oil Cooler (35BVAC) Price: Call Us |
| 10 |
425491 |
Mounting Bracket - RH, Oil Cooler (35BVAC) Price: Call Us |
| 12 |
04021-09 |
Nut, Hex Elastic Stop 3/8-16 Price: Call Us |
| 13 |
482696 |
Pump, Right Hand Price: Call Us |
| 13 |
483100 |
Pump w/Fan, Right Hand (26DFI, 35BVAC) Price: Call Us |
| 14 |
04001-32 |
Bolt, Hex Head 3/8-16 x 1-1/4", Kawasaki FX / FT & FT-EFI Price: Call Us |
| 15 |
04021-09 |
Nut, Hex, Elastic Stop 3/8-16 Price: Call Us |
| 16 |
482695 |
Pump, Left Hand Price: Call Us |
| 16 |
483101 |
Pump w/Fan, Left Hand 26DFI, 35BVAC) Price: Call Us |
| 17 |
481793 |
Block, Pump Control Price: Call Us |
| 18 |
04001-09 |
Bolt, Hex Head 5/16-18 x 1.0" Zinc Price: Call Us |
| 19 |
04019-03 |
Nut, Serrated Flange 5/16-18 Price: Call Us |
| 20 |
48758 |
Oil Filter Price: Call Us |
| 21 |
482483 |
Tee, 3/4" O-Ring x JIC x 1/2" Hose Price: Call Us |
| 22 |
04021-08 |
Nut, Hex Elastic Stop 1/4-20 Price: Call Us |
| 23 |
481164 |
Cap, Hydraulic Tank Price: Call Us |
| 24 |
481507 |
Insert, Filler Neck Price: Call Us |
| 25 |
48603-02 |
O-Ring Price: Call Us |
| 27 |
482571 |
Bushing, .56" Dia. Viton Price: Call Us |
| 27 |
482572 |
Elbow, 90 Degree .38" Hose Price: Call Us |
| 28 |
48136-13 |
Hose Clamp, 0.69" Dia. Price: Call Us |
| 29 |
48811 |
Hose, 3/8" ID, Pushlock (order by inch) Price: Call Us |
| 30 |
04010-10 |
Screw, Phillips Head, 1/4-20 Price: Call Us |
| 31 |
48571-02 |
Cap Price: Call Us |
| 32 |
422694 |
Clamp Plate, Pump Control Price: Call Us |
| 33 |
48136-05 |
Clamp, Hose Price: Call Us |
| 34 |
48350-02 |
Elbow, 90 Degree, 1/2" x 1/2" (35BV Only) Price: Call Us |
| 34 |
48350-05 |
Elbow, 90 Degree, 5/8" x 1/2" Price: Call Us |
| 35 |
48938-02 |
Bushing, 7/8"-14 JIC x 3/4"-16 O-Ring Price: Call Us |
| 36 |
482505 |
Cooler, Oil Price: Call Us |
| 37 |
04001-08 |
Bolt, Hex Head 5/16-18 x 3/4" Price: Call Us |
| 38 |
04003-02 |
Bolt, Carraige 1/4-20 x 3/4" Price: Call Us |
| 39 |
482573 |
Bushing, .78" Dia. Viton Price: Call Us |
| 39 |
482574 |
Elbow, 90 Degree Price: Call Us |
| 40 |
423513 |
Strap, Hydraulic Tank Price: Call Us |
| 41 |
423485 |
Support Bracket, Hydraulic Tank Price: Call Us |
| 42 |
484459 |
Hose Assembly, Pump Price: Call Us |
| 43 |
48572-04 |
Union, 3/4"-16 JIC x 3/4"-16 O-Ring Price: Call Us |
| 44 |
04001-59 |
Bolt, Hex Head, 1/4-20 x 1-1/4" Price: Call Us |
| 45 |
04030-02 |
Lockwasher, 1/4" Spring Price: Call Us |
| 46 |
04060-09 |
Roll Pin, Spring 3/16 x 3/4" Price: Call Us |
