| Ref | Part Number | Description |
|---|
| 1 |
603000127 |
WASHER, 5/16 FLAT Price: $2.99 |
| 2 |
603000134 |
SCREW HX TYP TT Price: $2.99 |
| 3 |
603000183 |
CLAMP Price: $3.99 |
| 3 |
712-05015 |
Nut M6 This part replaces 712-04212. Price: $5.78 |
| 4 |
603000464 |
BRKT, GOV CABLE SNAP-IN Price: $8.99 |
| 5 |
603000340 |
NUT Price: $1.99 |
| 6 |
6030005O8 |
Bracket, Rear, Cable Snap-In Price: Call Us |
| 7 |
603000509 |
BRKT, REAR ACC CABLE SNAP-IN Price: $5.99 |
| 8 |
603000579 |
SCREW, M8-125 X 22 HEX GR.8.8 Price: $2.99 |
| 9 |
603000886 |
CABLE, GOV, SNAP-IN Price: $24.99 |
| 10 |
603000887 |
CABLE, ACC, SNAP-IN Price: $27.99 |
| 45 |
710-04916 |
Bolt M6X14 Price: $3.86 |
| 171 |
710-04982 |
Bolt M8X54 Price: $3.37 |
| 172 |
951-10292A |
SPARK PLUG (F6RTC/RN11YC/BPR6ES) This part replaces 951-10292. Price: $6.35 |
| 174 |
951-11818 |
VALVE SEAL Not Available Price: |
| 175 |
951-10345 |
Valve Kit Not Available Price: |
| 176 |
951-12116 |
Valve Spring Price: $3.24 |
| 177 |
951-12000 |
Valve Spring Retainer Price: $3.53 |
| 178 |
951-11629 |
PUSH ROD GUIDE Price: $7.04 |
| 179 |
951-11606A |
ROCKER ARM This part replaces 951-11606. Price: $29.12 |
| 180 |
710-04902 |
Rocker Arm Stud Price: $5.94 |
| 181 |
951-12001 |
Rocker Arm Price: $6.65 |
| 182 |
751-11123 |
Fulcrum Nut Price: $9.09 |
| 183 |
751-11124 |
Jam Nut Price: $8.18 |
| 184 |
951-11551 |
VALVE COVER GASKET Price: $9.14 |
| 185 |
951-11548 |
VALVE COVER Price: $13.09 |
| 186 |
710-05094 |
Muffler Stud M6X95 Price: $3.78 |
| 186 |
951-10342 |
Muffler Stud Assemlby Price: $8.66 |
| 187 |
951-12474 |
MUFFLER GASKET Not Available Price: |
| 188 |
951-12740 |
Muffler Assembly Price: $71.27 |
| 189 |
951-12741 |
SECONDARY AIR VALVE Not Available Price: |
| 190 |
710-05434 |
BOLT M6 x 12 Not Available Price: |
| 191 |
951-12743 |
Secondary Air Valve Gasket Price: $5.05 |
| 192 |
951-12742 |
SECONDARY AIR TUBE Not Available Price: |
| 193 |
951-12744 |
Muffler Shield Not Available Price: |
| 194 |
951-10351A |
SPARK ARRESTOR This part replaces 951-10351. Price: $48.91 |
| 195 |
710-04983 |
Spark Arrestor Screw Price: $3.65 |
| 196 |
951-11630 |
CYLINDER HEAD GASKET Price: $10.78 |
| 197 |
715-04108 |
Cylinder Head Dowel Pin 10×16 Price: $3.65 |
| 198 |
951-10344 |
Push Rod Kit This part replaces 751-10344. Price: $16.42 |
| 199 |
951-11607 |
Tappet Price: $7.42 |
| 200 |
951-11767 |
CAMSHAFT ASSEMBLY Not Available Price: |
