| Ref | Part Number | Description |
|---|
| 1 |
125-5266 |
SCREEN Price: $35.26 |
| 1 |
817060408 |
SCREW Price: $4.99 |
| 2 |
532133025 |
CONTROL.TH/CH.RH.BLK.FLG.EEC Price: $24.99 |
| 2 |
75-0170 |
PLUG-THREAD, STRAIGHT Price: $18.20 |
| 3 |
69-3130 |
PLUG This part replaces 107-4352. Price: $62.97 |
| 4 |
121-1723 |
CYLINDER BLOCK KIT Price: $2,637.59 |
| 4 |
596134201 |
Screws This part replaces 871070512. Price: $2.99 |
| 5 |
121-1724 |
PLATE-VALVE, CW Price: $389.03 |
| 5 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 6 |
121-1725 |
SERVO PISTON ASM Price: $476.74 |
| 6 |
532272293 |
GASKET.ENG.1.313 ID.TIN PLATED Price: $8.99 |
| 7 |
125-5270 |
SCREW Price: $9.02 |
| 7 |
596238701 |
Washers This part replaces 811050600. Price: $3.99 |
| 8 |
125-5276 |
ORIFICE (0.8) Price: $19.49 |
| 9 |
121-1726 |
SCREW Price: $8.75 |
| 9 |
734115441 |
WASHER - 26X6.5X1.6 This part replaces 819101216. Price: $0.99 |
| 10 |
125-5300 |
PLUG ASM Price: $29.15 |
| 10 |
596029801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040400. Price: $2.99 |
| 11 |
121-1727 |
SCREW Price: $6.72 |
| 12 |
125-5301 |
PLUG Price: $56.91 |
| 12 |
532137437 |
MUFFLER.SINGLE.B&S.12HP Price: $199.99 |
| 13 |
121-1728 |
SHAFT Price: $501.30 |
| 13 |
532101326 |
DEFL MUFFLER LTV Price: $4.01 |
| 14 |
125-5279 |
BEARING-ROLLER Price: $280.87 |
| 14 |
532161464 |
SCREW.HEX.WS.HD.8-18 X 7/8 This part replaces 817030808. Price: $3.99 |
| 15 |
125-5280 |
RING-RETAINING Price: $11.40 |
| 15 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 16 |
121-1729 |
SHAFT SEAL KIT Price: $144.47 |
| 16 |
532127951 |
STOP THROTTLE Price: $2.52 |
| 17 |
125-5284 |
ADAPTER Price: $752.31 |
| 17 |
874930624 |
Bolt, Hex Head 3/8-16 UNC x 1-1/2 This part replaces 817490624. Price: $6.99 |
| 18 |
125-5285 |
SEAL-ADAPTER Price: $68.04 |
| 19 |
121-1730 |
COUPLING Price: $509.39 |
| 20 |
125-5281 |
SCREW Price: $9.16 |
| 21 |
125-5282 |
SCREW Price: $9.84 |
| 22 |
125-5287 |
PLATE-THRUST Price: $82.02 |
| 23 |
121-1731 |
VALVE-RELIEF, HIGH PRESSURE Price: $989.04 |
| 24 |
125-5291 |
VALVE-RELIEF, HIGH PRESSURE Price: $989.04 |
| 25 |
121-1732 |
SWASH PLATE BEARING KIT Price: $631.14 |
| 26 |
125-5295 |
CONTROL KIT (12 VOLT) Price: $3,452.34 |
| 27 |
125-5303 |
PLUG ASM Price: $29.84 |
| 28 |
125-5297 |
CHARGE RELIEF KIT Price: $490.97 |
