| Ref | Part Number | Description |
|---|
| 1 |
532166627 |
STEERING WHEEL Price: $64.99 |
| 1 |
70-8050-03 |
BUMPER ASM This part replaces 70-8050. Price: $239.62 |
| 2 |
532178557 |
AXLE.FRONT.CAST.MACHINE.W/ZERK Price: $179.99 |
| 2 |
59-5350-01 |
REAR DEFLECTOR WA This part replaces 43-1060. Price: $220.99 |
| 3 |
322-4 |
SCREW-HH Price: $0.35 |
| 3 |
532183226 |
FITTING.GREASE.TAPERED This part replaces 532124836. Price: $4.99 |
| 4 |
32152-1 |
NUT-LOCK, CONE Price: $1.49 |
| 4 |
532161849 |
SPINDLE ASSY LH Price: $27.99 |
| 5 |
322-3 |
SCREW-HH Price: $0.79 |
| 5 |
532161848 |
SPINDLE ASM RH Price: $24.99 |
| 6 |
3256-56 |
WASHER-FLAT Price: $1.15 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 7 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 8 |
59-4920-01 |
IDLER WA This part replaces 59-4920. Price: $214.99 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
32152-4 |
NUT-LOCK, CONE Price: $1.29 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 10 |
59-4930-01 |
IDLER SLIDE This part replaces 59-4930. Price: $69.99 |
| 10 |
874781044 |
Bolt, Fin Hex 5/8-11 x 2-3/4 Price: $3.99 |
| 11 |
532136518 |
TUBE, PIVOT AXLE Price: $7.99 |
| 11 |
59-4940-01 |
IDLER ROD WA This part replaces 59-4940. Price: $114.44 |
| 12 |
3290-211 |
WASHER-SPRING Price: $4.89 |
| 12 |
583612401 |
LOCKNUT M This part replaces 873901000. Price: $2.99 |
| 13 |
19-1470 |
SCREW-SHOULDER Price: $3.49 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 14 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 15 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 15 |
873610600 |
NUT This part replaces 532124701. Price: $2.99 |
| 16 |
532145103 |
SHAFT ASM, STEERING Price: $99.99 |
| 16 |
56-4900-01 |
IDLER LEVER This part replaces 56-4900. Price: $25.99 |
| 17 |
23-1120 |
WASHER Price: $16.99 |
| 18 |
3296-44 |
NUT-LOCK, NI Price: $2.46 |
| 18 |
532175572 |
DRAGLINK, BALL JOINT (3SPG1401 Price: $64.99 |
| 19 |
532156011 |
SUPPORT ASM., STEERING VGT Price: $22.99 |
| 19 |
59-5170-03 |
PULLEY ASM This part replaces 59-5170. Price: $456.93 |
| 20 |
532163887 |
BOOT.STEERING.BLACK.STEALTH This part replaces 532177592. Price: $5.99 |
| 20 |
59-5190 |
NUT-PULLEY Price: $126.34 |
| 21 |
127-1843 |
PLUG-DOME This part replaces 59-5310. Price: Call Us |
| 21 |
532159945 |
STEERING WHEEL ADAPTOR Price: $6.99 |
| 22 |
532155108 |
KIT.BUSHING.STEERING. This part replaces 532155105. Price: $6.99 |
| 22 |
59-5270 |
V-BELT Price: $34.41 |
| 23 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 24 |
59-5290-01 |
LATCH This part replaces 59-5290. Price: $25.44 |
| 25 |
596564401 |
Bolts This part replaces 874780616. Price: $3.99 |
| 25 |
77-0180 |
RH COVER ASM Price: $319.94 |
| 26 |
321-4 |
SCREW-HH Price: $0.99 |
| 26 |
532172092 |
INSERT.CAP.STRG.WH (3 2) (L B) This part replaces 532166626. Price: $12.99 |
| 27 |
532003366 |
BEARING.STEERING.COLUMN This part replaces 532124937. Price: $3.99 |
| 27 |
77-0160-01 |
SPRING BRKT WA This part replaces 77-0160. Price: $60.76 |
| 28 |
3290-321 |
SCREW-HWH Price: $3.99 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 29 |
249-21 |
CLAMP-SLOTTED Price: $18.93 |
| 29 |
532104239 |
BEARING-FLANGE GT Price: $9.99 |
| 30 |
32128-17 |
NUT-LOCK, FLANGE Price: $0.25 |
| 31 |
32153-4 |
NUT-HEX, SIDE DEFORM Price: $0.75 |
| 31 |
532138136 |
BUSHING.NYLINER. Price: $8.99 |
| 32 |
56-4810-03 |
PULLEY ASM This part replaces 56-4810. Price: $229.99 |
| 32 |
819111610 |
WASHER Price: $4.99 |
| 33 |
32121-8 |
PIN-ROLL, SLOTTED Price: $0.88 |
| 33 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 34 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 34 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874780512. Price: $3.99 |
| 35 |
43-1120 |
WARNING DECAL Price: $7.84 |
| 35 |
531165701 |
SERVICE KIT GEAR.ASM.SECT This part replaces 532138059. Price: $49.99 |
| 36 |
532186799 |
ROD.TIE.NON-ADJUSTABLE Price: $59.99 |
| 36 |
56-4920 |
PULLEY-IDLER Price: $85.99 |
| 37 |
323-6 |
SCREW-HH Price: $0.66 |
| 38 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 39 |
323-7 |
SCREW-HH Price: $0.65 |
| 40 |
322-2 |
SCREW-HH Price: $0.69 |
| 41 |
44-7770-01 |
REAR SHELF WA This part replaces 44-7770. Price: $405.61 |
| 41 |
532155246 |
BRACKET INTERLOCK Price: $4.99 |
| 42 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 42 |
92-6297-01 |
FRONT DEFLECTOR WA This part replaces 67-7540. Price: $124.99 |
| 43 |
3230-1 |
BOLT-CARR Price: $1.49 |
| 44 |
44-7780-01 |
RH SHELF This part replaces 44-7780. Price: $28.73 |
| 44 |
532160135 |
EXT.STEERING.PREM.BLACK This part replaces 532177593. Price: $4.99 |
| 45 |
77-0130-01 |
PULLEY COVER WA This part replaces 77-0130. Price: $156.68 |
| 45 |
819132411 |
Washer 13/32 x 1-1/20 x 11 Ga. Price: $2.99 |
| 46 |
3256-12 |
WASHER-FLAT This part replaces 3256-13. Price: $0.99 |
| 46 |
819131610 |
WASHER PM Price: $4.99 |
| 47 |
3290-55 |
RIVET-POP Price: $0.25 |
| 47 |
529846001 |
SERVICE.KIT BRKT.ASM.IDLER.STA This part replaces 532179471. Price: $7.99 |
| 48 |
3256-4 |
WASHER-FLAT Price: $0.28 |
| 48 |
817000612 |
SCREW, 3/8-16X3/4 This part replaces 817060612. Price: $3.99 |
| 49 |
325-32 |
SCREW-HH Price: $5.77 |
| 49 |
596481401 |
Pulleys This part replaces 532175820. Price: $22.99 |
