| Ref | Part Number | Description |
|---|
| 1 |
139-2564 |
NUT-LUG This part replaces 242-50. Price: $0.99 |
| 1 |
532004197 |
AXLE SHAFT This part replaces 532124662. Price: $80.32 |
| 2 |
28-3680 |
TIRE Price: $118.18 |
| 2 |
812000034 |
Retaining Ring (AYP part number) Price: $2.99 |
| 3 |
217-60 |
RIM Price: $110.16 |
| 3 |
532184956 |
TRANSAXLE 6SP This part replaces 532004199. Price: $699.99 |
| 4 |
26-3790 |
NUT-LOCK Price: $24.46 |
| 4 |
532004216 |
Differential Gear (AYP part number) Price: $8.99 |
| 5 |
10-6821 |
BRAKE DRUM ASM This part replaces 10-6820. Price: $170.90 |
| 5 |
532004215 |
Differential Pinion (AYP part number) Price: $6.99 |
| 6 |
111512 |
DISCONTINUED This part replaces 10-6830. Price: Call Us |
| 6 |
532004217 |
Differential Carrier (AYP part number) Price: $24.99 |
| 7 |
11-1579 |
DISCONTINUED-SEE MPV NOTES This part replaces 215-73. Price: Call Us |
| 7 |
532124674 |
Axle Thrust Washer (AYP part number) Price: $2.99 |
| 8 |
329-3 |
SCREW-HH Price: $0.22 |
| 8 |
874020652 |
Hex Bolt (AYP part number) Price: $4.99 |
| 9 |
3255-7 |
WASHER-LOCK/EXT Price: $1.39 |
| 9 |
532100482 |
STEEL.BALL.KIT(12 BALLS) This part replaces 532124697. Price: $3.99 |
| 10 |
325-11 |
SCREW-HH Price: $1.93 |
| 10 |
532124676 |
Spring Shift Fork Detent (AYP part number) Price: $5.99 |
| 11 |
10-8000 |
BRAKE BRACKET *B Price: $37.62 |
| 11 |
532004985 |
Shift Fork, High-Low Range (AYP part number) Price: $17.99 |
| 12 |
237-80 |
O-RING Price: $6.10 |
| 12 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $5.99 |
| 13 |
353-389 |
FITTING-ELBOW, 45 DEG Price: $36.57 |
| 13 |
532004212 |
PINION This part replaces 532124667. Price: $8.99 |
| 14 |
32108-10 |
DISCONTINUED Price: Call Us |
| 15 |
27-2580 |
DISCONTINUED Price: Call Us |
| 15 |
532006276 |
SNAP RING This part replaces 532124677. Price: $5.54 |
| 16 |
27-2160 |
DISCONTINUED Price: Call Us |
| 16 |
532063363 |
GEAR This part replaces 532124679. Price: $54.99 |
| 17 |
3220-2 |
NUT-JAM Price: $0.50 |
| 17 |
532008118 |
Needle Bearing (AYP part number) Price: $5.99 |
| 18 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 18 |
532124705 |
Sintered Iron Bearing (AYP part number) Price: $7.99 |
| 19 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 19 |
532122238 |
Shift Fork Shaft High-Low Range (AYP part number) Price: $8.99 |
| 20 |
321-2 |
SCREW-HH Price: $2.79 |
| 20 |
532004218 |
Differential Pinion Spacer (AYP part number) Price: $3.99 |
| 21 |
10-6350 |
CONTROL ROD WA Price: $102.40 |
| 21 |
532006252 |
PINION This part replaces 532124673. Price: $5.99 |
| 22 |
321-5 |
SCREW-HH Price: $0.22 |
| 22 |
532124701 |
Gripco Centerlock Nut (AYP part number) Price: $5.99 |
| 23 |
10-8220 |
TOOL BOX PAD Price: $24.12 |
| 23 |
532004986 |
L.H. Shift Fork (AYP part number) Price: $27.30 |
| 24 |
10-6430 |
DISCONTINUED Price: Call Us |
| 24 |
532007393 |
OIL SEAL This part replaces 532124698. Price: $2.99 |
| 25 |
27-2380 |
SPACER Price: $11.14 |
| 25 |
532124709 |
Sintered Iron Bearing (AYP part number) Price: $7.99 |
| 26 |
3290-318 |
DISCONTINUED Price: Call Us |
| 26 |
532124672 |
Shift Fork Shaft (AYP part number) Price: $7.99 |
| 27 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 27 |
532006262 |
R.H. Shift Fork (AYP part number) Price: $29.99 |
| 28 |
3217-9 |
NUT-HH Price: $0.37 |
| 28 |
532122254 |
Shift Shaft, High-Low Range (AYP part number) Price: $7.99 |
| 29 |
3296-3 |
NUT-LOCK This part replaces 215-106. Price: $0.54 |
| 29 |
532006269 |
Oil Seal (AYP part number) Price: $8.99 |
| 30 |
3272-2 |
PIN-COTTER Price: $2.29 |
| 30 |
532005855 |
Pressure Relief Valve (AYP part number) Price: $4.99 |
| 31 |
27-8140 |
DISCONTINUED X-REF Price: Call Us |
| 31 |
532122162 |
R.H Gearcase Rvs Idler Shaft & Bearings (Inc. 17,18,25,33,50,63,76,77 & 82) (AYP part number) Price: $164.33 |
| 32 |
329-7 |
SCREW-HH This part replaces 215-105. Price: $0.22 |
| 32 |
532006277 |
Dowel Pin (AYP part number) Price: $2.99 |
| 33 |
125-5196 |
BUSHING This part replaces 3-0348. Price: $6.00 |
| 33 |
532004225 |
Needle Bearing (AYP part number) Price: $9.99 |
| 34 |
20-7650 |
DISCONTINUED Price: Call Us |
| 34 |
532007396 |
Thrust Bearing Race (AYP part number) Price: $3.99 |
| 35 |
3217-5 |
NUT-HEX Price: $0.25 |
| 36 |
136-8446 |
KIT, CENTER PULL FRAME This part replaces 12-8200. Price: $340.89 |
| 37 |
283-1 |
PIN-CLEVIS Price: $1.63 |
| 37 |
532007395 |
Thrust Bearing Race (AYP part number) Price: $3.99 |
| 38 |
282-2 |
YOKE Price: $30.04 |
| 38 |
532121878 |
Gearcase Gasket (AYP part number) Price: $17.99 |
| 39 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 39 |
532122163 |
L.H. Gearcase and Bearings (Inc. 18,25,49, 50 (2), 51 and 52) (AYP part number) Price: $159.61 |
| 40 |
10-8010 |
DISCONTINUED X-REF Price: Call Us |
| 40 |
813320400 |
N.P.T. Pipe Plug (AYP part number) Price: $2.99 |
| 41 |
11-5790 |
KEY-SQUARE Price: $17.50 |
| 42 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 43 |
62-5070 |
DECAL-WARNING This part replaces 27-2890. Price: $5.59 |
| 44 |
215-75 |
HOLD DOWN SPRING Price: $7.60 |
| 45 |
532006271 |
Oil Seal (AYP part number) Price: $3.99 |
| 45 |
99-5652 |
BRAKE ASM & LEVER This part replaces 3-6944. Price: $179.21 |
| 46 |
215-74 |
DISCONTINUED Price: Call Us |
| 46 |
813060200 |
N.P.T. Pipe Plug (AYP part number) Price: $2.99 |
| 47 |
215-76 |
DISCONTINUED Price: Call Us |
| 47 |
539976935 |
CAPSCREW 5/16 X 1/1/2 HEX HEAD This part replaces 874780524. Price: $1.99 |
| 48 |
232-24 |
STEM-VALVE Price: $4.03 |
| 48 |
810040500 |
LOCKWASHER This part replaces 810140500. Price: $2.99 |
| 49 |
532004895 |
Needle Bearing (AYP part number) Price: $9.99 |
| 50 |
532004222 |
Needle Bearing (AYP part number) Price: $5.99 |
| 51 |
532001529 |
Needle Bearing (AYP part number) Price: $7.99 |
| 52 |
532008119 |
Needle Bearing (AYP part number) Price: $17.99 |
| 53 |
532004220 |
Thrust Bearing Race (AYP part number) Price: $3.99 |
| 55 |
532004213 |
GEAR This part replaces 532124668. Price: $44.99 |
| 58 |
532004214 |
Final Dive Pinion (AYP part number) Price: $14.99 |
| 61 |
532004208 |
PINION This part replaces 532124666. Price: $14.99 |
| 63 |
532007398 |
Needle Bearing (AYP part number) Price: $8.99 |
| 64 |
532004203 |
LOW SPEED GEAR This part replaces 532124664. Price: $22.99 |
| 65 |
532004204 |
Reverse Gear (AYP part number) Price: $17.99 |
| 66 |
532002898 |
Key-Hi-Pro (AYP part number) Price: $2.42 |
| 67 |
532004926 |
Snap Ring Crescent Type (AYP part number) Price: $2.99 |
| 68 |
532004205 |
Intermediate Speed Gear (AYP part number) Price: $16.93 |
| 69 |
583750601 |
GEAR.HIGH SPEED This part replaces 532125099. Price: $11.99 |
| 70 |
532001370 |
Thrust Bearing Race (AYP part number) Price: $2.99 |
| 71 |
532063369 |
GEAR.CLUSTER.GT. This part replaces 532124681. Price: $32.99 |
| 72 |
532000208 |
Input Shaft (AYP part number) Price: $74.99 |
| 73 |
532004201 |
Low Speed Pinion (AYP part number) Price: $22.99 |
| 74 |
812000002 |
E-Ring (AYP part number) Price: $3.99 |
| 75 |
532001153 |
Reverse Idler Gear (AYP part number) Price: $8.99 |
| 76 |
532100482 |
STEEL.BALL.KIT(12 BALLS) This part replaces 532007392. Price: $3.99 |
| 77 |
532003990 |
Needle Bearing (AYP part number) Price: $6.44 |
| 78 |
873220500 |
Hex Nut 5/16-18 (AYP part number) Price: $3.99 |
| 79 |
532001167 |
Sealing Washer (AYP part number) Price: $2.99 |
| 80 |
873610700 |
NUT.ASF.HEX.7/16 This part replaces 873360700. Price: $3.99 |
| 81 |
532006270 |
SEAL This part replaces 532124675. Price: $3.99 |
| 82 |
532124696 |
Reverse Idler Shaft (AYP part number) Price: $32.99 |
| 84 |
532005384 |
Bent Gear Shift Lever (AYP part number) Price: $17.99 |
| 85 |
532002978 |
Gear Shift Cap (AYP part number) Price: $3.99 |
| 86 |
532063385 |
COVER This part replaces 532124682. Price: $8.99 |
| 87 |
532008739 |
GUIDE BALL This part replaces 532124704. Price: $12.99 |
| 88 |
532004924 |
Spring (AYP part number) Price: $3.99 |
| 89 |
819151516 |
Washer (AYP part number) Price: $6.99 |
| 90 |
532110542 |
Shift Mechanism Seal (AYP part number) Price: $5.99 |
| 91 |
819181511 |
Washer (AYP part number) Price: $2.99 |
| 92 |
532000075 |
Gear Shift Gate and Reinforcement (AYP part number) Price: $3.99 |
| 93 |
532006274 |
Shift Ball Cover Gasket (AYP part number) Price: $3.99 |
| 94 |
876020412 |
Cotter Pin (AYP part number) Price: $3.99 |
| 95 |
810040500 |
Lockwasher 5/16 (AYP part number) Price: $2.99 |
| 96 |
874760514 |
Hex Bolt 5/16 x 18 UNC x 7/8 (AYP part number) Price: $3.99 |
| 97 |
532124678 |
Gear Shift Lever Assy. (AYP part number) Price: $3.33 |
