| Ref | Part Number | Description |
|---|
| 1 |
75-0540 |
TETHER AND BUTTON KIT This part replaces 2410-73. Price: $6.89 |
| 2 |
532188655 |
MUFFLER.SINGLE.CYL.KOHL/B&S Price: $39.99 |
| 2 |
75-0540 |
TETHER AND BUTTON KIT Price: $6.89 |
| 3 |
93-4365 |
CAP-OIL This part replaces 86-4870. Price: $55.97 |
| 4 |
85-9510 |
DISCONTINUED Price: Call Us |
| 5 |
237-79 |
O-RING Price: $5.46 |
| 6 |
354-120 |
FITTING-ELBOW, 90 Price: $30.04 |
| 7 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 8 |
237-146 |
O-RING Price: $3.75 |
| 9 |
23-8910 |
STEM-BARB-90 Price: $153.60 |
| 9 |
532194319 |
KEEPER.BELT.ENGINE.3.25 (3 2) Price: $11.99 |
| 10 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 11 |
85-7610 |
DISCONTINUED Price: Call Us |
| 12 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 12 |
586729001 |
PULLEY.ENGINE This part replaces 532401985. Price: $27.99 |
| 13 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 14 |
321-3 |
SCREW-HH Price: $0.28 |
| 15 |
581289901 |
FUEL.TANK.ASM.NON-EPA This part replaces 532407545. Price: $44.99 |
| 15 |
61-3770 |
FILTER HEAD ASM Price: $132.08 |
| 16 |
354-78 |
FITTING-STR Price: $49.33 |
| 17 |
85-7680 |
DISCONTINUED Price: Call Us |
| 18 |
23-9740 |
FILTER-OIL, HYDRAULIC Price: $13.14 |
| 18 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532430220. Price: $22.99 |
| 19 |
240-11 |
BUSHING-FLANGE Price: $5.32 |
| 20 |
532176636 |
CONTROL.TH/CK.C.BLACK This part replaces 532183897. Price: $27.99 |
| 20 |
63-8410 |
WASHER Price: $1.76 |
| 21 |
323-5 |
SCREW-HH Price: $0.41 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 22 |
322-2 |
SCREW-HH Price: $0.69 |
| 23 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 24 |
85-8570-03 |
SHROUD-UPPER This part replaces 85-8570. Price: $19.18 |
| 25 |
14-7579 |
DISCONTINUED Price: Call Us |
| 26 |
32144-11 |
SCREW-THD ROLL, HWH Price: $6.99 |
| 27 |
3274-86 |
SCREW-HSH Price: $1.76 |
| 28 |
587044820 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532137040. Price: $9.99 |
| 28 |
85-9590 |
HOSE-HYD Price: $74.97 |
| 29 |
237-22 |
O-RING Price: $2.43 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
108-8457 |
COOLER-OIL This part replaces 85-9460. Price: $405.79 |
| 31 |
88-8120 |
SCREEN-COOLER, LH Price: $52.83 |
| 32 |
32148-6 |
NUT-CLINCH Price: $1.24 |
| 33 |
88-8110 |
SCREEN-COOLER, RH Price: $52.83 |
| 34 |
85-9670 |
NUT-T Price: $1.63 |
| 35 |
85-9550 |
RUBBER CLAMP ASM Price: $5.56 |
| 36 |
340-18 |
FITTING-HYD, 90 DEG Price: $38.93 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 37 |
92-2349 |
TUBE-VALVE TO COOLER Price: $61.15 |
| 39 |
353-550 |
PLUG-HYD, HH Price: $10.71 |
| 40 |
92-8959 |
TANK-HYD Price: $723.53 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 83 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 86 |
596134201 |
Screws This part replaces 532192334. Price: $2.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 94 |
583955301 |
TUBE.EXHAUST.KOHLER.COURAGE This part replaces 532188654. Price: $27.99 |
| 96 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 97 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 122 |
532421922 |
EXTENSION DRAIN OIL Price: $24.99 |
