| Ref | Part Number | Description |
|---|
| 1 |
106-0050 |
LH INNER COVER ASM This part replaces 69-6800. Price: $186.64 |
| 2 |
3234-12 |
SCREW-HHF Price: $0.61 |
| 3 |
69-6360-01 |
PLATE-GEARBOX, LH ASM This part replaces 69-6360. Price: $258.21 |
| 4 |
32128-21 |
NUT-HF Price: $0.39 |
| 5 |
237-81 |
O-RING Price: $2.76 |
| 6 |
340-8 |
FITTING-STRAIGHT Price: $9.70 |
| 7 |
237-65 |
O-RING Price: $2.50 |
| 8 |
88-9360 |
HOSE ASSY Price: $386.10 |
| 9 |
88-9370 |
HOSE ASSY Price: $240.46 |
| 10 |
237-22 |
O-RING Price: $2.43 |
| 11 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 12 |
237-42 |
O-RING Price: $2.78 |
| 13 |
94-4907 |
MOTOR-HYD This part replaces 93-4363. Price: $1,685.80 |
| 14 |
63-0660 |
GEARBOX PULLEY WA Price: $80.31 |
| 15 |
23-1640 |
BUSHING-TAPERLOCK Price: $68.50 |
| 16 |
106-0051 |
LH OUTER COVER ASM This part replaces 69-6810. Price: $251.73 |
| 17 |
3269-25 |
RIVET-POP Price: $0.27 |
| 18 |
69-6870 |
PLATE-MAGNET Price: $4.91 |
| 19 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 20 |
69-6260 |
MAGNET Price: $58.32 |
| 21 |
32105-1 |
SCREW-SHH Price: $3.19 |
| 22 |
3233-30 |
SCREW-CARR Price: $3.26 |
| 23 |
69-6960 |
SPACER-IDLER Price: $22.57 |
| 24 |
140-5848 |
PULLEY-IDLER This part replaces 63-1540. Price: $62.48 |
| 25 |
32128-23 |
NUT-HF Price: $1.51 |
| 27 |
3231-28 |
SCREW-CARR Price: $1.92 |
| 28 |
95-0845 |
DECAL-HOC This part replaces 71-4260. Price: $11.75 |
| 501466901 |
501466901 |
SCREW Price: $7.99 |
| 501468701 |
501468701 |
SCREW Price: $6.99 |
| 501666101 |
501666101 |
FUEL INLET SCREEN Price: $12.99 |
| 501667801 |
530035121 |
IDLE SCREW SPRING This part replaces 501667801. Price: $2.99 |
| 502103001 |
502103001 |
SPACER Price: $11.99 |
| 502103101 |
502103101 |
BUSHING Price: $9.99 |
| 502119701 |
502119701 |
SPRING Price: $0.99 |
| 502213301 |
502213301 |
Throttle Flap Price: $0.84 |
| 502213401 |
502213401 |
SHAFT ASSY, THROTTLE Price: $3.99 |
| 502213501 |
502213501 |
Plug Price: $10.05 |
| 502213601 |
504130807 |
PUMP DIAPHRAGM This part replaces 502213601. Price: $27.99 |
| 502213701 |
502213701 |
FUEL LINE FITTING Price: $5.99 |
| 502213901 |
502213901 |
CHOKE SHAFT Price: $3.99 |
| 503104701 |
503104701 |
SCREW Price: $9.99 |
| 503108701 |
503584601 |
SCREW This part replaces 503108701. Price: $2.99 |
| 503117001 |
503117001 |
VALVE/INLET. Price: $19.99 |
| 503281508 |
503281516 |
CARBURETOR WT500 WALBRO This part replaces 503281508. Price: $99.99 |
| 503281510 |
503281516 |
CARBURETOR WT500 WALBRO This part replaces 503281510. Price: $99.99 |
| 503316717 |
503316717 |
Price: Call Us |
| 503574201 |
503574201 |
WELCH PLUG Price: $6.99 |
| 503581501 |
503581501 |
JET Price: $4.99 |
| 503612301 |
503612301 |
Lo-Speed Needle Price: $2.17 |
| 503612401 |
503612401 |
HI SPEED NEEDLE Price: $2.23 |
| 503625201 |
503625201 |
SCREW Price: $0.55 |
| 503783801 |
503783801 |
Price: $6.17 |
| 503783901 |
503783901 |
Price: $13.11 |
| 503784001 |
503784001 |
Price: $2.42 |
| 503784101 |
503784101 |
GOVERNOR Price: $0.36 |
| 503784201 |
503784201 |
O-RING Price: $2.04 |
| 503795910 |
503795910 |
Price: Call Us |
| 503864301 |
503864301 |
Throttle Lever Price: $3.35 |
| 504130808 |
503896701 |
DIAPHRAGM This part replaces 504130808. Price: $44.99 |
| 504130906 |
504130906 |
GASKET Price: $9.99 |
| 504210049 |
504210049 |
SPRING, H-NEEDLE Price: $11.99 |
| 504210050 |
530035293 |
NEEDLE SPRING This part replaces 504210050. Price: $2.99 |
| 505316745 |
505316745 |
SPRING Price: $2.99 |
| 505316754 |
505316754 |
DIAPHRAGM COVER Price: $3.99 |
| 505316782 |
505316782 |
STARTER LEVER Price: $2.99 |
| 505520110 |
505520110 |
GASKET, METERING SIDE Price: $3.99 |
| 505520125 |
505520125 |
FULCRUM PIN Price: $6.99 |
| 506028101 |
506028101 |
FLAP Price: $2.99 |
| 530035139 |
530035188 |
SPRING-METERING LEVER This part replaces 530035139. Price: $3.99 |
| 530035173 |
530069844 |
GASKET/DIAPHRAGM KIT This part replaces 530035173. Price: $17.99 |
