| Ref | Part Number | Description |
|---|
| 2 |
575543314 |
SCREW 14MM Price: $3.99 |
| 3 |
579529401 |
CLAMP PCB Price: $2.99 |
| 4 |
579708201 |
LOOM LOOP SENSOR Price: $11.99 |
| 5 |
579660201 |
PRINTED CIRCUIT ASSY PCBA LOOP Price: $54.99 |
| 6 |
580370701 |
Price: Call Us |
| 7 |
579708701 |
LOOM ON/ OFF Price: $29.99 |
| 9 |
574450101 |
SCREW ITXPANT Price: $3.99 |
| 10 |
115-3018 |
NOZZLE HOLDER KIT Price: $440.14 |
| 11 |
575543314 |
SCREW 14MM Price: $3.99 |
| 12 |
579529401 |
CLAMP PCB Price: $2.99 |
| 13 |
592841401 |
NEEDS DESCRIPTION Price: Call Us |
| 14 |
575543314 |
SCREW 14MM Price: $3.99 |
| 15 |
579529401 |
CLAMP PCB Price: $2.99 |
| 16 |
579728501 |
Price: Call Us |
| 17 |
575543314 |
SCREW 14MM Price: $3.99 |
| 18 |
581556101 |
SPRING GUIDE HEIGHT ADJUSTMENT Price: $4.99 |
| 20 |
121-2411 |
NUT Price: $6.48 |
| 20 |
583944501 |
Price: Call Us |
| 21 |
576019301 |
LOCK WASHER PUSH-ON TYPE P 8 S Price: $2.99 |
| 22 |
580764601 |
WASHER DIN 988 13X8X0.5 Price: $2.99 |
| 23 |
580605101 |
BALL BEARING SINGLE ROW S688 Price: $6.99 |
| 24 |
580605101 |
BALL BEARING SINGLE ROW S688 Price: $6.99 |
| 25 |
535087803 |
WASHER FRONT WHEEL CENTER HOLE Price: $2.99 |
| 26 |
580764601 |
WASHER DIN 988 13X8X0.5 Price: $2.99 |
| 27 |
581621501 |
SHIELD KIT Price: $6.99 |
| 28 |
580487101 |
SEALING 12X18X3 Price: $4.99 |
| 29 |
580605101 |
BALL BEARING SINGLE ROW S688 Price: $6.99 |
| 30 |
579457101 |
WHEEL FRONT WHEEL INSIDE Price: $4.99 |
| 30 |
99-8302 |
WASHER-ADJUSTING Price: $7.16 |
| 31 |
574449801 |
WHEEL RUBBER TYRE Price: $7.99 |
| 32 |
580445101 |
O-RING 2,62X15,54 Price: $3.99 |
| 33 |
580605101 |
BALL BEARING SINGLE ROW S688 Price: $6.99 |
| 34 |
580764601 |
WASHER DIN 988 13X8X0.5 Price: $2.99 |
| 35 |
576019301 |
LOCK WASHER PUSH-ON TYPE P 8 S Price: $2.99 |
| 36 |
579457201 |
WHEEL FRONT WHEEL OUTSIDE Price: $5.99 |
| 37 |
575543314 |
SCREW 14MM Price: $3.99 |
| 38 |
580336102 |
SPINDLE This part replaces 580336101. Price: $9.99 |
| 39 |
579505502 |
HUB CAP REAR WHEEL NO CENTER P Price: $4.99 |
| 40 |
731432401 |
HEXAGON THIN NUT Price: $6.99 |
| 40 |
99-8303 |
SPRING-NOZZLE Price: $11.49 |
| 41 |
586210601 |
WASHER WASHER REAR WHEEL 16X40 Price: $5.99 |
| 42 |
582280202 |
WHEEL ASSY D249 BLACK Price: $32.99 |
| 43 |
582280201 |
WHEEL ASSY D249 HVA LIGHT GREY This part replaces 579505602. Price: $29.99 |
| 44 |
575543314 |
SCREW 14MM Price: $3.99 |
| 46 |
580443901 |
Price: Call Us |
| 47 |
574450101 |
SCREW ITXPANT Price: $3.99 |
| 48 |
581621201 |
PLUG KIT Price: $7.99 |
| 49 |
575543314 |
SCREW 14MM Price: $3.99 |
| 50 |
581621601 |
SCREW KIT Price: $17.99 |
| 50 |
99-8304 |
SPACER-DISTANCE Price: $29.26 |
| 51 |
581621801 |
BEARING KIT Price: $6.99 |
| 52 |
579564701 |
Price: Call Us |
| 53 |
510018703 |
Price: Call Us |
| 55 |
575543314 |
SCREW 14MM Price: $3.99 |
| 56 |
580342101 |
Price: Call Us |
| 57 |
510722901 |
Price: Call Us |
| 58 |
579708001 |
LOOM HEIGHT ADJUSTMENT Price: $17.99 |
| 59 |
579505702 |
COVER REAR WHEEL NO PAINT This part replaces 579505701. Price: $17.99 |
| 60 |
581822501 |
Price: Call Us |
| 60 |
99-8305 |
ROD-PUSH Price: $60.67 |
| 61 |
734113741 |
WASHER Price: $3.99 |
| 62 |
581621402 |
Wheels Price: $59.99 |
| 70 |
99-8306 |
NUT-NOZZLE Price: $34.65 |
| 80 |
99-8307 |
WASHER-PLAIN Price: $8.84 |
| 90 |
115-3020 |
PIECE-NOZZLE Price: $150.73 |
| 100 |
99-8309 |
ADJUSTING WASHER ASM Price: $56.19 |
| 110 |
99-8310 |
WASHER-ADJUST (0.10MM) Price: $2.74 |
| 110 |
99-8311 |
WASHER-ADJUST (0.20MM) Price: $3.56 |
| 110 |
99-8312 |
WASHER-ADJUST (0.30MM) Price: $2.74 |
| 110 |
99-8313 |
WASHER-ADJUST (0.40MM) Price: $2.74 |
| 110 |
99-8314 |
WASHER-ADJUST (0.50MM) Price: $1.91 |
| 110 |
99-8315 |
WASHER-ADJUST (0.52MM) Price: $1.91 |
| 110 |
99-8316 |
WASHER-ADJUST (0.54MM) Price: $1.91 |
| 110 |
99-8317 |
WASHER-ADJUST (0.56MM) Price: $1.91 |
| 110 |
99-8318 |
WASHER-ADJUST (0.58MM) Price: $1.91 |
| 110 |
99-8319 |
WASHER-ADJUST (0.80MM) Price: $1.91 |
| 120 |
98-7676 |
GASKET Price: $2.73 |
