| Ref | Part Number | Description |
|---|
| 1 |
749-0886 |
UPPER HANDLE Not Available Price: |
| 2 |
747-1094 |
GUIDE ROD Not Available This part replaces 747-0790. Price: |
| 3 |
725-1590 |
CORD MINDER Not Available Price: |
| 4 |
731-1270 |
FAN Not Available Price: |
| 5 |
748-0356 |
BLADE ADAPTER Not Available Price: |
| 6 |
738-0102 |
Axle Bolt Price: $9.22 |
| 7 |
17098P |
HINGE CLIP Not Available This part replaces 17098. Price: |
| 8 |
731-1028 |
FLAP ASSEMBLY Not Available Price: |
| 9 |
749-0885 |
HANDLE-LOW Not Available Price: |
| 13 |
714-0104 |
Hairpin Clip Price: $3.90 |
| 15 |
738-0507B |
Shld. Bolt .5" Dia. x .434" Price: $3.86 |
| 20 |
987-02106A |
HANDLE BRACKET ASSEMBLY (RH) Not Available This part replaces 682-3024. Price: |
| 21 |
987-02107A |
BRACKET ASSEMBLY Not Available This part replaces 682-3025. Price: |
| 24 |
736-0105 |
Spr. Washer .401 x .870 x .063 Price: $3.96 |
| 25 |
936-0356 |
BELL WASHER Not Available This part replaces 736-0356. Price: |
| 26 |
712-0798 |
Hex Nut 3/8-16 Thd. Price: $3.86 |
| 27 |
94832 |
Front Spring Lever This part replaces 14832. Price: $9.48 |
| 28 |
15262B |
Pivot Bar Price: $13.59 |
| 29 |
787-01290A |
Height Adjustment Plate This part replaces 15261A. Price: $10.58 |
| 31 |
682-0018 |
DECK ASSEMBLY Not Available Price: |
| 32 |
753-06761 |
Height Adj. Ass'y. Comp. (R.H.) This part replaces 14578. Price: $57.55 |
| 33 |
731-1263 |
COVER-MOTOR BLACK Not Available Price: |
| 34 |
710-3009 |
Screw #10-24 x .75" Lg. Price: $6.24 |
| 35 |
710-0605 |
Oval C-Sunk Screw 1/4-20 x 1.81 Price: $3.85 |
| 36 |
712-0241 |
Lock Nut 3/8-24 Thd. Price: $3.86 |
| 37 |
710-0654A |
Hex Lock Wash. TT-Tap Scr. 3/8-16 x 1.00" Price: $3.75 |
| 38 |
710-0191 |
Hx Hd.3/8-24: 1.25 Lg. Price: $4.02 |
| 39 |
736-0452 |
Bell Washer .396" I.D. x 1.14" Price: $4.05 |
| 41 |
720-04072A |
Star Knob This part replaces 720-0241. Price: $6.07 |
| 42 |
734-1855 |
Wheel - LH This part replaces 734-1781. Price: $30.37 |
| 43 |
731-1268 |
Upper Handle Insulator Price: $14.24 |
| 44 |
731-1267 |
LOWER HANDLE INSULATOR Not Available Price: |
| 45 |
710-0450 |
SCREW 5/16-18 x 3.0 GR1 Price: $5.59 |
| 46 |
720-0279 |
Wing Nut 1/4-20 Thd. Price: $3.93 |
| 47 |
725-0157 |
Cable Tie This part replaces 726-0240. Price: $3.46 |
| 48 |
736-0331 |
Bell Wash. .39 x 1.13 x .062 Price: $3.50 |
| 50 |
625-0050 |
CORD & SWI Not Available Price: |
| 53 |
742-0718 |
MULCHING BLADE 1 Not Available Price: |
| 54 |
731-1501 |
Mulching Plug Price: Call Us |
| 71 |
726-0230 |
Cable Tie This part replaces 726-0209. Price: $23.95 |
| 72 |
731-1388 |
INSULATOR KNOB Not Available Price: |
| 73 |
710-1251 |
SCREW 3/8-24 x 2.50 GR8 Not Available Price: |
| 78 |
731-1409B |
Side Discharge Deflector This part replaces 731-1409. Price: $24.80 |
| 79 |
N/A |
UNKNOWN |
| 80 |
736-0270 |
SPRING WASHER BELL Price: $3.63 |
| 81 |
710-0599 |
Hex Wash. Hd. TT-Tap Scr. 1/4-20 x .5" Lg. Price: $3.86 |
| 87 |
747-0710A |
Hinge Pin This part replaces 747-0710. Price: $3.86 |
| 88 |
782-7006 |
MOUNTING BRACKET Not Available Price: |
| 89 |
932-0731 |
Torsion Spring This part replaces 732-0731. Price: $9.09 |
