| Ref | Part Number | Description |
|---|
| 2 |
74-0720 |
TUBE-MANUAL Price: $22.99 |
| 3 |
2412-133 |
CLAMP-R Price: $3.19 |
| 4 |
67-8820-01 |
RH HINGE ASM This part replaces 67-8820. Price: $26.10 |
| 5 |
43-3900-03 |
FAN BELT GUARD ASM This part replaces 43-3900. Price: $290.98 |
| 6 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 10 |
67-8810-01 |
LH HINGE ASM This part replaces 67-8810. Price: $26.95 |
| 11 |
3234-32 |
SCREW-HHF Price: $8.48 |
| 12 |
67-8190-01 |
BRACKET-SUPPORT, ENGINE This part replaces 67-8190. Price: $50.66 |
| 13 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 14 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 16 |
3234-17 |
SCREW-HHF Price: $0.72 |
| 18 |
212-93 |
CLAMP-CASING Price: $3.46 |
| 20 |
72-4320 |
SWITCH-BALL Price: $90.18 |
| 21 |
322-2 |
SCREW-HH Price: $0.69 |
| 22 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 23 |
237-30 |
O-RING Price: $2.50 |
| 24 |
43-8610 |
GUIDE Price: $23.35 |
| 25 |
43-8600 |
SPRING-COMPRESSION Price: $3.03 |
| 26 |
43-8860 |
PLUNGER-SWITCH Price: $11.85 |
| 27 |
43-8620 |
PIN-GUIDE, SWITCH Price: $88.57 |
| 28 |
237-7 |
O-RING Price: $8.82 |
| 29 |
218-461 |
NUT-HH Price: $2.50 |
| 30 |
43-8870 |
BOOT-SWITCH Price: $47.92 |
| 31 |
3-6657 |
CLIP-SKID Price: $22.64 |
| 32 |
86-7040 |
ROD-PROP, SEAT Price: $29.51 |
| 33 |
32144-10 |
SCREW-HWH Price: $4.29 |
| 34 |
93-8472-01 |
GUARD - FLYWHEEL This part replaces 93-8472. Price: $77.00 |
| 503217120 |
503216618 |
SCREW This part replaces 503217120. Price: $3.99 |
| 503718201 |
503718201 |
START/STOP SWITCH Price: $11.99 |
| 503877901 |
503877903 |
THROTTLE TRIGGER This part replaces 503877901. Price: $7.99 |
| 503878001 |
503878001 |
THROTTLE LOCK Price: $4.99 |
| 503878501 |
503878501 |
WIRE Price: $14.99 |
| 503918101 |
503918101 |
LEVER Price: $5.99 |
| 503961301 |
503961301 |
SCREW MT5X11 Price: $0.50 |
| 503961401 |
503961401 |
VIBRATION DAMPER Price: $4.99 |
| 503995501 |
503995501 |
HSG THROTTLE RH Price: $9.99 |
| 503995502 |
503995502 |
HANDLE Price: $19.99 |
| 503995601 |
503995601 |
HANDLE HALF HSG LH Price: $9.99 |
| 503995602 |
503995602 |
HANDLE Price: $19.99 |
| 537011301 |
537011301 |
SPRING Price: $4.99 |
| 537052501 |
544171701 |
THROTTLE CABLE This part replaces 537052501. Price: $19.99 |
| 740420600 |
740420600 |
O-RING 8X1.6 Price: $0.17 |
