| Ref | Part Number | Description |
|---|
| 1 |
161-7216 |
SEAL KIT This part replaces 117-0235. Price: $95.73 |
| 1 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK This part replaces 532171040. Price: $4.99 |
| 2 |
107-7820 |
VALVE-RELIEF Price: $589.10 |
| 2 |
532401042 |
SEAT.XG090.BLK.KB/BLT.NO-LOG This part replaces 532140838. Price: $149.99 |
| 3 |
532195530 |
PAN.ASM.SEAT.1SLOT This part replaces 532155925. Price: $17.99 |
| 4 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 5 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532153236. Price: $2.99 |
| 6 |
532145006 |
PUSH CLIP Price: $2.99 |
| 8 |
596564401 |
Bolts This part replaces 874760616. Price: $3.99 |
| 9 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 11 |
596135501 |
Washers This part replaces 819133210. Price: $4.99 |
| 12 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 13 |
871110814 |
BOLT.HEX.BLACK This part replaces 874780814. Price: $8.99 |
| 14 |
810040800 |
LOCKWASHER Price: $5.99 |
| 15 |
819171912 |
WASHER Price: $3.99 |
| 16 |
532127018 |
BOLT,SHOULD Price: $4.99 |
| 18 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532171041. Price: $3.99 |
| 19 |
532121248 |
BUSHING Price: $4.99 |
| 20 |
532121250 |
SPRING Price: $3.99 |
| 21 |
532134300 |
SPACER SPLIT 28X.96 Price: $3.99 |
