| Ref | Part Number | Description |
|---|
| 1 |
710-0607 |
Tap Screw, 5/16-18, 0.500 Price: $6.06 |
| 2 |
710-06095 |
Hex Flange Screw, 3/8-16 x .75 Price: $3.70 |
| 3 |
712-04063 |
Flange Lock Nut, 5/16-18 Price: $3.56 |
| 4 |
732-04905 |
Seat Spring Price: $3.49 |
| 5 |
738-0140 |
Shoulder Screw, .435 x .178, 5/16 x .56 This part replaces 938-0140. Price: $4.93 |
| 6 |
738-04012C |
Shoulder Screw, .625 x .145, 3/8-16 This part replaces 738-04012B. Price: $4.75 |
| 7 |
757-05003 |
Seat Price: $242.18 |
| 8 |
783-07213A-0637 |
Seat Pivot Bracket Price: $29.83 |
| 9 |
710-0227 |
Screw, #8 Price: $3.90 |
| 10 |
710-04484 |
SCREW 5/16-18 x .750 Price: $3.19 |
| 11 |
710-1652 |
Tap Screw, 1/4-20, .625 Price: $3.86 |
| 12 |
925-06119C |
IGNITION MODULE SWITCH RMC (MAN PTO BLK) This part replaces 925-04227B. Price: $102.50 |
| 13 |
725-04363 |
Interlock Switch Price: $13.25 |
| 14 |
925-05013 |
Seat Switch Price: $28.07 |
| 15 |
725-1643 |
Switch Spring Price: $8.98 |
| 16 |
926-0320 |
Insulator Plate Price: $6.01 |
| 17 |
738-04237A |
Shoulder Screw, #10-32, .500 Price: $5.30 |
| 18 |
747-06131B |
BATTERY TRAY ROD This part replaces 747-06131. Price: $16.76 |
| 19 |
747-06148 |
Battery Hold Down Bracket Price: $5.59 |
| 20 |
925-1745A |
IGNITION KEYS This part replaces 625-05002. Price: $15.91 |
| 21 |
683-04754-0637 |
PTO Handle Assembly Price: $12.14 |
| 22 |
710-04683C |
SCREW 3/8-16 x 1 This part replaces 710-04683A. Price: $5.67 |
| 23 |
720-04049A |
Handle Grip, 3/8 Price: $14.09 |
| 24 |
750-0526 |
Spacer, .380 ID x .50 OD x .265 Price: $3.96 |
| 25 |
651P08861 |
FUEL TANK ASSEMBLY This part replaces 951-04366B. Price: $81.61 |
| 26 |
751-12089-28 |
Hose Vent, 3/16 EPA Price: $7.79 |
| 27 |
735-04081 |
Rubber Grommet Price: $3.96 |
| 28 |
751-12118 |
Rollover Valve Price: $31.61 |
| 29 |
951-12179C |
FUEL CAP W/12"TETHER VENTED This part replaces 951-12179A. Price: $33.78 |
| 29 |
951-12426B |
Fuel Cap This part replaces 951-12426. Price: $36.44 |
| 30 |
951-10589 |
CARBON CANISTER Not Available Price: |
| 31 |
951-10590 |
Vent Filter Canister Price: $13.59 |
| 32 |
951-10610 |
CARBON CANISTER ADAPTER BRACKET Not Available Price: |
| 33 |
751-10749-30 |
Fuel Hose, White Price: $31.87 |
| 34 |
751-10750-48 |
Fuel Hose, Yellow Price: $50.40 |
| 35 |
925-1707D |
BATTERY Not Available Price: |
| 36 |
738-1132 |
Screw, Shoulder, .250 x .150 Price: $4.47 |
| 37 |
712-0271 |
Nut, Sems, 1/4-20 Price: $3.78 |
| 38 |
712-04064 |
Flange Lock Nut, 1/4-20 Price: $3.64 |
