| Ref | Part Number | Description |
|---|
| 1 |
683-0195-0637 |
BRACKET ASSEMBLY (POWDER BLACK) Not Available This part replaces 683-0195. Price: |
| 2 |
710-0599 |
Self-tapping Screw, 1/4-20 x .5 Price: $3.86 |
| 3 |
710-0751 |
SCREW 1/4-20 x .620 GR5 Price: $3.63 |
| 4 |
710-0924 |
Phillips Pan Screw, 1/4-20 x .75 Price: $4.02 |
| 5 |
710-1017 |
Truss Phillips Screw, 1/4-20 x .625 Price: $7.26 |
| 6 |
710-1268 |
Screw, #10-16 x .375 Price: $3.90 |
| 7 |
710-0376 |
Hex Cap Screw, 5/16-18 x 1.0 Price: $3.66 |
| 8 |
712-0271 |
Hex Sems Nut, 1/4-20 Price: $3.78 |
| 9 |
712-0292 |
U-type Speed Nut, 1/4-20 Price: $8.97 |
| 10 |
912-0431 |
Flange Lock Nut 3/8-16 This part replaces 7120431. Price: $4.29 |
| 11 |
726-0211 |
U-nut, 5/16-18 Price: $3.90 |
| 12 |
726-0293 |
RETAINING NUT Not Available Price: |
| 13 |
931-1854A |
Headlight Lens (8-style) This part replaces 731-1854A. Price: $72.82 |
| 14 |
735-0126A |
RUBBER WASHER Not Available This part replaces 735-0126. Price: |
| 15 |
736-0105 |
Bell Washer, .401 x .87 x .063 Price: $3.96 |
| 16 |
946-1085A |
Choke Cable 39" Lg. This part replaces 746-1085. Price: $28.73 |
| 17 |
783-0475C |
SIDE PANEL (LH) 8STY Not Available This part replaces 783-0475A. Price: |
| 18 |
783-0476B |
SIDE PANEL (RH) 8STY Not Available Price: |
| 19 |
783-0477A |
GRILLE Not Available Price: |
| 20 |
983-0478B |
HOOD-8 STYLE Not Available This part replaces 783-0478A. Price: |
| 21 |
783-1309 |
BRACKET Not Available Price: |
| 22 |
783-0553A-0637 |
HOOD SUPPORT BRACKET Not Available This part replaces 783-0553A. Price: |
| 23 |
710-0604A |
Self-tapping Screw, 5/16-18 x .625 Price: $3.96 |
| 24 |
751-0658E |
Fuel Tank 3 Gal. This part replaces 751-0658D. Price: $107.07 |
| 25 |
751-0603B |
TANK CAP This part replaces 751-0603. Price: $20.42 |
| 26 |
710-0809 |
Self-tapping Screw, 1/4-20 x 1.25 Price: $6.37 |
| 27 |
710-0895 |
Self-tapping Screw, 1/4-15 x .75 Price: $5.82 |
| 28 |
710-3217 |
Truss Phillips Screw, #8-32 x .375 Price: $5.94 |
| 29 |
712-0142 |
Hex Nut, #8-32 Price: $3.90 |
| 30 |
731-1857 |
Throttle Control Knob Price: $12.90 |
| 32 |
731-2226 |
Cruise Control Button Price: $14.70 |
| 33 |
731-2227 |
DASH BRAKE LEVER Not Available Price: |
| 34 |
736-0142 |
Flat Washer, 9/32 x 1/2 x 1/16 Price: $3.95 |
| 35 |
747-1196 |
Brake/Cruise Pivot Rod Price: $13.38 |
| 36 |
749-1087A-0637 |
DASH SUPPORT TUBE Not Available This part replaces 749-1087A. Price: |
| 37 |
747-1184 |
AIR DUCT SUPPORT ROD Not Available Price: |
| 40 |
925-04174A |
PTO SWITCH (BLACK KNOB) TEXT SYM This part replaces 725-1752. Price: $62.00 |
| 41 |
912-3027 |
LOCK NUT 1/4 This part replaces 712-3027. Price: $3.85 |
| 42 |
736-3078 |
Flat Washer, .349 x 1.0 x .063 Price: $3.95 |
| 43 |
710-1238A |
SCREW 5/16-18 x .875 GR5 HXFLG HD This part replaces 710-1238. Price: $3.74 |
| 44 |
712-3004A |
HEX FLANGE NUT Price: $3.49 |
| 45 |
747-1215A |
HOOD LATCH Not Available Price: |
| 46 |
712-0272 |
Hex Sems Nut, #10-32 Price: $3.58 |
| 47 |
710-0473 |
Machine Screw, #10-24 Price: $3.90 |
| 48 |
925-0051 |
Headlight Assembly This part replaces 625-0051. Price: $14.90 |
| 49 |
710-0896 |
Hex Index Washer Screw, 1/4-14 x .0625 Price: $3.86 |
| 50 |
735-0199A |
Rubber Bumper Price: $6.89 |
| 51 |
925-1745A |
Key This part replaces 725-1745. Price: $15.91 |
| 52 |
925-1741 |
Ignition Switch This part replaces 725-1741. Price: $41.91 |
| 58 |
911-0332 |
Clevis Pin This part replaces 711-0332. Price: $14.98 |
| 59 |
OEM-190-679 |
BUMPER KIT Not Available This part replaces 768-0010. Price: |
| 60 |
714-0145 |
Internal Cotter Pin Price: $4.42 |
| 61 |
731-2300 |
HOOD Not Available Price: |
| 63 |
783-1034 |
HOOD BRACKET Not Available Price: |
| 64 |
783-1038A |
Hood Side Bracket (7-Style) Price: Call Us |
